Sharp LC-17SH1E Service Manual

Sharp LC-17SH1E Service Manual

Hide thumbs Also See for LC-17SH1E:
Table of Contents

Advertisement

Quick Links

Download this manual
SERVICING NOTICES ON CHECKING ......................................................................................................................
HOW TO ORDER PARTS ............................................................................................................................................
IMPORTANT .................................................................................................................................................................
ABOUT LEAD FREE SOLDER (PbF) ..........................................................................................................................
GENERAL SPECIFICATIONS .....................................................................................................................................
DISASSEMBLY INSTRUCTIONS ................................................................................................................................
SERVICE MODE LIST .................................................................................................................................................
CONFIRMATION OF HOURS USED ..........................................................................................................................
WHEN REPLACING EEPROM (MEMORY) IC ...........................................................................................................
ELECTRICAL ADJUSTMENTS ....................................................................................................................................
TROUBLESHOOTING GUIDE .....................................................................................................................................
BLOCK DIAGRAMS .....................................................................................................................................................
PRINTED CIRCUIT BOARDS ......................................................................................................................................
SCHEMATIC DIAGRAMS ............................................................................................................................................
WAVEFORMS ..............................................................................................................................................................
EXPLODED VIEW ........................................................................................................................................................
REPLACEMENT PARTS LIST .....................................................................................................................................
SERVICE MANUAL
LCD COLOR TELEVISION
MODEL
In the interests of user-safety (Required safety regulations
in some countries) the set should be restored to its original
condition and only parts identical to those specified be used.
CONTENTS
SHARP CORPORATION
LC-17SH1E
S4512LC-17SH1E
Page
B-1
C-1
C-1
C-2
D-1
E-1
F-1
G-1
H-1
I-1
J-1
K-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-17SH1E and is the answer not in the manual?

Questions and answers

Related Manuals for Sharp LC-17SH1E

Summary of Contents for Sharp LC-17SH1E

  • Page 1: Table Of Contents

    SERVICE MANUAL S4512LC-17SH1E LCD COLOR TELEVISION LC-17SH1E MODEL In the interests of user-safety (Required safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified be used. CONTENTS Page SERVICING NOTICES ON CHECKING ........................

  • Page 2: Servicing Notices On Checking

    SERVICING NOTICES ON CHECKING 1. KEEP THE NOTICES PERFORM A SAFETY CHECK AFTER SERVICING As for the places which need special attentions, they are indicated with the labels or seals on the Confirm that the screws, parts and wiring which cabinet, chassis and parts.

  • Page 3: About Lead Free Solder (Pbf)

    ABOUT LEAD FREE SOLDER (PbF) Distinction of PbF PCB: PCBs (manufactured) using lead free solder will have a PbF printing on the PCB. (Please refer to figures.) Caution: • Pb free solder has a higher melting point than standard solder; Typically the melting point is 50°F~70°F(30°C~40°C) higher.

  • Page 4: General Specifications

    GENERAL SPECIFICATIONS LCD Size / Visual Size 17.1 inch / 434.4mmV System LCD Type Color TFT LCD Number of Pixels 1280(H) x 768(V) View Range Left/Right 88/88 degree Up/Down 88/88 degree Color System Speaker 2 Speaker Position Front Size 1.5 x 2.7 inch Impedance 16 ohm Sound Output...
  • Page 5 GENERAL SPECIFICATIONS On Screen Menu (TV) Display Menu Type Icon Picture Brightness Contrast Colour Tint Sharpness DNR ON/OFF Blue Screen Audio NICAM AUTO/OFF Bass Treble Balance Setup Auto Tuning Manual Tuning Sort (CH Allocation) Backlight Language Position (Vertical Position) 4:3 Mode (Auto 4:3 Default) EXT2 Output (AV2 Output) EXT2 Input (AV2 Input) EXT Colour (AV Colour)
  • Page 6 Timer Back-up (at Power Off Mode) more than G-10 Remote Unit RC-LN Control Glow in Dark Remocon Remocon Format SHARP Format SHARP Custom Code 10000 / 10001 / 01111 Power Source Voltage(D.C) UM size x pcs UM-3 x 2 pcs...
  • Page 7 GENERAL SPECIFICATIONS G-11 Features Auto Shut Off Auto Search Sort (CH Allocation) Channel Lock Just Clock Function Game Position CH Label T'Text Text type Fastext / Toptext Text Language English , French, Swedish, Hungarian Finnish, Turkish, German, Dutch Portuguese, Spanish, Italian, Greek Subtitle Wide (AUTO/4:3/Panorama/FULL/14:9) Position (Picture Scroll)
  • Page 8 Cabinet Front PS 94V0 Non-Decabrom Cabinet Rear PS 94V0 Non-Decabrom Non-Halogen Eyelet G-18 Environment Environmental standard requirement (by buyer) Green procurement of SHARP Pb-free Phase3 (Phase3A) G-19 AC Power Adaptor Provided Accessories Power Requirement 220~240V 50/60Hz Max Power Consumption (Adapter Only)

  • Page 9: Disassembly Instructions

    DISASSEMBLY INSTRUCTIONS REMOVAL AND INSTALLATION OF When IC starts moving back and forth easily after desoldering completely, pickup the corner of the IC using FLAT PACKAGE IC tweezers and remove the IC by moving with the IC desoldering machine. (Refer to Fig. 1-3.) REMOVAL NOTE Put Masking Tape (cotton tape) around the Flat Package...
  • Page 10 DISASSEMBLY INSTRUCTIONS INSTALLATION When bridge-soldering between terminals and/or the soldering amount are not enough, resolder using a Thin- Take care of the polarity of new IC and then install the tip Soldering Iron. (Refer to Fig. 1-8.) new IC fitting on the printed circuit pattern. Then solder each lead on the diagonal positions of IC temporarily.

  • Page 11: Service Mode List

    SERVICE MODE LIST This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily. To enter the Service Mode, press both set key and remote control key for more than 2 seconds. Remocon Key Operations Set Key Reset the user setting items (PICTURE, VOLUME, LANGUAGE and AUDIO) to the initial VOL.
  • Page 12 WHEN REPLACING EEPROM (MEMORY) IC If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1 and 2. Main Micon side EEPROM (IC104) initial setting ADDRESS DATA OEC7127A_063...

  • Page 13: When Replacing Eeprom (Memory) Ic

    WHEN REPLACING EEPROM (MEMORY) IC Table 1-2 Enter DATA SET mode by setting VOLUME to minimum. Press both VOL. DOWN button on the set and Channel button (6) on the remote control for more than 2 seconds. ADDRESS and DATA should appear as FIG 1. ADDRESS is now selected and should "blink".

  • Page 14: Electrical Adjustments

    RGB COLOR CENT damage to the IC and Transistor). BRIGHT CENT RGB COLOR MAX BRIGHT MAX RGB COLOR MIN BRIGHT MIN RGB SHARP CENT 2. BASIC ADJUSTMENTS TINT RGB SHARP MAX SHARP CENTER RGB SHARP MIN On-Screen Display Adjustment SHARP MAX RGB V POSI 50 Hz Set the VOLUME to minimum.
  • Page 15 RGB CONTRAST CENT RGB CONTRAST MAX RGB CONTRAST MIN RGB COLOR CENT RGB COLOR MAX RGB COLOR MIN RGB SHARP CENT RGB SHARP MAX RGB SHARP MIN RGB V POSI 50 Hz RGB V POSI 60 Hz RGB H POSI 50 Hz...
  • Page 16 ELECTRICAL ADJUSTMENTS 3. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE (WIRING CONNECTION) LCD PANEL OPERATION PCB CD2200 J4301 CP7201 J4303 J4302 J4306 J4305 J4304 CP101 CP102 CP802 CP801 SCALER PCB CP4402 CP5003 CD3804 CP3803 TU4401 CP301 J4401 J4402 J3801 SPEAKER AV PCB REMOCON PCB CD2201...

  • Page 17: Troubleshooting Guide

    TROUBLESHOOTING GUIDE (LCD SECTION) POWER DOES NOT TURN ON CHANGE F3801. IS F3801 BROKEN ? IS THERE VOLTAGE CHECK IC3803, AND AT 5V OF 1 PIN OF IC3803 LINE. AT9.5V AND 3 PIN AT5V ? AT STATE OF POWER KEY PUSHING, IS THERE CHECK IC101.
  • Page 18 TROUBLESHOOTING GUIDE THE PICTURE APPEARS, BUT THE AUDIO DOES NOT APPEAR. (AT RF MODE) CONNECT SP301. IS SP301 CONNECTED ? IS THERE SIGNAL ON CHAGE SP301. PINS 1 AND 4 OF CP301 ? IS THERE SIGNAL ON CHECK IC301, IC302 AND PIN 11 OF IC301 AND PERIPHERAL CIRCUIT.
  • Page 19 TROUBLESHOOTING GUIDE THE PICTURE DOES NOT APPEAR (1). CHECK THE CONNECTED OF CP3803 AND THE DOSE BACK LIGHT SHINE ? VOLTAGE OF PINS 6, 7 AND IS CD7201 CONNECTED ? CONNECT CD7201. IS THERE SIGNAL AT PINS 5, 6, 8, 9, 11, 12, 14, CHANGE V2301.
  • Page 20 TROUBLESHOOTING GUIDE THE PICTURE DOES NOT APPEAR (2). IS THERE SIGNAL AT CHANGE IC5001. PIN 31, 33 AND 35 OF IC5001 ? IS CP5003 CONNECTED CONNECT CP5003. AND IS THERE SIGNAL AT PIN 1, 3 AND 5 ? IS THERE SIGNAL CHANGE IC801 AND AT C832, C859 PERIPHERAL CIRCUIT.
  • Page 21 TROUBLESHOOTING GUIDE THE COLOR DOES NOT APPEAR. IS SETTING OF CHANGE THE SETTING OF COLOR NORMAL ? COLOR. IS THE COLOR RECEIVE THE COLOR SIGNAL. SIGNAL RECEIVED ? CHECK IC801 AND PERIPHERAL CIRCUIT.
  • Page 22 TROUBLESHOOTING GUIDE ON SCREEN DISPLAY DOES NOT APPEAR. IS THERE SIGNAL AT CHECK IC101 AND PINS 2, 3, 4 AND 5 OF PERIPHERAL CIRCUIT. IC101 ? IS THERE SIGNAL AT CHECK NR801AND PINS 57, 58, 59 AND 60 PERIPHERAL CIRCUIT. OF IC801 ? CHECK IC801 AND PERIPHERAL CIRCUIT.
  • Page 23 SCALER/LVDS/MICON/ADC/JACK/AV_SW/REGULATOR BLOCK DIAGRAM SYNC COUNT IC8102 TA1383FG X801 54MHz X8101 X8102 DIGITAL 3.579545MHz 500KHz 24bit RGB D-SVB D_CLK, D_EN, CP4302 D_HS, D_VS VGA_R DIGITAL SCALER 24bit RGB LCD PANEL LVDS IC TX OUT0~3+ VGA_G A/D CONVERTER IC801 D_CLK, D_EN, D_HS, D_VS V2301 TX OUT0~3- IC7201...
  • Page 24 AV_SWITCH/TUNER/21PIN/STEREO/SOUND AMP BLOCK DIAGRAM SCART2 OUT CVBS SW SCART2 IC4401 MM1501XNRE J4202 AV SW IC5001 AN15853B-E1 19 V_OUT V1-V SCART2_V_IN V1-Y 11 V5 V1-C SCART2_C_IN V1-L SCART2_A_IN_L VL-R SCART2_A_IN_R SW_A_IN_R SC2_A_OUT_R SW_A_IN_L TU4401 SIDE_CVBS SC2_A_OUT_L SCALER/LVDS/ SW_CVBS SW_CVBS TUNER_V MICON/ADC/ SW_Y JACK/AV_SW/ SW_Y...
  • Page 25 POWER BLOCK DIAGRAM J3801 DC JACK +12V AT+3.3V REG IC3806 PQ070XF01SZH AT+5V REG IC3803 KIA7805API AT+3.3V AT+5V DC-DC Q3814 P.CON+5V AT+5V SWITCHING P.CON+5V POWER_ON_H AT+32V REG DC-DC IC3810 Q3812 LA7995M-TLM 3.8V P.CON+3.8V SWITCHING AV_SWITCH/TUNER/ P.CON+32V 21PIN/STEREO/ AV_SWITCH/TUNER/ SOUND AMP 21PIN/STEREO/ SOUND AMP P.CON+9V REG IC3804...

  • Page 26: Printed Circuit Boards

    PRINTED CIRCUIT BAORDS SCALER (TOP SIDE) SCALER (BOTTOM SIDE) CP7201 C4316 B4301 C4311 B4302 NR7201NR7202 W840 IC3201 IC3202 Q4301 C7204 IC7201 R4317 W842 C7206 D3206 Q4304 C109 C107 R161 R160 NR802 NR803 NR804 NR805 NR806 NR807 R105 R833 C887 R106 C113 B805 B804...
  • Page 27 PRINTED CIRCUIT BAORDS AV/REMOCON/OPERATION (TOP SIDE) CEE070A SW2206 SW2204 SW2203 SW2208 CD2200 SW2209 SW2202 C2205 CEE053A CEE054A CD2201 J3801 C3845 J4401 J4402 C3841 C338 L4405 C4420 C4419 L4412 Q3804 C4431 C5017 R321 C4430 C4433 C4415 C4434 C341 C337 D302 R329 D5001 C3837 L302...
  • Page 28 PRINTED CIRCUIT BAORDS AV/REMOCON/OPERATION (BOTTOM SIDE) CME025A Q3815 Q3813 R302 IC3807 W818 R5025 W822 IC3810 W802 Q5005 Q3806 Q3807 W824 W857 Q3812 R3839 Q3814 R3837 IC3805 IC3809 Q4401 R5023 R314 R5029 Q5006 Q5004 Q307 R5017 W861 Q5007 R4439 R5016 W862 W814 W813 W812...
  • Page 29 AV SWITCH/SIDE JACK SCHEMATIC DIAGRAM (AV PCB) FROM/TO POWER AT+3.3V AT+5V P.CON+9V P.CON+5V FROM TO TUNER/21PIN FROM/TO STEREO/SOUND AMP SC_SW_A_IN_R P.CON+5V SC_SW_A_IN_L SWITCH_CVBS STEREO_RESET C5040 SW_AUDIO_L[PC] SW_AUDIO_R[PC] C5027 C5034 0.01 B 0.01 B Vref C5028 C5037 DVD_Y_OUT HP_OUT_L 0.01 B 0.01 B HP_OUT_R C5012...
  • Page 30 C4401 TUNER/21PIN SCHEMATIC DIAGRAM R4466 FROM/TO POWER R4421 0.1 B RF_AGC MUTE_SW (AV PCB) Q4401 2SC3052 AS(GND) AT+5V R4471 P.CON+32V P.CON+9V C4416 HP_MUTE P.CON+5V 0.1 F R4442 POWER_ON-H C4417 R4429 100P LCDON POWER_FAIL TUNER_VIDEO LIGHT_CTL C4418 LCD-H 31.9 TUNING 100P CH L4416 L4415 47uH0305...
  • Page 31 STEREO/SOUND AMP SCHEMATIC DIAGRAM R329 FROM/TO POWER (AV PCB) R330 SOUND+B 3.3 3W P.CON+5V SOUND_GND W856 C317 W850 1000 L6603 P.CON+8V SOUND AMP 10uH 0305 IC301 LA4901-E R6605 W816 PGND PGND C313 R307 L6601 C306 0.1 F 2.2 1/4W PGND OUT+ FROM/TO AV SWITCH/SIDE JACK 10uH 0305...
  • Page 32 POWER SCHEMATIC DIAGRAM (AV PCB) LEVEL SHIFT Q3813 DTA124EKA SOUND+B_REG LEVEL SHIFT IC3807 BA00BC0WFP R3820 Q3815 DTC124EKA Q3816 2SC3052 FROM/TO STEREO/SOUND AMP P.CON+9V_REG P.CON+12V_SW IC3804 KIA78R09API Q3804 KTA1281_Y SOUND+B 11.8 C3859 P.CON+5V 12.3 AT5V REG 0.47 F 12.1 SOUND_GND IC3803 AT+3.3V_REG 10.9 10ERB20-TA1B2...
  • Page 33 OPERATION/REMOCON/CHOKE COIL SCHEMATIC DIAGRAM (REMOCON PCB) OS2201 RPM7138-SH8 Vout FROM/TO AV SWITCH/SIDE JACK CD2201 (CP5001_1) C3243004 REMOCON IN AT+5V STANDBY LED PCBDA0 CEE053 (OPERATION PCB) FROM/TO JACK CD2200 (CP2200) C3234501 KEY A KEY B ACCESSORY CD3801 AD001 0G138801 1C030046 BT001 R6P(AR)XICI TM101 NTR1283-0100109...
  • Page 34 MICOM SCHEMATIC DIAGRAM PSU_5VD/DSR (SCALER PCB) SCART_AUDIO_SW R136 4.7K R137 C116 4.7K AUDIO_MUTE 220 6.3V EXT_MUTE-H HEADPHONE_IN R141 HP_MUTE EEPROM_SCL Q105 R132 R142 SCART1_SW EEPROM_SDA DTA124EKA R133 SCART2_SW FROM/TO JACK C117 Q101 DTC124EKA CVBS/PC SCART1_Y D108 0.1 F HEADPHONE_IN R151 NC NC NC STEREO_RESET FROM/TO SCALER...
  • Page 35 SCALER SCHEMATIC DIAGRAM (SCALER PCB) FROM/TO TUNER/21PIN CP802 (CP4402) 00_6232_030_006_800+ STANDBY_LED STANDBY LED REMOCON_IN REMOCON IN W880 HP_MUTE FROM/TO MICOM HP_MUTE AUDIO_MUTE AUDIO_MUTE W821 EXT_MUTE-H STANDBY_LED EXT_MUTE REMOCON_IN SCART1_B_IN FROM/TO ADC SCART1_B SCART2_SW SCART1_G_IN DDHS SCART1_G DDVS SCART1_SW DDCK SCART1_R_IN SCART1_Y SCART1_R EXT_MUTE-H...
  • Page 36 ADC SCHEMATIC DIAGRAM (SCALER PCB) FROM/TO MICOM SCL1 SDA1 FROM/TO SCALER DDHS DDVS DDCK DPG7 DPG6 DPG5 C2130 DPG4 GREEN7 DPG3 0.1 B DPG2 C2136 DPG1 NR2101 GREEN6 REF BYPASS 4D03WGJ0101T5E DPG0 0.1 B DPG7 DPG6 GREEN5 DPR7 DPG5 DPR6 DPG4 DPR5 GREEN4...
  • Page 37 LVDS SCHEMATIC DIAGRAM FROM/TO PANEL CP7201 17WLCD A2006WR0-2X10P VDD +12V (SCALER PCB) P.CON+12V VDD +12V LCD_TXOUT0- RXIN0- LCD_TXOUT0+ RXIN0+ LCD_TXOUT1- RXIN1- LCD_TXOUT1+ (17W,20W) LVDS RXIN1+ IC7201 DTC34LM85AL LCD PANEL LCD_TXOUT2- CD7201 W828 RXIN2- D420003A TxIN4 LCD_TXOUT2+ V2301 RXIN2+ LC171W03 TxIN5 TxIN3 LCD_TXCLKOUT- RXCLK IN-...
  • Page 38 JACK SCHEMATIC DIAGRAM (SCALER PCB) HEADPHONE JACK J4301 HSJ0913-01-140 CVBS/PC R4301 (W128) P.CON+3.3V R4307 HEADPHONE_IN PC/YUV Rch SW B4301 IC4301 MM1501XNRE HP_OUT_L C4332 PC_A_IN_R MMZ1608R102CT B4302 Vin1 HP_OUT_R MMZ1608R102CT V.OUT C4333 CVBS_A_IN_R FROM/TO SCALER W890 Vin2 SIDE_CVBS J4306 YELLOW MTJ-032-05A-30-FE SW_AUDIO_R[PC] NLCV32T SW_AUDIO_L[PC]...
  • Page 39 AV_SW SCHEMATIC DIAGRAM (SCALER PCB) SYNC_HD SYNC_VD R8108 L8103 P.CON+5V 47uH NLCV32T C8151 0.1 B R8126 C8149 SCL1 R8124 C8148 SDA1 0.1 B 0.1 B R8114 VGAHS R8112 VGAVS P.CON+9V FROM/TO JACK SW_Y/G VGA-G SW_PB/B VGA-R SW_PR/R VGA-B VGAHS VGAVS VGA-R FROM/TO MICOM C_SYNC...
  • Page 40 REGULATOR SCHEMATIC DIAGRAM (SCALER PCB) FROM/TO POWER CP3201 (CD3804) A2001WV2-11P W900 P.CON+12V P.CON+12V W899 P.CON+9V P.CON+9V W902 FROM/TO ADC P.CON+5V P.CON+5V W901 AT+3.3V AT+3.3V P.CON+3.3V P.CON+3.8V W903 P.CON+5V P.CON+3.8V FROM/TO SCALER B3206 HDMI5V P.CON+3.3V BLM18PG181SN1D AT+5V P.CON+1.8V P.CON+3.3V_REG P.CON+1.8V_REG W904 IC3201 BA00BC0WFP AT+5V IC3202...

  • Page 41: Waveforms

    WAVEFORMS MICON 20µs 5µs 50ns 200mV 500nV 500mV SCALER 20µs 5µs 20µs 500mV 500nV 500mV 20µs 5µs 20µs 500mV 2.0V 500mV 20µs 10µs 20ns 2.0V 500mV 1.0V LVDS 20µs 5µs 10ms 500nV 200mV 100mV The following waveforms were measured at the point of the corresponding NOTE: balloon number in the schematic diagram.
  • Page 42 WAVEFORMS JACK 1.0ms 1.0µs 20µs 1.0V 1.0V 500mV 1.0ms 10ms 1.0ms 1.0V 1.0V 1.0V AV_SW AV SW/SIDE JACK 200ns 100µs 1.0ms 100mV 2.0V 1.0V 1.0ms 1.0µs 100µs 50mV 1.0V 2.0V TUNER/21PIN 1.0ms 5.0µs 20µs 1.0V 1.0V 500mV...
  • Page 43 WAVEFORMS STEREO/SOUND 2.0ms 20µs 2.0V 1.0V 2.0ms 2.0ms 2.0V 500mV 50ns 2.0ms 500mV 500mV 2.0ms 500µs 500mV 5.0V 2.0ms 500µs 5.0V 500mV The following waveforms were measured at the point of the corresponding NOTE: balloon number in the schematic diagram.

  • Page 44: Exploded View

    MECHANICAL EXPLODED VIEW 102D 102E 102B 102C 102F 102A 102G 102I 102H 101J 101F 101F 101K 101K PCBDA0 (REMOCON PCB ASS'Y) 101I 101G 101B 101C 101H 101F 101F 101D 101G 101I 101K 101K 101E 101H 101A...
  • Page 45 MECHANICAL EXPLODED VIEW PCBD20 (AV PCB ASS'Y) 207 206 PCBDS0 (SCALER PCB ASS'Y) PCB270 (OPERATION PCB ASS'Y)
  • Page 46 MECHANICAL EXPLODED VIEW (PACKING DIAGRAM) PACKAGE,TOP ADAPTER BOX AC ADAPTER AC CORD REMOTE CONTROL UNIT BATTERY,MANGAN POLY BAG,INSTRUCTION INSTRUCTION BOOK (E/S) GUARANTEE CARD PACKAGE,TOP CORRECTION SHEET FILM BAG GIFT BOX PACKAGE,BOTTOM PACKAGE,PAD PACKAGE,BOTTOM...

  • Page 47: Replacement Parts List

    MECHANICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION CODE 9JD7A7010110A FRONT CABI ASS'Y 101A 9JD701WPJ1349 CABINET,FRONT 101B 9JD702WPA1181 COVER,HINGE 101C 9JD713WPA0368 GLASS,LED 101D 9JD713WPD0015 PLATE,FRONT 101E 9JD7230007983 POP LABEL 101F 9JD761WSA0167 ANGLE,SPEAKER 101G 9JD800WQ0A048 FELT SHEET 101H 9JD800WQ0A049 FELT SHEET 101I 9JD800WQ0A106 FELT SHEET 101J...
  • Page 48 ELECTRICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION CODE OPERATION PCB ASS'Y *** PCB *** PCB270 9JDA3U401D270B PCB ASS'Y CEE054A *** SWITCHES *** SW2202 9JD0504101T34 SWITCH,TACT EVQ21505R SW2203 9JD0504101T34 SWITCH,TACT EVQ21505R SW2204 9JD0504101T34 SWITCH,TACT EVQ21505R SW2206 9JD0504101T34 SWITCH,TACT EVQ21505R SW2208 9JD0504101T34 SWITCH,TACT...
  • Page 49 REF. NO. PART NO. DESCRIPTION CODE *** ICS *** ! IC301 9JDI03DP901E0 LA4901-E ! IC302 9JDI03DP901E0 LA4901-E ! IC3803 9JDI1KA97805A KIA7805API ! IC3804 9JDI1KA98R09A KIA78R09API IC3805 9JDI1LF010100 AL1010 ! IC3806 9JDI0GA9XF010 PQ070XF01SZH ! IC3807 9JDI07F0C0WF0 BA00BC0WFP-E2 IC3809 9JDI1LF010100 AL1010 ! IC3810 9JDI03D979950 LA7995M-TLM IC4401...
  • Page 50 REF. NO. PART NO. DESCRIPTION CODE *** COILS *** L3808 9JD021404470M COIL 70A 47 UH L4401 9JD021LA6220J COIL L4402 9JD021LA6220J COIL L4403 9JD021LA6220J COIL L4404 9JD021LA6220J COIL L4405 9JD02167F150J COIL L4410 9JD02167F100J COIL L4411 9JD02167F100J COIL L4412 9JD021LA61R5J COIL 1.5 UH L4413 9JD021LA61R5J COIL...
  • Page 51 REF. NO. PART NO. DESCRIPTION CODE *** ICS *** IC101 9JDS3U401DM01 MEMORY DATA OEC7127A IC102 9JDI9UF032290 PST3229NR IC104 9JDS3U401DE01 MEMORY DATA AT24C256N-10SU-2.7 IC801 9JDI56K04A710 R8J66604A71FP IC2101 9JDIFSK0883C0 MST9883C-LF-110 ! IC3201 9JDI07F0C0WF0 BA00BC0WFP-E2 ! IC3202 9JDI07F0C0WF0 BA00BC0WFP-E2 IC4301 9JDI0UF015010 MM1501XNRE IC4302 9JDI0UF015010 MM1501XNRE IC7201...
  • Page 52 REF. NO. PART NO. DESCRIPTION CODE *** CONNECTORS *** CP801 9JD069EVT3030 CONNECTOR PCB SIDE 00_6232_029_006_800+ CP802 9JD069EVU3030 CONNECTOR PCB SIDE 00_6232_030_006_800+ CP2200 9JD069S230629 CONNECTOR PCB SIDE A2001WV2-3P CP3201 9JD069S2B0629 CONNECTOR PCB SIDE A2001WV2-11P CP4302 9JD0694S15017 CONNECTOR PCB SIDE 1-1734344-1 CP7201 9JD069S2K0679 CONNECTOR PCB SIDE A2006WR0-2X10P...
  • Page 53 RESISTOR RC....CARBON RESISTOR CAPACITORS CC....CERAMIC CAPACITOR CE....ALUMI ELECTROLYTIC CAPACITOR CP....POLYESTER CAPACITOR CPP....POLYPROPYLENE CAPACITOR CPL....PLASTIC CAPACITOR CMP....METAL POLYESTER CAPACITOR CMPL....METAL PLASTIC CAPACITOR CMPP....METAL POLYPROPYLENE CAPACITOR K2-6...
  • Page 54 © COPYRIGHT 2005 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic , mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

Table of Contents
