- Page 1 SHOP EASY. SAVE MONEY. USER'S MANUAL Ice Cream Maker EP24899US...
-
Page 2: Important Notices
IMPORTANT NOTICES When using an electrical appliance, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury, including the following: 1. Read all instructions before using. 2. Remove all packing material and carefully check your ice cream maker to ensure it is in good condition and that there is no damage to the ice maker or power cord and plug. - Page 3 supervised to ensure that they do not play with the appliance. 13. Do not use the appliance close by flames, hot plates or stoves. 14. Do not switch on the power button frequently (ensure 5min. interval at least) to avoid the damage of compressor. 15.
- Page 4 respect the following instructions: – Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. – Clean regularly surfaces that can come in contact with food and accessible drainage systems. –...
-
Page 5: Product Feature
SPECIFICATIONS Model： EP24899US Capacity：1L Voltage： 120V/60Hz Anti-shock protection class：I Climate type：N/SN N.W：16 LBS G.W： 20.2 LBS PRODUCT FEATURE 1. Knob control, simple and reliable operation, will not bring you a lot of trouble; Plastic shell, elegant, stylish, and light; High mixing and low noise;... - Page 6 1. Please read the instruction manual carefully before use. 2. Check if the voltage range used is the same as that marked on the nameplate, whether the power cord plug and the socket match, and ensure that the socket is well grounded. 3.
- Page 7 gas or electric stove to avoid accidents. 11. Do not start the compressor power switch frequently (at least 5 minutes each time) to avoid damage to the compressor. 12. Metal foil or other conductive materials are not allowed to be inserted into the machine to prevent fire or short circuit.
- Page 8 water to directly wash the evaporator. After operation, please unplug the power plug in time. 20. When the ice cream machine is started without adding ice cream, there will be a slight sound of mixing blade scraping to the loading bowl, which is a normal phenomenon.
- Page 9 .PRODUCT INSTRUCTION…… ………………… .... 1) Structure Motor Transparent lid Mixing blade Loading bowl Top lid Spoon Housing 2) Control panel Single refrigeration mode Power Off Ice cream mode Single Mixing mode...
- Page 10 HOW TO MAKE ICE CREAM NOTE: Please thoroughly clean all parts that will contact with ice cream before use, including: cooling bowl, loading bowl, mixing fan blade, transparent lid, etc. Before cleaning, you must ensure that the power cord plug is disconnected from the outlet.
- Page 11 Step 2. Then put the loading bowl into the ice cream machine, both ends of the loading bowl handle shall be aligned with the groove of the upper cover. Installation position of loading bowl handle Step 3. Install the transparent lid and motor assembly.
- Page 12 Step 4. Install the mixing fan blade, transparent lid and motor assembly Step 5. Put the components installed in step 4 into the ice cream machine, make sure that the center of the convex hull of the loading bowl and the motor components of the mixing fan blade are in the same straight line, lock the components clockwise, and make sure that the triangle mark on the components rotates to the "LOCK"...
- Page 13 Step 6. Plug in the power and turn the knob to select the ice cream mode Step 7. When the ice cream is finished, turn the knob back to the “OFF” position...
-
Page 14: Operation
Step 8. Turn the transparent lid and motor assembly anticlockwise. When the triangle mark is aligned with the unlocking mark, take out the assembly and then take out the loading bowl OPERATION 1. Connect the power supply and plug the power cord into a suitable socket. - Page 15 ② Single refrigeration mode The compressor and cooling fan are started to realize the refrigeration function. The default time is 30min. After completion, there will be 10 beeps to remind that the refrigeration is completed. After completion, please turn the knob to other positions to carry out other operations.
-
Page 16: Electrical Diagram
5. COMPRESSOR SELF-PROTECTION FUNCTION After switching from ice cream mode or single refrigeration mode to shutdown mode, if it is switched back to ice cream mode or single refrigeration mode again, the compressor has a protection time of about 3 minutes. However, after unplugging the power line, start the machine again. -
Page 17: Maintenance
MAINTENANCE Caution: The plug must be removed before cleaning to avoid electric shock. （1）Take out the mixing blade, wipe it with a dampened cloth （2）Take out the removable bowl, clean it with a dampened soft cloth （3）Wipe the transparent lid and refill lid with a dampened cloth （4）Remove the dirt on the body or other places with a dampened... - Page 18 Correct Disposal of this product This marking indicates that this product should not disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
