- Page 1 MODEL N0: 1-DIN DVD-NAVICEIVER WITH MOTORIZED 17.8CM /7" LCD DISPLAY USER MANUAL English · FrEnch · gErman...
-
Page 2: Table Of Contents
CONTENTS BEFORE USING START CODE ... 06 FRONT PANEL ... 06 AUXILIARY LCD ...07 REMOTE CONTROL ... 08 BASIC OPERATIONS POWER ON/OFF ...10 NAV ...10 VOLUME ADJUSTMENT ... 10 OPEN SOURCE MENU ...10 PLAYING SOURCE SELECTION ...10 DISPLAY SYSTEM TIME ...11 USING THE TFT MONITOR ...11 RESET THE UNIT ...11 RADIO MODE... - Page 3 ZE-NC514 USB MODE SELECT USB AS PLAYING SOURCE ...24 TOUCH SCREEN CONTROLS ...24 ONSCREEN CONTROL BUTTONS ...24 SUSPEND PLAYBACK ...24 STOP PLAYBACK ...24 DISPLAY FILE LIST..24 FAST PLAYBACK ...24 PREVIOUS/NEXT...24 CHANGE FOLDER ...25 REPEAT PLAYBACK ...25 RANDOM PLAYBACK ...25 INTRO PLAYBACK ...25 DIRECT SEARCH ...25 GOTO SEARCH ...25...
- Page 4 WARNINGS 1. Only connect this unit to a 12V DC power supply with negative grounding. 2. Never install this unit where the operation for safe driving is restrained. 3. Never use the video display function in the front when driving to prevent the violation of laws & regulations and also to reduce the risk of traffic accident, except when using the rear view video camera.
- Page 5 PRECAUTIONS 1. Never disassemble or a djust the unit without any professional guide. For details, please consult an authorized ZENEC dealer for inquiry. 2. lf the front panel or TFT monitor is squalid, please use a clean silicone cloth and neutral detergent to wipe off the spot.
-
Page 6: Before Using
BEFORE USING START CODE: 012345 (Description: Page 35) FRONT PANEL 1. [WIDE] Key: Change display mode 2. [ ] Key: Next/Move cursor to the right 3. [ ] Key: Previous/Move cursor to the left 4. [NAV] Key: Enter/exit NAV source 5. -
Page 7: 14. Auxiliary Lcd
BEFORE USING 10. [ ] Key: Eject disc 11. [OPEN/CLOSE] Key: Open/Close the TFT monitor 12. [AS/TILT+] Key: Auto save/Preview scan/Increase display angle 13. [BAND/TILT-] Key: Change radio band/Decrease display angle 14. AUXILIARY LCD 1. Disc indicator Light up when one disc is inside; Light off when no disc is inside. 2. -
Page 8: Remote Control
BEFORE USING REMOTE CONTROL lntroduce of key functions NOTE: Your remote control may differ slightly from the one pictured here. The above diagram is for illustrative purpose only. 1. [SRC] Key: Select playing source 2 [EJECT] Key: Eject disc 3. [MENU] Key: DVD MENU/PBC 4. - Page 9 BEFORE USING NOTES FOR REMOTE CONTROL USE 1. Aim the remote control at the remote sensor on the unit. 2. Remove the battery from the remote control or insert a battery insulator if the battery has not been used for a month or longer. 3.
-
Page 10: Basic Operations
BASIC OPERATIONS POWER ON/OFF Press any key on the front panel or the [POWER] key on the remote control to turn on the power under standby mode. The unit goes back to the last status after power on. Press and hold the [SRC] key on the front panel or press the [POWER] key on the the remote control to turn off the power under work mode. -
Page 11: Display System Time
BASIC OPERATIONS DISPLAY SYSTEM TIME Press and hold the [DISP] key on the front panel to switch the display information between system time and playing source when the TFT monitor is closed. USING THE TFT MONITOR Open/Close monitor Press the [OPEN/CLOSE] key on the front panel or remote control to push the display panel out or in. -
Page 12: Radio Mode
RADIO MODE SELECT RADIO AS PLAYING SOURCE Open the SOURCE MENU and then touch the RADlO icon. SELECT ONE RADIO BAND Press the [BAND] key on the display panel or on the remote control or touch the [BAND] icon on the user interface to select one radio band among FM1, FM2, FM3, AM1 and AM2. -
Page 13: Manual Save
RADIO MODE MANUAL SAVE When one expected radio station has been detected ... 1. Press the [MEM] icon on the user interface and the preset menu will be opened. 2. Press one preset button among P1~P6. 3. lf you want to abort, press the [Exit] button. PREVIEW SCAN Preview scan searching is such a process that the searching pauses when a station is received and then played for 5–10 seconds. -
Page 14: Rds Operations
RDS OPERATIONS The unit provides basic functions of RDS, including Pl (Program ldentification), radio station name, RT (Radio Text), CT (Clock Time), AF (Alternative Frequency), TA (Traffic Announcement) and PTY (Program Type) selection. AF FUNCTION Alternative frequencies lists are used for the same program service and used in conjunction with the Pl code (Program ldentification code) to assist automatic tuning. -
Page 15: Pty Function
RDS OPERATIONS PTY FUNCTION PTY is the abbreviation for Program Type which is a code defining the type of program being broadcasted (e.g. News or Rock). Six PTY options will display on the screen. To view more PTY options, touch the scroll bar and arrows on the screen. -
Page 16: Disc Mode
DISC MODE INSERT A DISC Upon inserting a disc, the unit will switch to disc mode automatically. NOTES: Please confirm whether there is a disc in the unit before you insert another one. Some recorded discs, such as CD-R, CD-RW, DVD-R, DVD+R, DVD-RW, DVD+RW cannot be played back because of different recording status. -
Page 17: Onscreen Control Buttons
DISC MODE ONSCREEN CONTROL BUTTONS Disc type/ MP3/WMA Icon Numeric keypad Setup menu Fast forward Fast rewind Previous Next Play/ Pause Stop Repeat Random EQ setup EQ setup Back AUDIO SUBTITLE DISP MENU TITLE DIR+ Next folder Previous DIR-... -
Page 18: Suspend Playback
DISC MODE SUSPEND PLAYBACK Press the [/] key on the front panel or remote control or open the onscreen control buttons menu and then touch the [/] button. To resume normal playback, repeat the above operation. STOP PLAYBACK To stop playback, press the [] key on the remote control or open the onscreen control buttons menu and then touch the [] button. -
Page 19: Repeat Playback
DISC MODE REPEAT PLAYBACK Press the [RPT] key on the remote control repeatedly or open the onscreen control buttons menu and then touch the [ ] button repeatedly to alter repeat mode according to the following table. Disc type Repeat Chapter VCD (PBC off) Repeat Single Repeat Single... -
Page 20: Intro Playback
DISC MODE INTRO PLAYBACK When this function is on, the unit will play back the first 10 seconds of each track of a VCD or CD disc. You can search the file you desired using this function. Press the [SCN] key on the remote control to activate this function. Do the above operation again to cancel this function. -
Page 21: Dvd Menu And Title
DISC MODE DVD MENU AND TLTLE This function is only available for the DVD discs having "MENU/TlTLE". Press the [MENU] key on the remote control or open the onscreen control buttons menu and then touch the [MENU] button to open DVD MENU. You can select audio language, subtitle language and so on for playback. -
Page 22: Zoom In/Out
DISC MODE NOTES: When PBC is on, playback goes back to the track list and starts from the first track. When PBC is on, fast motion playback, slow motion playback or skip search is available but repeat playback and searching for a particular chapter or track is prohibited. If you do the operation of random playback, scan playback or searching playback when PBC is on, PBC will be turned off automatically. - Page 23 DISC MODE For VCD 1. Disc type. 2. PBC function indicator. "PBC On" indicates that PBC function has been activated. 3. VCD Track information. "6/18" indicates that this VCD has 18 tracks and the track playing back now is the sixth title. 4.
-
Page 24: Usb Mode
USB MODE SELECT USB AS PLAYING SOURCE Open the SOURCE MENU and then touch the USB icon. NOTES: The unit switches to USB mode once an USB device has been inserted. The unit supports hot swap. USB storage devices formatted with FAT 16/32 are supported by this player, but not NTFS format. -
Page 25: Change Folder
USB MODE CHANGE FOLDER The operation is the same as disc mode. REPEAT PLAYBACK The operation is the same as disc mode. RANDOM PLAYBACK The operation is the same as disc mode. INTRO PLAYBACK The operation is the same as disc mode. DIRECT SEARCH The operation is the same as disc mode. -
Page 26: Ipod Mode
IPOD MODE SELECT IPOD AS PLAYING SOURCE The unit will switch to iPod mode automatically when an iPod player is plugged into the unit. To return to the iPod mode from any other sources, open the SOURCE MENU and then touch iPod. -
Page 27: Video Playback
IPOD MODE VIDEO PLAYBACK 1. Enter iPod video mode Press the [AUDIO] key on the remote control or touch the video icon on the user interface. 2. Control video files playback Use the keys on your iPod player to control playback. NOTES: To exit VIDEO mode, press the [MENU] button on the iPod. - Page 28 DVB-T MODE SELECT DVB-T AS PLAYING SOURCE Open the SOURGE MENU and then select DVB-T, and touch the screen to POP UP control menu. Press the [] button to increase volume or press the [] button to decrease volume. TOUCH SCREEN CONTROLS The touch key areas for DVB-T mode are outlined below: QUICK SELECT Press the [OK] button to POP UP the [QUICKSELECT] menu and press the [] or []...
-
Page 29: Other Modes
OTHER MODES AV-IN External peripheral devices with RCA audio and video outputs can be connected with the unit. To enter AV-lN mode, open the SOURCE MENU and then touch AV-lN. CAMERA This player is "camera ready". Before accessing any camera features, you must purchase and install a rear video camera. -
Page 30: Setup
SETUP SETUP PROCEDURES 1. Enter setup mode Press the [SETUP] key on the remote control or touch the setup icon [ ] on the user interface. The following menu appears after entering the setup mode. The GENERAL sub-menu is highlighted by default. 2. -
Page 31: General
SETUP GENERAL Clock mode 12 Hr: the clock displays in the type of 12 hours such as 11:18 AM. 24 Hr: the clock displays in the type of 24 hours such as 20:18. Clock Adjust the clock displayed on the top right corner of the TFT screen. Tuner Region The unit supports several radio systems and you can select a correct radio system according to your country. -
Page 32: Audio
SETUP AUDIO Set the dynamic range of Dolby digital DVD discs. On: Playback more dynamic audio with Bass. Off: Normal output. Loudness On: Loud mode is on. Off: Loud mode is off. Subwoofer On: Open the subwoofer speaker. Off: Close the subwoofer speaker. Sub Filter You can get different bass effect when you set different cut off frequency of subfilter. - Page 33 SETUP You should set a new password ASAP. METHOD OF CHANGING PASSWORD: 1. Locate the cursor on the 'password' option, press the numeric keys on the remote control or touch the 'Password' option directly to open the onscreen keypad, touch the numeric buttons to enter your password (original password for the first time) and then confirm.
-
Page 34: Hardware
SETUP 3. Close the parental lock Repeat the operation of the first step to enter a 6-digit password (old or new) and then confirm. The parental lock is closed. Load Factory To restore the default settings relating with DVD playback (e.g.: DVD Audio, DVD Subtitle), press the [RESET] option. -
Page 35: Method Of Changing Passwort
SETUP Source Select one playing source that you want to set relative volume. Level You can set relative volume level from 0 to 6. METHOD OF CHANGING PASSWORT 1. Locate the cursor on the “Anti-PSW” option, press the numeric keys on the remote control or touch the “Anti-PSW”... - Page 36 Audio control allows you to easily adjust the audio system to get the best possible sound effect. 1. Enter the EQ setup mode Press the [SEL] key on the remote control or touch the EQ icon in the user interface and the following interface will display on the screen.
-
Page 37: Troubleshooting
TROUBLESHOOTING What appears to be trouble is not always serious. Please check the following points before calling a service center. Problem Unit fuse blown. Unit can not power on. Car battery fuse blown. lllegal operation. Battery depleted. Remote control does not work. Battery installed incorrectly. - Page 38 TROUBLESHOOTING (Continued) Problem Cannot insert disc. Disc does not play back. PBC cannot be used during VCD playback. Repeat or search function is invalid during VCD playback. No disc. Bad disc. Unknown disc. Region Error. Cause Disc playback A disc inside the unit already. Disc is warped or scratched.
-
Page 39: Device Connection
ZE-NC514 DEVICE CONNECTIONS NOTES OF CONNECTION This unit is designed to be used in a vehicle with a 12-volt battery and negative grounding. Before installing this unit to a mobile home, a bus, or a truck, make sure the battery voltage is appropriate for this unit to be used, otherwise, install a transformer to convert the output voltage to 12 V. -
Page 40: Control Cables
DEVICE CONNECTIONS CONTROL CABLES Auto Brightness Control To avoid the display being too bright at night time, if the headlight cable is connected to lLLUMl, turning on the head light will dim the backlight of the TFT LCD and vice versa. TELEPHONE MUTE lf the MUTE cable is connected to a car phone, other audio outputs mute when one call is received by the car phone. -
Page 41: Parking Brake Cable Connections
ZE-NC514 DEVICE CONNECTIONS PARKING BRAKE CABLE CONNECTIONS REVERSE DRIVING CABLE CONNECTIONS Gearbox... -
Page 42: Installation And Uninstall
INSTALLATION AND UNINSTALLATION NOTES OF INSTALLATION 1. Before installation, please make sure proper connections are conducted and the unit operates normally. lmproper connection may result in damage to the unit. 2. Use only accessories designed and manufactured for this unit and other unauthorized accessories may result in damage to the unit. - Page 43 INSTALLATION AND UNINSTALLATION Dashboard Mounting Bracket Long Assemble Bar 4. lnsert the unit into the bracket, fasten the M4 x 6 screw to the fireproofing board available at the back of the dashboard, and use 4 pieces of M2 x 2 screw to lock the assemble bars and the mounting bracket in position.
-
Page 44: Trim Ring Installation
INSTALLATION AND UNINSTALLATION TRIM RING INSTALLATION Attach the trim ring around the front panel with two indentions on one side facing upwards. UNINSTALL Disassemble trim ring 1. Push the trim ring upward and pull out the upper part. 2. Push the trim ring downward and pull out the lower part. DISASSEMBLE THE UNIT 1. -
Page 45: Specifications
ZE-NC514 SPECIFICATIONS General Reference Supply Voltage ... 12V (DC) Operating Voltage Range ... 10.5~15.8V (DC) Max Operation Current ... 10A Grounding System ...Car Battery Negative Pole Installation Dimension (WxHxD) ... 178mm x 50mm x (165+25) mm Installation Angle ... 0°~30° Net Weight ... - Page 46 SPECIFICATIONS Video Normal Video Input Level (CVBS) ... 1.0±0.2V Video Input Impedance ...75Ω Video Output Impedance ...75Ω Video Output Level ... 1.0±0.2V TFT Monitor Screen Diagonal ...17.8cm/ 7 inches Usable Display Area ... 154.1(W) x 87.0 (H) Resolution ... 1440 (W) x 234 (H) Brightness ...400cd/m (Measure the centre brightness after 30 minutes) Contrast ...
-
Page 47: Appendix
APPENDIX REGION CODE According to DVD sale region, the whole world is divided into six regions. A DVD disc can be played back only when its region code is compatible with that of the player in use. Region 1: USA, Canada, East Pacific Ocean lslands; Region 2: Japan, West Europe, North Europe, Egypt, South Africa, Middle East;... -
Page 48: Wiring Connections
APPENDIX WIRING CONNECTIONS... -
Page 49: Warranty
2 YEARS LIMITED WARRANTY Dear customer Thank you for purchasing this ZENEC product. It is advisable to keep the original packing material for any future transporting of the product. Should your ZENEC product require warranty service, please return it to the retailer from whom it was purchased or the distributor in your country. - Page 50 ZENEC by ACR AG · Bohrturmweg 1 · Bad Zurzach · Switzerland...
