SPECIFICATION:
PATTERN: Cardioid (NORM) / Supercardioid (TELE)
FREQUENCY RANGE: 20 -20KHz
SENSITIVITY: Cardioid -46dB (0dB=1V/Pa@1KHz)
Supercardioid -36dB (0dB=1V/Pa@1KHz)
LOW CUT FILTER: -5dB @300Hz
OUTPUT IMPEDANCE: 1.5K ohm at high level
600 ohm at low level
POWER REQUIREMENT: 1AA battery
BATTERY LIFE: approx.100 hours
OUTPUT CONNECTOR: 3.5mm stereo plug
MIC INPUT: 3.5mm stereo plug
CABLE: 90cm
DIMENSION(WITH SHOCK MOUNT) (Lx WxH): 14.4 x 3.2 x 6.7 cm
WEIGHT(WITH BATTERY): 113.4g
AMERICAN RECORDER TECHNOLOGIES, INC.
www.AmericanRecorder.com
1872 Angus Ave.
Simi Valley, CA 93063 - USA
805-527-9580 - 808-527-1433(fax)
info@AmericanRecorder.com
PHO-MIC-0286
SUPER CARDIOID VIDEO MICROPHONE
THANK YOU FOR CHOOSING EM-286 VIDEO MICROPHONE
PHO-MIC-0286 is a super-cardioid condenser microphone for DSLR
camer, video recorder and phones/tablets with proper adapter cable.
The Mic-in jack allows plugging in an additional microphone or
background music, to work with this condenser microphone as
separate L and R channel outputs to camera or video recorder, and an
earphone jack for monitoring during recording.
The special designed shock mount to minimize vibrations from the
camera or motion noise from a boom pole. The shock mount adapter fits
any shoe-mount attachment, and the 1/4"-20 threaded socket fits most
boom poles.
USER MANUAL
Advertisement
Table of Contents
Summary of Contents for American Recorder PHO-MIC-0286
- Page 1 DIMENSION(WITH SHOCK MOUNT) (Lx WxH): 14.4 x 3.2 x 6.7 cm WEIGHT(WITH BATTERY): 113.4g THANK YOU FOR CHOOSING EM-286 VIDEO MICROPHONE PHO-MIC-0286 is a super-cardioid condenser microphone for DSLR camer, video recorder and phones/tablets with proper adapter cable. The Mic-in jack allows plugging in an additional microphone or AMERICAN RECORDER TECHNOLOGIES, INC.
- Page 2 Functions: 1. Power ON/LOW CUT Filter/OFF 2. Gain level switch (0 dB, +10dB) 3. Polar pattern selector 4. Mic input jack 5. Headphone jack 2. 3. 6. Shock mount 7. Locking wheel 8. Mounting foot with 1/4"-20 threaded socket 9. Battery compartment 10.
