Basic Fun K'nex Mega Motorized Deluxe Quick Start Manual

BUILDING BASICS
Start Building
Look at the pictures, find the pieces in your set that match and then
connect them together. Try to face your model in the same direction as
the instructions while you build. The arrows show you where the parts
connect, but not all connection points have arrows. Faded colors show
you this section is already built.
Connectors
Push these special connectors together tightly until you hear a "click".
Spacers
Be sure to use the correct color and number of spacers shown.
Keep this important information for future reference

BATTERY INFORMATION

How to Insert and Remove Batteries

Use a small Phillips head screwdriver to loosen the screw. Insert 2 fresh AA
batteries** (LR6) into the compartment with the correct polarity (+/-) as shown
here. Install batteries before building models.
** Not included
CAUTION: To Avoid Battery Leakage
• Insert batteries with correct polarity (+/-) as shown.
• Do not mix different types of batteries.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable batteries.
• Do not mix new and used batteries. Only batteries of the same or equivalent
type recommended should be used.
• Remove exhausted batteries from the toy; do not short-circuit supply terminals.
• Remove all batteries if the toy will not be used for a long period of time.
*Important Battery Tips
See back panel.
3
1
1
90994
90900
4 2
90950
91224
1
4
1-3
PARTS LIST
Before you start building, be sure to compare the parts in your set with the parts list here.
If anything is missing, contact us using the information on the back cover. We are here to help you!
WARNING: CHOKING HAZARD – Small parts. Not for children under 3 years.
CAUTION: – Keep hands, face, hair and clothing away from all moving parts.
