User's manual
Customer Service
US: 1-800-645-2986
Battery Powered Scissor Lift
Model 989062 - Battery Powered Scissor Lift 40" x 20-1/2" Table 660 Lb. Cap.
Model 988854 - Battery Powered Scissor Lift 40" x 20-1/2" Table 1100 Lb. Cap.
Manual del usuario
Servicio de atención al Cliente
US: 1-800-645-2986
Read this manual thoroughly prior to
installation, operation or maintenance.
Keep these instructions in a safe location
for future reference. For questions, visit
globalindustrial.com or contact Customer
Service at 1-800-645-2986.
1
1
Manuel de l'utilisateur
Service à la clientèle
Canada: 888-645-2986
Advertisement
Table of Contents
Related Manuals for Global Industrial 989062
Summary of Contents for Global Industrial 989062
- Page 1 US: 1-800-645-2986 Battery Powered Scissor Lift Model 989062 - Battery Powered Scissor Lift 40" x 20-1/2" Table 660 Lb. Cap. Model 988854 - Battery Powered Scissor Lift 40" x 20-1/2" Table 1100 Lb. Cap. Read this manual thoroughly prior to installation, operation or maintenance.
- Page 2 Battery Powered Scissor Lift Battery Powered Scissor Lift Instruction Manual READ THIS OPERATION MANUAL COMPLETELY BEFORE USING. THOROUGHLY UNDERSTAND AND FOLLOW ALL SAFETY INSTRUCTIONS. 1. WARNING DO NOT allow another person to stand in front of or behind lifter when it starts to move. ALWAYS travel with table in lowered position.
-
Page 3: Daily Inspection
Battery Powered Scissor Lift 2. CAUTION Hazard or unsafe practice, which, if not avoided, may result in PERSONAL INJURY and PROPERTY DAMAGE. READ THE OPERATION MANUAL COMPLETELY BEFORE USING AND THOROUGHLY UNDERSTAND AND FOLLOW ALL SAFETY INSTRUCTIONS. This lifter is designed for use with stable uniform load on a solid lever floor. DO NOT use the lifter for any other purpose than its intended use. -
Page 4: Name Of Parts
Battery Powered Scissor Lift 4. NAME OF PARTS 1.Handle 4.Platform 2.Switch 5.Link 3.Brake Pedal 6.Guide rail... -
Page 5: Operating Lift Table
Battery Powered Scissor Lift 5. OPERATING LIFT TABLE How to use the brake. CAUTION Use brakes when not moving the lifter to prevent sudden movement. The brake is equipped with the swivel caster on the right side. (1) Activate wheel brakes by pressing the brake pedal. (2) Release the brake by lifting up the brake pedal. -
Page 6: Charging The Battery
Battery Powered Scissor Lift 7.LOWERING TABLE CAUTION DO NOT lower table with load too fast and stop suddenly. Impact load could be created and lifter could be damaged. 8.MOVING THE LIFTER WARNING DO NOT move lifter on slope or inclined surface, otherwise lifter becomes uncontrollable and dangerous (1) Make the load stable to prevent it from falling. -
Page 7: Specifications
Battery Powered Scissor Lift 12. SPECIFICATIONS Model 989062 988854 Capacity (lbs) 1100 Table (inches) 40 x 20.5 40 x 20.5 Min. table height (inches) 19.5 19.5 Max. Table height (inches) 63.7 Lifting stroke (inches) 43.5 44.2 Motor (KW) Work cycle of hydraulic power pack 3 times of table moving up-down per 10 min. - Page 8 Battery Powered Scissor Lift 989062...
-
Page 9: Description Qty
Battery Powered Scissor Lift L L I I F F T T T T A A B B L L E E S S P P A A R R E E P P A A R R T T S S L L I I S S T T 9 9 8 8 9 9 0 0 6 6 2 2 DESCRIPTION QTY NO DESCRIPTION... - Page 10 Battery Powered Scissor Lift Connector block Roller for table Screw M5×10 Bushing Fixing plate Retaining ring for axle 20 Joint board Internal scissors for table Lifting limit switch External scissors for table Spring washer 6 Screw M8×16 Nut M6 Pin axle for scissors Hydraulic power pack Washer Terminals...
- Page 11 Battery Powered Scissor Lift 988854...
- Page 12 Battery Powered Scissor Lift L L I I F F T T T T A A B B L L E E S S P P A A R R E E P P A A R R T T S S L L I I S S T T 9 9 8 8 8 8 8 8 5 5 4 4 DESCRIPTION QTY NO DESCRIPTION...
- Page 13 Battery Powered Scissor Lift Connector block Bushing Screw M5×10 Retaining ring for axle 20 Fixing plate Internal scissors for table Joint board External scissors for table Lifting limit switch Screw M8×16 Spring washer 6 Pin axle for scissors Nut M6 Washer Hydraulic power pack Split pin 3.2×26...
- Page 14 Battery Powered Scissor Lift OPERATION INSTRUCTION ENERGY SERVICE-FREE ACID-LEAD STORAGE BATTERY 1. Storage and Transportation Uncharged ENERGY storage battery needs no maintenance，Please store it in dry ◇ and frost-free place. If the density of electrolyte in filled battery is less than 1.23kg/l, it shall be ◇...
- Page 15 Battery Powered Scissor Lift 3. CHARGING Before recharging，please take the battery down. ◇ The storage battery is allowed to be charged with DC power.Connect the plus ◇ pole and minus pole of storage battery correspondingly to the poles of the charger.
-
Page 16: Warning And Safety
Battery Powered Scissor Lift WARNING AND SAFETY Follow instructions described on the plate of the battery. ◇ Wear safety glasses. ◇ Keep children away from touching electrolyte and battery. ◇ Explosive Hazard Easy-explosive mixture come to escape during charge，So fire ◇...
