Summary of Contents for Positive Grid Spark 40
- Page 1 Spark 40 Footswitch Mod...
-
Page 2: Bill Of Materials
Bill of Materials MODZ You need this… Randall RF4G3 ($50-$70) ▪ General Tools search on ebay ▪ Wire Stripper ▪ Soldering Iron Pack of 5 Momentary switches ▪ Solder (you only need 4 for this mod) ▪ 3/4” Hole punch ▪... - Page 3 MODZ PHASE 1 PHASE 2 PHASE 3 PHASE 4 FOOTSWITCH CABINET TEST...
- Page 4 The Footswitch MODZ Strip all the components from the Punch 3/4” hole on either side for Take one of your 3ft or 10ft Randall footswitch. Sand and paint the panel mount RJ45 connector. network cables and cut it in half. whatever color..
- Page 5 The Footswitch MODZ Prep all your momentary foot Populate your newly painted Strip jacket 8”, tin & solder each pair to switches with lock-tight. footswitch with the switches. each switch, install strain relief. It shows the old switches with L Solder connections: Blu/bluwht for 1, Org/orgwht for 2, Grn/Grnwht for 3, Brn/Brnwht for 4...
- Page 6 The Cabinet MODZ Remove the right speaker Choose your location on the back Now use the backplate as your plate and trim the coating just over template and trace your cabinet thru- ¾” so that when you use your hole on the back of the cabinet. paddle bit you don’t tear up the Place back plate aside.
- Page 7 The Cabinet MODZ Just to the left of the speaker cable With the backplate removed use Carefully remove the circuit pass-thru drill a ½” hole into the a 1-1/2” paddle bit to open the board. Be mindful of the pass-thru hole for the RJ-45 Bluetooth cable and speaker lower cavity.
- Page 8 The Cabinet MODZ Remove the back panel again Connect the other half of With the connector and and remove the circuit board, the network cable that you cable installed, test fit the disconnect the cable from RJ45 cut in half and feed it thru back panel.
- Page 9 The Amp MODZ The Test Pin 1 – Color w/white stipe Looking down with the back of the amp facing you, carefully position and secure Pin 2 – Solid Color the circuit board. Strip the jacket 8” off the routed network cable and solder the assigned pairs to the appropriate contacts.
- Page 10 The Test MODZ To completely test the crcuit , With a Digital Multimeter set to To serve as strain-relief, zip tie the connect pedal with the other Ohms, put you leads on pins 1 pairs, and take 4” piece of electrical 12’...
- Page 11 The Test MODZ Re-assemble amp. Time to rock! Make sure to connect the And now you can change speaker connector before you presets with your foot! Whoa! re-install the circuit board.
-
Page 12: You're Done
MODZ You’re done! If you want me do it click here...
