INDCO HS-5 Series Owner's Manual
  1. Manuals
  2. Brands
  3. INDCO Manuals
  4. Industrial Equipment
  5. HS-5 Series
  6. Owner's manual

INDCO HS-5 Series Owner's Manual

Disperser
Hide thumbs

Advertisement

Quick Links

Download this manual
HS-5
Series
Disperser
OWNERS
MANUAL
Warranty
Our products are guaranteed against
defective materials and workmanship, we will
repair or replace such items as may prove
defective at our option. Warranty period is
one year on items manufactured by INDCO.
On items not manufactured by INDCO, the
manufactures warranty applies.
component parts of our products are covered
by this warranty, except for normal wear items
such as belts or impellers. We cannot be
responsible for damage or abuse to equipment
caused by improper installation or operation.
Warranties can also be voided by
unauthorized disassembly of equipment. For
warranty repairs, equipment is returned to
INDCO at the customer's expense; we will
repair and return to customer at our expense.
Under no circumstances will we allow labor
charges or other expense to repair defective
merchandise. This warranty is exclusive and
is in lieu of all other warranties, whether
express or implied. INDCO shall not be liable
for
any
other
damages,
consequential, indirect, or incidental, arising
from the sale or use of its products.
INDCO, Inc.
Contents
Safety, General & Installation
Operation
Maintenance .
Electric Motor Data & Troubleshooting
Parts List
All
INDCO, Inc.
4040 Earnings Way
New Albany, IN 47150
phone: 812-941-5954
whether
fax:
web:
M-M-30118 mixer manual HS-5
HS-5 SERIES
DISPERSER
.
.
.
.
.
.
.
.
812-944-9742
www.indco.com
date: 3/8/05
Page
.
.
.
.
.
.
.
.
.
.
.
.
.
.
page 1 of 11
3
4
5
6
10

Advertisement

loading
Need help?

Need help?

Do you have a question about the HS-5 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for INDCO HS-5 Series

  • Page 1 This warranty is exclusive and New Albany, IN 47150 is in lieu of all other warranties, whether phone: 812-941-5954 express or implied. INDCO shall not be liable other damages, whether fax: 812-944-9742...
  • Page 2 Dispersers - Variable Speed Electric Model: Serial No.: Date: Order No.: INDCO, Inc. M-M-30118 mixer manual HS-5 date: 3/8/05 page 2 of 11...

  • Page 3: Installation

    General Please follow the below safety precautions. Read this The HS-5 series 5-horsepower electric powered high-speed complete manual before trying to operate your mixer. dispersers are designed for small production batches. Failure to follow these instructions could result in serious bodily injury or death.

  • Page 4: Operation

    For best results always stop and start the disperser in the lowest variable speed hand-wheel setting. NOTE: DO NOT TURN THE HAND-WHEEL KNOB WHEN THE DISPERSER IS NOT RUNNING ! blade bolt INDCO, Inc. M-M-30118 mixer manual HS-5 date: 3/8/05 page 4 of 11...

  • Page 5: Maintenance

    • Use Loctite on set screws where necessary to prevent screws from backing out due to vibration in machine. blade bolt INDCO, Inc. M-M-30118 mixer manual HS-5 date: 3/8/05 page 5 of 11...

  • Page 6: Electrical Connections

    & conditions. Most locations as indicated by Underwriters’ label on motor. INDCO EP motors are Class I, Group D & Class II, Group F & G Consult UL, NEC and local codes for guidance.
  • Page 7 Temperature Limits - Insulation Classification Below are the temperature limits for some electric motors. Most INDCO mixers have insulation class ‘B’ and some have class ‘F’ ratings. Class Maximum Ambient Maximum Heat Rise Maximum Operating Temperature 104°F...
  • Page 8 3. Motor’s internal starter switch or capacitor could be defective. (A 3. Motor cannot be repaired by the user or by INDCO. tip here is that when turned on, the motor hums but does not turn. Replace motor with a new one.
  • Page 9 2. If motor is older, and motor is AC, then it is probably worn out or 2. Replace motor. NOTE: INDCO cannot rebuild elec- in need of rebuilding. tric motors, although it can be done. If customer wants to pursue this, they can check their local Yellow Pages under “Electric Motor Repair”...
  • Page 10 Parts List, HS-5 Series lift control valve INDCO, Inc. M-M-30118 mixer manual HS-5 date: 3/8/05 page 10 of 11...
  • Page 11 Parts List, HS-5 Series Item Description Part No. Qty. ELECTRIC MOTOR 100. 5 HP, fixed speed, TEFC - 230/460VAC - 3-phase MTR-5-BIGF-3-TEFC 100. 5 HP, fixed speed, Explosion-Proof - 230/460VAC - 3-phase MTR-5-BIGF-3-EP 100. 5 HP, AC Inverter-Duty, TEFC, 230/460VAC - 3-phase MTR-5-INV-184TC-TEFC 101.
