Summary of Contents for BaSys FOLDJET 2000
- Page 1 General Operation Folding Programs for the FOLDJET 2000...
- Page 2 Manufacturer: Basys GmbH. Wilhelm-Fressel-Straße 4 D-21337 Lüneburg Germany Telephone 0 41 31/95 23-0 Telefax 0 41 31/5 79 78 We reserve the right to change or modify without notice. All proposals are subject to availability. Copying of this Manual in whole or in part, transmission of this document or its contents to Third Parties or commercial is strictly forbidden unless agreed to in writing.
- Page 3 Control Panel Functions: Keyboard Folding for DIN A0 & E size Formats. Folding for DIN A1 & D size Formats. Folding for DIN A2 & C size Formats. Folding for DIN A3 & B size Formats. Wildformat Folding / Stop. The size of material to be folded may be a minimum length of 420 mm(16.5") by up to 30 m (100').
- Page 4 Feeding Instructions Positioning of the Paper Lay the paper flat on the feed in table. Smooth out paper and flatten any folded edges. Make sure the first few inches of the leading edge(15 -20 cm)is not curled. If curl exists re-roll the paper against the curl to flatten out the paper.
- Page 5 User Set-up To enter User Set-up press both the Packetfold and Border keys simultaneously. By use of the keys you will be able to move through the menu and reset the values. Sheet Counter: This indicates the total number of sheets which have been folded. With the you are able to reset the counter to zero.
- Page 6 Standards (User Set-up) Default Minimum Maximum 210/8.25 100/4.1 350/13.75 Fold width 190/7.5 100/4.1 330/13 20/0.8 10/0.4 50/1.96 Margin/Border 297/11.75 100/4.1 350/13.75 Crossfold Units Inches Format Engineering Architectural Language German English Cleaning and Service During regular use the feed in table may become dull and sticky. Clean the table and paper guide area with a soft cloth using a non-abrasive cleanser.
- Page 7 Page 5...
- Page 8 Page 6...
- Page 9 Page 7...
- Page 10 Page 8...
- Page 11 Page 9...
- Page 12 Page 10...
- Page 13 Page 11...
- Page 14 Page 12...
- Page 15 Page 13...
- Page 16 Page 14...
- Page 17 Datei: g:\anleitun\foldjet2000\ae.p65 Page 15 Stand: 09.01.01 Bearbeiter: Ge/Gu...
