  • Page 1 DOWN SET UPPER SET LOWER REVERSE STOP DECOSET KEYPAD Installation Instructions # 201576...
  • Page 2 Please use these QR Codes to access the updated installation instructions and video tutorials. Decoset Thank you for purchasing an SI product. If you have any questions or need any assistance with your Decoset, we would love to help you.

  • Page 3: Table Of Contents

    CONTENTS PARTS IN THE BOX INITIAL CONSIDERATIONS SETUP STEPS WIRING TOPOLOGY - AC 485 SCREENS CONNECTING TO AC 485 SCREENS WIRING TOPOLOGY - LV 485 MOTORS CONNECTING TO LV 485 MOTORS DECOSET MOVEMENT COMMANDS (WHITE BUTTONS & LED) 12 DECOSET SETTING COMMANDS(BLACK BUTTONS) DECOSET CONFIGURATION FOR END USER CONTROL TROUBLESHOOTING USING ON FACTORY RESET MOTORS...

  • Page 4: Parts In The Box

    PARTS IN THE BOX 5 button 8 button keypad 8 button Decora insert - base Decora insert (2)Insert screws (2)Trim plate screws 485 Motor only 485 Motor Interface White trim (1) Cate 5e cable (1)Decoset interface wall plate Parts in the Box...

  • Page 5: Initial Considerations

    INITIAL CONSIDERATIONS The Decoset is a pre-programmed control keypad/limit setting tool. And is designed to allow you to set the limits and adjust the rotation on your 485 screen/shade without the use of a PC or any other hardware. Once you complete your setup, then the keypad can be used to control the 485 screen/shade and installed in a wall.

  • Page 6: Wiring Topology - Ac 485 Screens

    WIRING TOPOLOGY - AC 485 SCREENS Solo/Pro 2 screen AC Power Supply 3 conductors Decoset (up to100') Interface Terminal Block RJ45 Wiring topology - AC 485 screens...

  • Page 7: Connecting To Ac 485 Screens

    CONNECTING TO AC 485 SCREENS 1. Connect the Terminal Block coming from your screen to the 485 interface 2. You can now connect your Decoset to the keypad port of the interface. Note: If you need to extend the length of cable to your Decoset, you can use standard Cat5e up to 100 ft.
  • Page 8 3. Once your Decoset is connected to the screen and the screen has AC power applied, a small red LED will start flashing directly above the RJ45 connector on the back of the Decoset. Note: If this does not happen, then check the AC power and connections (and see Troubleshooting section on Page 20).

  • Page 9: Wiring Topology - Lv 485 Motors

    WIRING TOPOLOGY - LV 485 MOTORS Solo/Pro 2 screen / Nano shades Power Supply Cat 5e (100ft) Decoset Note: Most all LV motors will come with a cable terminated into a 5 position terminal block. Note: The 485 Motor Interface power LED will illuminate green whenever LV power is applied to your shade/screen.

  • Page 10: Connecting To Lv 485 Motors

    CONNECTING TO LV 485 MOTORS 1. The included 485 Motor Interface provides connections for the 5 conductor wire coming from the screen/shade and the wire coming from the low-voltage power supply and a connection for Decoset via Cat5e. From the screen/ shade RJ45...
  • Page 11 3. A small red LED will start flashing directly above the RJ45 connector on the back of the Decoset. Note: If no LED activity, then check the low- voltage power supply and all connections (and see Troubleshooting section on Page 20). Momentary Momentary Momentary...

  • Page 12: Decoset Movement Commands (White Buttons & Led)

    DECOSET MOVEMENT COMMANDS (WHITE BUTTONS & LED) The command status LED will flash once per movement (button press) or in other words for each command sent to motor. Pressing UP will send motor to the Upper limit. Pressing DOWN will send motor to the Lower limit.

  • Page 13: Decoset Setting Commands(Black Buttons)

    DECOSET SETTING COMMANDS (BLACK BUTTONS) The command status LED Holding SET UPPER will continuously move motor up (even past the current upper DOWN Holding SET LOWER will limit). SET UPPER continuously move motor Releasing SET UPPER will down (even past the current set motor upper limit to the SET LOWER lower limit).
  • Page 14 3. Make screen/shade adjustments Screen/shades have upper and lower limits set at the factory. The typical screen installation should not require the upper limit being modified, however the lower limit is often modified, using 1 of the following 2 methods: a.
  • Page 15 Screen/shades have the correct motor rotations set at the factory. The typical screen installation should not require the motor rotation being modified. If directed by SI support the following method, will allow you to change the rotation. Hold the REVERSE button on the Decoset until you see the Command LED flash once.

  • Page 17: Decoset Configuration For End User Control

    DECOSET CONFIGURATION FOR END USER CONTROL When all limit settings have been completed you can mechanically configure the keypad for control only mode. DOWN DOWN SET UPPER Note: Never permanently SET LOWER install the Decoset with 3 REVERSE setting (Black) buttons in STOP STOP place.
  • Page 18 Step 1. Using a thin flathead screwdriver press in the 4 tabs along the side of the base unit to remove the 8 button Decora insert. Step 2. Remove the 3 black settings buttons from base and store in DecoSET box Decoset configuration for end user control...
  • Page 19 Step 3. Place 5 button Decora insert back on base snapping-in all 4 tabs on the sides Step 4. Decoset now ready to be installed in a 1-gang wall box with White trim to finish permanently Decoset configuration for end user control...

  • Page 20: Troubleshooting

    Verify the connection movement issue on between the screen/ (white) the Decoset shade and the Decoset buttons dongle. dongle. AC screen Older screen You will need to purchase doesn't have a low-voltage power 4 conductors supply #1822209 from SI. Troubleshooting...
  • Page 21 Problem Possible Cause Action to Take Mulitple Decoset is Ensure each Decoset is only shades connected wired to a single shade or a move when to multiple single screen. pressing the shades. movement buttons. Dry Contact Not using the Refer to pg. 12 and ensure the not working correct Pins in wiring is correct as per the...

  • Page 22: Using On Factory Reset Motors

    USING ON FACTORY RESET MOTORS SET UPPER SET LOWER REVERSE Decoset keypad can be used with a motor that has been factory reset to set the initial limits and rotation. By using the Set Upper button, to move the motor up and the Set Lower button to move the motor down, you can create the inital limits.

  • Page 23: Adjusting The Movement Buttons

    ADJUSTING THE MOVEMENT BUTTONS Decoset keypad buttons 7 (Down arrow), 8(Up arrow) can be adjusted by using the USB programming kit or TRO.Y. These buttons are default to 20 pulses and can be modified to suit your application. Refer to USB Programming kit or TRO.Y manuals for more details on how to change.
  • Page 24 Screen Innovations 9715-B Burnet Rd, Suite 400 Austin, TX 78758 512.832.6939 www.screeninnovations.com v. 1.7 | 26 Aug 2021...
