Summary of Contents for Ocean Super Match II
- Page 1 Owner’s Manual Super Match II NOTICE The Operator of this equipment is responsible for maintaining customer safety at all time. Details set forth in this document must be followed at all times.
- Page 2 SAFETY WARNING In order to use this game safely, be sure to read this Operator’s Manual thoroughly before installation, adjustment or use of this game. Whenever the owner of this game or his authorized representative disassembles, install, adjusts, repairs or performs periodic maintenance on this game, the owner should ensure that the person performing the work has read the appropriate precautions and the relevant section of this manual prior starting work.
- Page 3 Preface 1.Ocean Profile Thank you for Choosing our company.Ocean Amusement Machine Co.,Ltd. was found in 2007,located at Zhongshan,Guangdong.Over these years,we build a high-quality,high efficiency,high technology team via all my colleagues power,cooperate with absolute sincerity and work hard. We provide you with highest quality and the most professional service around design, development ,production , sales,after-service,every steps and every details.
-
Page 4: Table Of Contents
CONTENTS ..............P5 一、 Specifications&Requirement （1） Specifications （2） Requirements Package Contents Installation and Setting Location ,Fixed and Movement Connecting the power cord 二 、 Operation Manual ...................P8 Test and set Insert Coin Score/Ticket Bonus Score selection Mercy Tickets Setting of Game Mode... -
Page 5: 一、Specifications&Requirement
一、Specifications&Requirement 1.Specification Parameter (1)Rated power supply： AC220V±10% 50Hz or AC 110V±10% 60Hz; (Note: As the actual voltage, please refer the label of the machine.) (2)Power Consumption： Min power consumption: 150W Max power consumption: 150W (3)Dimensions： W787×D1120×H2355(mm) (4)Weight: 153kg (5)Environment Condition: Temperature(indoor): -10℃～+40℃... -
Page 6: Package Contents
2.Requirements (1)Package Contents ● Make sure that all the parts shown below are included in product package. ● If any parts are missing, contact your distributor. Country of Name Specification Unit Remark Origin 《Super Match W777×D1118×H2350( Ocean unit II》... - Page 7 Even indoors, avoid to install in places mentioned below so as not to cause a fire, electric shock, injury and or malfunctioning. Places subject to rain or water leakage, or places subject to high humidity in the proximity of an indoor swimming pool and or shower, etc.
-
Page 8: 二 、 Operation Manual
To fix the game, adjust the Leveler down until it touches the floor, lifting the casters off the ground by 5 mm. Repeat the same for all levelers. To move the game, adjust the leveler up to keep a distance 20mm from the floor. In order to avoid the damage while moving the game, when the caster touches the floor, move the game from its left or right side step by step. - Page 9 2)Press the "SERVICE" button 1 time, Seg display "t02" 1 second, stop at "22222xxx/22222xxx",Test the status of DIP1-3 that display on Seg1-3; 3)Press the "SERVICE" button 1 time, 7_Seg display "t03" 1 second, stop at "3333xxxx/3333xxxx", (Test INPUT), the input which is on will be display at <1>1-2,<1>3-4,<2>1-2,<2>3-4 4) Press the "SERVICE"...
- Page 10 (1)Insert Coins The adjustment of DIP switch ① Coins/Credit: Adjust it to set the how many tokens per credit. There are 4 options for user to select. It controlled by SW11~SW12. SW1-DIP Adjustment Item Content Remark SW11 SW12 1 coin/credit...
- Page 11 ④ Scores Selection: SW2-DIP Adjustment Remark Item Content SW21 SW22 SW23 Follow the Scores Scores Selection Selection ⑤ Bonus Scores Cumulation per Coin Adjust it to set the Bonus Scores .There are 6 options for user to select. It controlled by SW24~SW26 .
- Page 12 ⑦Game Multiple Superposition : SW3-DIP Adjustment Item Content Remark SW31 SW32 SW33 Game Selection of Scores Multiple Multiple Superposition ⑧ Whether X Multiples of Bonus or not: SW2-DIP Adjustment Item Content Remark SW34 Whether X Multiples of Bonus or ⑨Turntable Speed...
- Page 13 200(Bonus) 200(Bonus) 200(Bonus) 21pcs 200(Bonus) tickets 200(Bonus) 200(Bonus) 200(Bonus) 22 pcs 200(Bonus) tickets 200(Bonus) 200(Bonus) 1000(Bonus) 73 pcs 1000(Bonus) tickets 1000(Bonus) 1000(Bonus) 200(Bonus) 25 pcs 200(Bonus) tickets 200(Bonus) 200(Bonus) 200(Bonus) 28 pcs 200(Bonus) tickets VIII 200(Bonus) 200(Bonus) 2. Instruction for Ticket Dispenser Adjustment on meter ASSY ①Ticket Counter: Record how many tickets have payout.
-
Page 14: 三 、 Maintenance And Troubleshooting
Maintenance and Troubleshooting 三 、 1.Common faults and Troubleshooting PROBLE PROBABLE CAUSE SOLUTION 1.Check AC and 220V/110V Supply 1.No power Power is normal 2.Check AC and 12V&24V&5V GND is 2.Fault of power supply The game short circuit 3.Fault of Power Switch can’t start... - Page 15 ②Check to be sure that all of the game harnessing is plugged in properly and that all of the pins are firmly seated in the connectors. It is always possible that a harness can be damaged by rough shipping or moving.
-
Page 16: 四、Attachment&Picture
四、Attachment&Picture 48PCS of Output 1.Chartlet of Circuit Board Digital Tube Music IC Adjustment Input CPU chip Amplifier Volume Control Super MatchⅡ... - Page 17 Super MatchⅡ...
-
Page 18: Picture
2.Picture Specific Item No. Name Material Unit ation Back Cover of White double HYDTⅡ-03-02M δ15 LED Box Fiber Board Back Door of White double HYDTⅡ-03-03M δ15 LED Box Fiber Board Back Cover of White double HYDTⅡ-02-38M δ15 Cabinet Fiber Board Magnet HYDTⅡ-02-15B... - Page 19 OCEAN OCEAN AMUSEMENT MACHINE Co.,Ltd. Tel: +86-760-88661950 Fax: +86-760-88661960 www.zs-Ocean.com Super MatchⅡ...
