- Page 1 ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS w w w . s i s t e m a i r . c o m TECHNICAL MANUAL ROLL Flex...
- Page 3 INTRODUCTION Dear Customer, TECNOPLUS S.r.l., owner of the SISTEM AIR Trademark would fi rst of all like to thank you for having chosen to buy our motorized wall-mounted hose reel. We are sure that the characteristics described in this manual will satisfy your needs.
-
Page 4: How To Use The Manual
It is strictly forbidden to reproduce, copy or disclose any part of this document by any means without prior written consent of TECNOPLUS s.r.l. which is the owner of the SISTEM AIR Trademark. TECNO- PLUS s.r.l . reserves the right to upgrade or modify this manual or the vacuum cleaner itself anytime without giving any prior notice to third parties. - Page 5 ROLL FLEX ROLL Flex ROLL Flex Model Ø 32 Ø 40 Article 7041.51E 7041.61E Protection degree Supply V ac 220/240 220/240 Frequency 50/60 50/60 Motor power 120* 120* Absorption 0,92* 0,92* Weight Vacuum inlet (D) Ø mm Flexible hose Ø mm Flexible hose max.
-
Page 6: Safety Features
Instructions manual the motorized wall-mounted hose reel 3 SAFETY FEATURES It is recommended to read carefully all the installation, use and maintenance instructions detai- led in this manual. Furthermore, the following WARNINGS should always be observed: • Never use the machine for unauthorized purposes. •... -
Page 7: Unauthorized Use
4 - AUTHORIZED USE The motorized wall-mounted hose reel RollFlex has been designed exclusively to vacuum clean dust, very small-size solids and dry materials. The use of the motorized wall-mounted hose reel is authorized for tertiary building use and connected to a wall traced PVC or steel pipe network. -
Page 8: Ceiling Installation
Instructions manual the motorized wall-mounted hose reel 7 - INSTALLATION Ceiling installation Wall installation OPTIONAL Art.7041.100 (LINGUA ORIGINALE) 15/09/2021 Rev:1.1.0... - Page 9 7.1 Connection to the pipe network 15/09/2021 Rev:1.1.0 (LINGUA ORIGINALE)
-
Page 10: Electrical Connection
Instructions manual the motorized wall-mounted hose reel 7.2 Electrical connection Electrical supply connection of motorized wall-mounted hose reel system External controls connection MICRO (White) MICRO (red) VALVE (green) VALVE (brown) 10 x 0,75 mm² ROLL UP_CW (grey) ROLL UP_CW (pink) ROLL DOWN_CCW (blue) ROLL DOWN_CCW... - Page 11 MICRO normally open contact (max1A) for connecting the activation signal of the vacuum unit. The MICRO contact has the function of activating / deactivating the suction device of the system automatically when the motorized wall-mounted hose reel is in use or at rest. MICRO (bianco) Linea MICRO MICRO (rosso)
- Page 12 Instructions manual the motorized wall-mounted hose reel ROLL UP connection for an external normally open contact, useful to pick the vacuum hose of the motorized wall-mounted hose reel system up. When the external control is on, motorized wall-mounted hose reel system rewind the hose, completely if the contact stays closed for 0,5 seconds, partially if the contact stay provisionally closed longer than 0,5 seconds.
- Page 13 ON/OFF connection useful for activating / deactivating the suction system and the sleeve valve in manual mode, independently from the position of the motorized wall-mounted hose reel. The suction management command will be provided via the ON / OFF button on the motorized wall-mounted hose reel push button panel (see page 15) Below is an illustrated example of a connection to activate / deactivate suction with manual control.
- Page 14 Instructions manual the motorized wall-mounted hose reel 8 USE WARNING: Do not leave the hose when you rewind it, but follow it through while it rewinds on the wheel during the closing. Do not pull the hose down hard, neither when it winds up nor when it unwinds. It is not recommended to unwind the hose near the hose reel.
- Page 15 Press the button with the arrow UP to rewind the suction hose. If the button is pressed for less than 0.5 seconds, the hose will be completely rolled up and, once the limit switch is reached, it will stop automatically (automatic winding). If the button is pressed for more than 0.5 seconds, the motori- zed wall-mounted hose reel will stop as soon as the button is released (step-by-step operation).
- Page 16 Instructions manual the motorized wall-mounted hose reel 9 MODIFICATION TO THE WINDING HOSE ENDSTOP If it is necessary to modify the limit switch which regulates the roll operaions of the hose on the Mo- torized wall-mounted hose reel device, the number of winding turns can be changed by acting on the switch positioned under the closing casing (see fi...
-
Page 17: Programmed Routine Maintenance
device continues to rotate automatically until one of the two preset limit switches is reached. Using switches 2 and 3, positioned under the closing casing (see fi gure on page 15), it is possible to exclude one of these two functions. To disable the “step-by-step”... -
Page 18: Troubleshooting
Instructions manual the motorized wall-mounted hose reel 13- TROUBLESHOOTING PROBLEM CAUSE SOLUTION Close the other vacuum points Use of more than one vacuum until you have the vacuum power points simultaneously required Check if the fl exible hose and Flexible hose or cleaning the accessories are intact (if accessories broken necessary, replace them) - Page 20 F0920289.1 27020 Gravellona Lomellina (PV) ITALIA - Via Cilavegna, 53 - GPS: N: 45° 19’ 28” ; E: 8° 45’ 32” ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS Tel. + 39 0381 650082 - Fax +39 0381 650120 - info@sistemair.com...
