Home Entertainment System
HT-E6730W_ZA_0417-1(D2D).indd 1
HT-E6730W_ZA_0417-1(D2D).indd 1
7.1CH Blu-ray™
user manual
imagine
the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/register
HT-E6730W
2012-04-17 오후 7:04:28
2012-04-17 오후 7:04:28
Advertisement
Table of Contents
Related Manuals for Samsung HT-E6730W
Summary of Contents for Samsung HT-E6730W
- Page 1 7.1CH Blu-ray™ Home Entertainment System imagine Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register HT-E6730W_ZA_0417-1(D2D).indd 1 HT-E6730W_ZA_0417-1(D2D).indd 1 user manual the possibilities HT-E6730W 2012-04-17 오후 7:04:28 2012-04-17 오후 7:04:28...
-
Page 2: Warning
Safety Information Warning TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lighting flash and Arrowhead within the triangle is a warning sign alerting you of dangerous voltage inside the product. -
Page 3: Precautions
Precautions Important Safety Instructions Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference. 1 . Read these instructions. 2 . Keep these instructions. 3 . Heed all warnings. 4 . -
Page 4: Using The 3D Function
Blu-ray Disc Association. Copyright © 2012 Samsung Electronics Co.,Ltd. All rights reserved; No part or whole of this user’s manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd. 2012-04-17 오후 7:04:50 2012-04-17 오후 7:04:50... -
Page 5: License
License • Dolby and the double-D symbol are registered trademarks of Dolby Laboratories. • Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535; 7,392,195; 7,272,567; 7,333,929; 7,212,872 & other U.S. and worldwide patents issued & pending. DTS-HD, the Symbol, & DTS- HD and the Symbol together are registered trademarks &... -
Page 6: Table Of Contents
Contents SAFETY INFORMATION Warning Precautions Disc Storage & Management Handling Cautions Using the 3D Function Copyright License GETTING STARTED Disk and Format Compatibility Logos of Discs the product can play Accessories Front Panel Rear Panel Remote Control CONNECTIONS Attaching the Toroidal Ferrite Core to the Power Cord of the Main Unit Connecting the Speakers Speaker Components... -
Page 7: Getting Started
Please note that this is not a defect in the product. \ Samsung cannot guarantee that this product will play every disc bearing the Blu-ray Disc, DVD or CD logo because disc formats evolve, and problems and errors may occur during the creation of Blu-ray Disc, DVD, and CD software and/or the manufacture of discs. -
Page 8: Logos Of Discs The Product Can Play
Getting Started Region Code Both products and discs are coded by region. These regional codes must match for a disc to play. If the codes do not match, the disc will not play. The Region Number for this product is displayed on the rear panel of the product. - Page 9 Video File Support File Extension Container *.avi *.mkv *.asf *.wmv WMV (wmv9) *.mp4 *.3gp 3GPP *.vro *.mpg *.mpeg *.ts *.tp *.trp Limitations - Even when a file is encoded by a supported codec listed above, the file might not be played if its content has a problem.
- Page 10 Press the HOME button to move to the home menu, press the YELLOW (C) button, and then press the E button. • SAMSUNG is not responsible for any data file damage or data loss. AVCHD (Advanced Video Codec High Definition) •...
-
Page 11: Accessories
NOTE \ Some AVCHD format discs may not play, depending on the recording conditions. \ AVCHD format discs need to be finalized. \ “x.v.Color” offers a wider color range than normal DVD camcorder discs. \ Some MKV and MP4 format discs may not play, depending on their video resolution and frame rate. Accessories Check for the supplied accessories below. -
Page 12: Front Panel
Getting Started Front Panel DISC TRAY POWER NOTE \ If Cellular phone or mobile device is near vacuum tube amp, or put other electronic products on the top of the product would cause noise from the audio. \ Please be careful that children do not touch the product's surface When the set is on working. It would be hot. \ To upgrade the product's software through the USB Host jack, you must use a USB memory stick. -
Page 13: Remote Control
Remote Control Tour of the Remote Control Turn the product on and off. To change to TV mode, press the TV button. To change to Home Theater, press the BD button. Press numeric buttons to operate options. Press to view the disc menu. Press to skip backwards or forwards. -
Page 14: Installing Batteries In The Remote Control
NOTE \ The remote control may not work on some brands of TV's. Also, some operations may not be possible, depending on your brand of TV. \ The remote control will work with Samsung TVs by default. English HT-E6730W_ZA_0417-1(D2D).indd 14 HT-E6730W_ZA_0417-1(D2D).indd 14... -
Page 15: Connections
Connections This section describes various methods of connecting the product to other external components. Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Attaching the Toroidal Ferrite Core to the Power Cord of the Main Unit If you attach a Toroidal ferrite core to the power cord of the main unit, it will help to prevent RF interference from radio signals. -
Page 16: Stand
Connections Speaker Components SCREW (5 STAND BASE STAND CENTER FRONT/FRONT TOP SURROUND Installing the Speakers on the Tallboy Stand 1. Straighten the speaker cable and put it into the hole on the Stand Base. 2. Turn the Stand Base upside-down and connect it to the Stand. - Page 17 Connecting The Speakers 1. Match each speaker cable bundle to the correct speaker by matching the color coded plug on each bundle to the colored sticker on the bottom of each speaker. 2. To attach speaker wire to each speaker: a.
-
Page 18: Connecting The Fm Antenna
Connections CAUTION \ If you want to install the product on the wall, fasten the screws or nails on the wall firmly and use the holes on the rear of speaker to install. However, when you install it, accessories (nails or screws) and installation is not provided by the company. \ Do not let children play with or near the speakers. -
Page 19: Connecting To An Ipod/Iphone
Connecting to an iPod/iPhone Using a USB Cable Connect an iPod/iPhone using the USB cable to the front USB port. Using a Dock To view a video from your iPod on your TV, you must also connect the VIDEO OUT jack on the product to the VIDEO IN jack on your TV. -
Page 20: Method 1
Connections Connecting to a TV Select either Method 1 or Method 2. • If you have set the product's remote control to operate your TV, press the TV SOURCE button on the remote control, and then select the source the product is connected to (HDMI, Video In, etc.) to view video from the home theater. SPEAKERS OUT CENTER FRONT... -
Page 21: An External Component With An Hdmi Cable
Connecting to External Devices To select the correct mode for an external device, press the FUNCTION button. Each time you press the button, the mode changes in this order : BD/DVD White SPEAKERS OUT CENTER FRONT FRONT TOP SUBWOOFER FRONT FRONT TOP SPEAKER IMPEDANCE : 3 iPod... -
Page 22: Connecting To A Network Router
Router Broadband modem NOTE \ Internet access to Samsung’s Software Update server may not be allowed, depending on the router you use or your ISP’s policy. For more information, contact your ISP (Internet Service Provider). \ DSL users, please use a router to make a network connection. -
Page 23: Settings
Settings The Initial Settings Procedure • The Home menu will not appear if you do not configure the initial settings. • The OSD (On Screen Display) may change in this product after you upgrade the software version. • The access steps may differ depending on the menu you selected. - Page 24 Settings Initial Settings > Network Settings (4/5) Enter security key. 0 entered Space 8 . Enter your network's security key. When done, use the ▲▼◄► buttons to select Next, and then press the E button. NOTE \ Enter numbers by pressing the number buttons on your remote.
-
Page 25: The Home Screen
Reset option. (See page 31) \ If you use an HDMI cable to connect the product to an Anynet+ (HDMI-CEC)-compliant Samsung TV and 1.) You have set the Anynet+ (HDMI-CEC) feature to ON in both the TV and the product and 2.) You have set the TV to a language supported by the product, the product will select that language as the preferred language automatically. -
Page 26: Accessing The Settings Screen
Settings Accessing the Settings Screen 1 . Select Settings on the Home screen, and then press E . The Settings screen appears. 3D Settings Display TV Aspect Ratio Smart Hub Screen Size Audio BD Wise Network Resolution Movie Frame (24Fs) System HDMI Color Format HDMI Deep Color... -
Page 27: Settings Menu Functions
Lets you select the optimal size for the Smart Hub Screen. BD Wise is Samsung’s latest inter-connectivity feature. When you connect a Samsung product and a Samsung TV with BD Wise to each other via HDMI, and BD Wise is on in both the product and TV, the product outputs video at the video resolution and frame rate of the Blu-ray/DVD Disc. - Page 28 Settings Audio Speaker Settings Auto Sound Calibration Equalizer Smart Volume Speaker Selection Audio Return Channel Digital Output Dynamic Range Control Audio Sync English HT-E6730W_ZA_0417-1(D2D).indd 28 HT-E6730W_ZA_0417-1(D2D).indd 28 You can set the speaker options. The product automatically creates a sound field optimized for your environment.
- Page 29 Network Network Settings Network Status Wi-Fi Direct Soft AP AllShare Settings Device Name BD-Live Settings HT-E6730W_ZA_0417-1(D2D).indd 29 HT-E6730W_ZA_0417-1(D2D).indd 29 For more information about Network Settings and network functions, see "Networks and the Internet" starting on page Lets you check whether a connection to the network and the Internet have been established.
- Page 30 Anynet+ is a convenient function that offers linked operations with other Samsung products that have the Anynet+ feature and lets you control those products with one Samsung TV remote. To operate this function, you must connect this product to an Anynet+ Samsung TV using an HDMI cable.
- Page 31 For more information about the Software Update function, see "Upgrading Software" on page 37. Provides contact information for assistance with your product. When activated, lets Samsung Call Center agents diagnose and fix problems with the product remotely. Requires an active Internet connection. Remote Management service might not be available in some countries.
-
Page 32: Auto Sound Calibration
Settings Auto Sound Calibration By running the Auto Sound Calibration (ASC) function just once when you relocate or install the product, you can have the product automatically recognize the distance between speakers, levels between channels, and frequency characteristics to create a 7.1-channel sound field optimized for your environment. - Page 33 Wired - Manual If you have a static IP address or the Automatic procedure does not work, you'll need to set the Network Settings values manually. After following Steps 1 to 3 above: 1 . Select Start in the Network Settings screen, and then press the E button.
- Page 34 Settings Wireless (General) - Automatic After following Steps 1 to 3 in "Configuring Your Network Connection" on page 32: 1 . Select Start in the Network Settings screen, and then press the E button. The product searches for and then displays a list of the available networks.
- Page 35 11 . Select the IP Mode field, and then set it to Manual. 12 . Use the number keypad on your remote to enter the Network values. Use the ▲▼◄► buttons on the remote to move from entry field to entry field. NOTE \ You can get these values from your Internet provider.
-
Page 36: Allshare Settings
Settings 3 . The Connecting pop-up appears, followed by the Connected pop-up. When it closes, you should see the device listed on the Wi-Fi Direct screen as connected. Through the Product Using PBC 1 . Select the Wi-Fi Direct device you want to connect to this product, and then press the E button. -
Page 37: Upgrading Software
\ The upgrade is complete when the product turns off, and then turns on again by itself. \ Samsung Electronics takes no legal responsibility for product malfunction caused by an unstable Internet connection or consumer negligence during a Software Update. - Page 38 Settings By Disc 1 . Visit www.samsung.com. 2 . Click SUPPORT on the top right of the page. 3 . Enter the product's model number into the search field, and then click Find Product. 4 . Click Get downloads in the center of the page below the Downloads header.
-
Page 39: Media Play
Media Play Your Blu-ray product can play Disc and USB contents and the contents located on your PC, DLNA compatible mobile phone, or NAS using the AllShare Play function. For more information about AllShare Play, refer to page 42. The AllShare Play Screen To access the AllShare Play screen, select the AllShare Play icon on the Main screen, and then press the E button. -
Page 40: Playing Files On A Usb Storage Device Or Ipod/Iphone
Media Play Playing Files on a USB Storage Device or iPod/iPhone You can play multimedia files located on a connected USB device. 1 . With the product turned off, connect a USB storage device or an iPod/iPhone. 2 . Turn on the product. When the Main screen appears, select AllShare Play >... -
Page 41: The Function Screen
The Function Screen On the Function Screen, you can select the audio and/or video input source to view or listen to. NOTE \ You can also change sources by pressing the Function button in the upper right of the remote. To access the Function Screen, select the Function icon on the Main screen, and then press the E button. -
Page 42: Content
You can download the PC software and get detailed instructions for using AllShare from the Samsung.com website. 1 . Go to www.samsung.com. 2 . Click Support at the top of the page. 3 . On the Support page, enter the model number of your product into the Model Number field. - Page 43 Product Play back PC's files AllShare Connection (Only available with Samsung phones supporting AllShare functionality.) 1 . Connect the product, your PC, and your DLNA compatible cell phone to the same wireless network. 2 . Follow the directions in the AllShare software Installation/Instruction manual to set up devices and files for playing or viewing.
-
Page 44: Controlling Video Playback
Media Play Controlling Video Playback You can control the playback of video files located on Blu-ray, DVD, and CD discs, and on USB storage devices. Depending on the disc, some of the functions described in this manual may not be available. Buttons on the Remote Control used for Video Playback DISC MENU TITLE MENU... - Page 45 Using the TOOLS Menu During playback, press the TOOLS button. Select to move to a desired title if the disc has more than one title, to a desired scene, or, using Time Search, to a specific point in a movie or video. Title Search With Time Search, you designate Time Search...
-
Page 46: Controlling Music Playback
Media Play Controlling Music Playback You can control the playback of music content located on a DVD, CD, or a USB storage device. Buttons on the Remote Control used for Music Playback DISC MENU TITLE MENU POPUP MUTE Fast Play (Audio CD (CD-DA) only) During playback, press the 3 or 4 button. -
Page 47: Controlling Photo Playback
• Use Select All to select all tracks. This cancels your individual track selections. When you press the RETURN ( ' ) button on your remote or select PLAY and then press the E button, all tracks will appear on the Music Playback screen, and the product will begin to play all tracks from Track 001. -
Page 48: Using The Tools Menu When A File Is Highlighted
Media Play NOTE \ Depending on the disc or storage device, the Tools menu may differ. All options may not be displayed. \ To enable the background music function, the photo file must be in the same storage media as the music file. However, the sound quality can be affected by the bitrate of the MP3 file, the size of the photo, and the encoding method. - Page 49 E button. The Log In/Out function lets you log in Login / Out to your online Samsung account. Select to create a playlist or add files or tracks to a playlist. 1. Select Add to Playlist, and then press the E button.
-
Page 50: Presetting Stations
Media Play Encoding - which changes by language or by geographical area - modifies how the product sorts, arranges, and Encoding presents files or tracks, displays dates, etc. Select Encoding to change the encoding to match your language or geographical area. Displays media file and content Information information. - Page 51 Dolby Pro Logic II Movie Music Game Matrix Prologic Off • Movie : Adds realism to a movie soundtrack. • Music : When listening to music, you can experience sound effects as if you are listening to the actual performance.
-
Page 52: Network Services
For instructions that explain how to use Smart Hub, follow these steps: 1 . Go to www.samsung.com. 2 . Click Support at the top of the page. 3 . On the Support page, enter the model number of your product into the Model Number field. -
Page 53: Using The Web Browser
My Applications : Displays your personal gallery of applications which you can add to, modify, and delete. Samsung Apps : Open Samsung Apps to download various for pay or free-of-charge application services. Using the Web Browser You can access the internet using the Web Browser application which is installed in the Smart Hub screen by default. -
Page 54: Using Disc To Digital
Network Services Navigation Help : Displays the remote control buttons you can use to navigate in Web Browser. • GREEN (B) : To display the Control Panel. • YELLOW (C) : You can change the cursor to Link Browsing mode or Pointer Browsing mode. •... -
Page 55: Additional Information
• If you select 16:9 Original, your TV may display 4:3 Pillarbox (black bars on sides of picture). BD Wise (Samsung Products only) • When BD Wise is on, the Resolution setting automatically defaults to BD Wise and BD Wise appears in the Resolution menu. - Page 56 TV. • This function is not available if the HDMI cable does not support CEC. • If your Samsung TV has an Anynet+ logo, then it supports the Anynet+ function. BD Data Management • In the external memory mode, disc playback may be stopped if you disconnect the USB device in the middle of playback.
- Page 57 Playing Video files • Video files with high bitrates of 20Mbps or more strain the product’s capabilities and may stop playing during playback. Selecting the Audio Language • The ◄► indicator will not appear on the screen if the BONUSVIEW section does not contain any BONUSVIEW audio settings.
- Page 58 Appendix Playing Music • Adjust the volume to a moderate level before you connect your iPod to the product. • When the product is on and you connect an iPod, the product will charge the iPod's battery. Watching a Movie •...
- Page 59 Resolution according to the output mode Blu-ray Disc/E-contents/Digital Contents playback Output Setup Blu-ray Disc Resolution of Blu- BD Wise Max. Resolution of Auto 1080p@60F 1080p@60F Movie Frame : Auto 1080p@24F (24Fs) 1080i 720p 480p 480i DVD playback Output Setup BD Wise Auto 1080p@60F 1080i...
- Page 60 Appendix Digital Output Selection Setup Connection Up to PCM 7.1ch Dolby Digital Up to PCM 7.1ch Dolby Digital Up to PCM 7.1ch Plus Audio Stream Dolby TrueHD Up to PCM 7.1ch on Blu-ray Disc Up to PCM 6.1ch DTS-HD High Resolution Up to PCM 7.1ch Audio...
-
Page 61: Troubleshooting
Refer to the table below when this product does not function properly. If the problem you are experiencing is not listed below or if the instructions below do not help, turn off the product, disconnect the power cord, and contact Samsung Electronics at 1-800-SAMSUNG (1-800-726-7864). Symptom I cannot eject the disc. - Page 62 Appendix Symptom The menu screen does not • Are you using a disc that does not contain menus? appear even when the menu function is selected. • You can play 16:9 Blu-ray/DVD discs in 16:9 Full mode, 4:3 Letter Box mode, or The aspect ratio cannot be changed.
- Page 63 We will provide you with the amount of the administration fee before we make a home visit or begin any work on your product. We recommend you read this manually thoroughly, search for a solution on line at www.samsung. com, or contact Samsung Customer Care at 1-800-SAMSUNG (726-7864) before seeking to repair your product.
-
Page 64: Specifications
Appendix Specifications Power Requirements Power Consumption Weight General Dimensions Operating Temperature Range Operating Humidity Range Signal/noise ratio FM Tuner Usable sensitivity Total harmonic distortion BD (Blu-ray Disc) DVD (Digital Versatile Disc) Disc CD : 5 inches (COMPACT DISC) CD : 3 1/2 inches (COMPACT DISC) Video Output Composite Video Video/Audio... - Page 65 Dimensions (W x H x D) Weights • Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. • Weight and dimensions are approximate. • Design and specifications are subject to change without prior notice. • Dispose unwanted electronics through an approved recycler.
- Page 66 SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG.
