Summary of Contents for PhonicEar 330T
- Page 1 All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:52 PM Page 2 330T Transmitter 216MHz user guide...
-
Page 2: Table Of Contents
....21 wearing 330T ..... .9 product warranty . -
Page 3: 330T Transmitter Features
All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:52 PM Page 7 330T transmitter features front back... - Page 4 All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:52 PM Page 8 side channel number label belt clip serial number/part number/operating band battery compartment mute button ( off) charging input jack (1.3mm) on/off, low battery and charging indicator light auxiliary input jack (3.5mm)
-
Page 5: 330T Available Accessories
All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:52 PM Page 9 330T available accessories... - Page 6 8/17/04 3:52 PM Page 10 330T carrying case aux-in adaptor cord* (841-6440-101) (384-01-210-08) 3.5mm - 3.5mm connects 330T to external audio, CD player, stereo, computer, etc. rechargeable NiMH AAA batteries (374-30-310-09) aux-in adaptor cord* (300-6332-107) elastic belt 3.5mm - dual RCA connects 330T to external...
-
Page 7: 330T Setup And Operation
(or alkaline batteries) and replace door. Check polarity markings to confirm batteries are positioned correctly. NOTE: The 330T uses high performance NiMH (nickel-metal hydride) batteries. To achieve maximum battery efficiency, charge batteries for 12 hours before initial use. Charge batteries nightly for 12 hours... -
Page 8: Charging Batteries Using 230R
3:52 PM Page 12 ™ charging batteries using 230R EasyListener 2 sound field system Do NOT attempt to charge alkaline batteries in the 330T. Only Phonic Ear rechargeable batteries can be recharged. Push power button to turn 230R receiver off. - Page 9 Page 13 ™ charging batteries using 230R EasyListener 2 sound field system Do NOT attempt to charge alkaline batteries in the 330T. Only Phonic Ear rechargeable batteries can be recharged. Plug any end of 300-6497-105 charge cord (included with 230R...
-
Page 10: Charging Batteries Using Wall Charger
8/17/04 3:52 PM Page 14 charging batteries using wall charger Do NOT attempt to charge alkaline batteries in the 330T. Only Phonic Ear rechargeable batteries can be recharged. Switch 330T power to off (chg) position. Plug either end of AT0749 charging... -
Page 11: Wearing 330T
All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:52 PM Page 15 wearing 330T Clip to elastic belt (AT0712), pocket, pants or clothes. AT0712 Attach transmitter to necklace-style lavalier cord (AT0512-BK). AT0512-BK... -
Page 12: 330T Microphone Options
All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:52 PM Page 16 330T microphone options * Lapel style microphones are less resistant to feedback when used with a sound field system. AT0291-L* AT0655 AT0814 AT0816... -
Page 13: Plugging In Microphone And Using
Plug microphone into jack on 330T unit. The microphone cord also acts as the antenna for the 330T. To ensure a consistent transmis- sion, keep the microphone cord as straight as possible. Position microphone approximately 3in/7.6cm from mouth. -
Page 14: Turning On 330T
All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:52 PM Page 18 turning on 330T Push power switch up to turn transmitter power on. Confirm red indicator light is on. indicator light features: = Dim red light... -
Page 15: Verifying Channel Setting
ADIUM PRITE the same channel. ISTENER 230R NOTE: The 330T is available on 19 chan- 330T (back) nels in the 216MHz frequency. See the chart on pages 19 & 20 for a complete list of frequencies and corresponding Phonic Ear channel numbers. -
Page 16: Connecting Cd, Tv And Other Audio Sources
300-6332-107 keep the microphone cord as straight (3.5mm – dual RCA) as possible.) Using appropriate auxiliary input cord, connect the 330T to the secondary sound source. NOTE: Check the type of connection need- 384-01-210-08 (3.5mm – 3.5mm) ed for the secondary sound source – refer to page 4 for available aux-in adaptor cord specs and usage descriptions. -
Page 17: Troubleshooting
• verify the mute switch on the top of the unit • verify only Phonic Ear NiMH batteries are is in the off (up) position. being charged. 330T unit will not charge dis- posable alkaline or other rechargeable batteries. • verify the transmitter is operating on the same FM channel as the receiver •... - Page 18 (AT0655, AT0814, AT0816, AT0291-L, • make sure the user microphone is not too AT0668-L) close to external speakers in the room • make sure an omni-directional mic is not being used. Omni-directional mics should not be used with the 330T.
-
Page 19: Caring For Your 330T
Clean with a soft damp cloth and remove the batteries from the transmitter. Place the unit into the 841-6440-101 carrying case. other important notes • Protect your 330T transmitter from excessive moisture, heat, and mechanical shocks. • The AT0749 wall transformer may get warm under normal operation. -
Page 20: Product Specifications
All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:53 PM Page 24 product specifications transmitter: 330T transmitting 216MHz, Crystal Controlled (U.S./Canada) frequency modulation FM narrow-band operating range up to 50m/160ft user controls off/on; push button mute switch inputs/outputs 3.5mm auxiliary input jack... -
Page 21: Frequencies And Corresponding Phonic Ear Channel Numbers
All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:53 PM Page 25 frequencies and corresponding Phonic Ear channel numbers EasyListener 2 Lexis receiver frequency channel 330T Radium Sprite 230R • 216.0125 • 216.2125 • 216.2875 •... - Page 22 All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:53 PM Page 26 frequencies and corresponding Phonic Ear channel numbers (cont’d) EasyListener 2 Lexis receiver frequency channel 330T Radium Sprite 230R • • • • •...
-
Page 23: Battery Warnings
All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:53 PM Page 27 battery warnings Caution • Remove all batteries when replacing. • Do not mix new and used batteries. • Do not mix alkaline and rechargeable batteries. -
Page 24: Product Warranty
1. Malfunctions resulting from abuse, neglect as the instrument remains the property of or accident. the original owner. The 330T transmitter has a 2. Instruments connected, installed, used or adjusted 3-year limited warranty. in any manner contrary to instructions provided by the manufacturer. - Page 25 All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:53 PM Page 29 warranty (cont’d) Phonic Ear Inc. reserves the right to make changes in what to do if you need service the design or construction of any of its instruments at...
- Page 26 NiCad 10-7475 Kimbel Street rechargeable batteries or alkaline disposable batteries Mississauga, Ontario in the 330T. Only NiMH batteries supplied by L5S 1E7 Canada Phonic Ear should be charged in the 330T. what to do if you have questions...
-
Page 27: Code Of Federal Regulations
All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:53 PM Page 31 code of federal regulations (United States only) transmitter IMPORTANT NOTE: To comply with FCC RF This transmitter is authorized by rule under the Low exposure compliance requirements, only use sup- Power Radio Service (47 C.F.R. -
Page 28: Regulatory Approvals
All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:53 PM Page 32 regulatory approvals The term "IC:" before the radio certification num- EasyListener 2 Transmitter 330T ber only signifies that Industry of Canada technical specifications were met. - Page 29 All manuals and user guides at all-guides.com 4075 330T Trans User Guide 8/17/04 3:52 PM Page 1 u.s.a. 800.227.0735, then press 5 • canada 800.263.8700 • international +45 3917 7101 © 2004 Phonic Ear Inc. Phonic Ear and the names of Phonic Ear products are trademarks or registered trademarks of Phonic Ear Inc.
