I003975 Genio Smart Wi‐Fi LED Stick Light 6pc
TO ENSURE THE SAFE AND SATISFACTORY OPERATION OF THIS SET PLEASE READ THESE INSTRUCTIONS CAREFULLY AND
FOR ANY QUESTIONS OR TROUBLESHOOTING PLEASE VISIT www.mirabellagenio.net.au/faqs
We recommend that the set be tested prior to being set up in the desired location
SAFETY INFORMATION
• Remove set from the packaging before connecting to power supply.
• Before using or re‐using the set, inspect carefully
• Use only with transformer supplied
• Do not connect set electrically to another set
• Do not use any set which has: – cut, damaged, or frayed wire insulation, cracks in lamp‐holders,
loose connections or exposed wires
The LED bulb is not replaceable
Note: When connecting, please ensure the arrows are aligned with one another
Included in the Kit
x12
Installation
Screws
Link and connect the stick light
It is recommended you connect the stick light according to the ABCD marking. A‐A, B‐B, C‐C D‐D etc, and cover the
end with the rubber end cap.
RETAIN FOR FUTURE REFERENCE
:
Power Adaptor
x 12
Installation clips
Extension cables
x6
x1
Rubber end cap
Advertisement
Table of Contents
Summary of Contents for Genio I003975
- Page 1 I003975 Genio Smart Wi‐Fi LED Stick Light 6pc TO ENSURE THE SAFE AND SATISFACTORY OPERATION OF THIS SET PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN FOR FUTURE REFERENCE FOR ANY QUESTIONS OR TROUBLESHOOTING PLEASE VISIT www.mirabellagenio.net.au/faqs We recommend that the set be tested prior to being set up in the desired location : SAFETY INFORMATION • Remove set from the packaging before connecting to power supply. • Before using or re‐using the set, inspect carefully • Use only with transformer supplied • Do not connect set electrically to another set • Do not use any set which has: – cut, damaged, or frayed wire insulation, cracks in lamp‐holders, loose connections or exposed wires The LED bulb is not replaceable Note: When connecting, please ensure the arrows are aligned with one another Included in the Kit x12 x6 x1 x 12 Installation Power Adaptor Installation clips Extension cables Rubber end cap Screws ...
- Page 2 If you have dual band router but you don’t see two Wi‐Fi name SSID’s, one with 5G and one without 5G, you MUST log into the router and manually disable the 5Ghz Wi‐Fi signal if you’re having connection issues. Please contact your internet provider on how to disable 5Ghz Wi‐Fi for your router. Install the APP and register Account For the best experience, download the "Mirabella Genio" APP to your smartphone from the App Store or Google Play, the APP icon will be displayed after it’s installed successfully EZ method – when the light is fast blinking (2 blinks per second) Connect the stick light to the Wi‐Fi controller and power supply, then switch on power at the wall, wait a few seconds, stick light will start to rapidly blink (2 binks per second) If it did not automatically start to blink fast when first powered on, press and hold the pairing button on the Wi‐Fi controller until the light starts to blink rapidly Open Mirabella Genio APP, tap on +, add Manually then choose genio strip light from the list ...
- Page 3 Entre your 2.4Ghz Wi‐Fi name and password, (make sure Wi‐Fi name doesn’t end with ‐5G) Follow the APP instruction carefully to complete the network pairing process. if the fast‐blinking method (EZ method, mentioned above) doesn’t work, please try the slow blinking (AP method) below. While the strip light is rapidly blinking, press and hold the pairing button on the Wi‐Fi controller again and then wait for the light to start blinking slowly (1 blink per every 2 seconds) open up the Mirabella genio APP, tap on + , add Manually then choose genio strip light from the list 1. Entre your 2.4Ghz Wi‐Fi name and password, (make sure the Wi‐Fi name doesn’t end with ‐5G) then in reset the device first screen tap on EZ mode in the Top right hand corner just below the battery image, select AP Mode (refer to the 1st and 2nd image below) Now Confirm indicator slowly blinking (refer to image 3), hit Next, then Go to connect and connect to Wi‐Fi named SmartLife_XXXX Note: If you fail to see Wi‐Fi name beginning with the word SmartLife_XXXX, then mean the device is not slowly blinking, please reset and make it slowly blinking ...
- Page 4 After connected to SmartLife_XXXX, return back to Mirabella Genio, APP will commence adding device Please pay attention to this screen please check our online FAQ page to determent the cause of the and ensure time‐out error If the light never stops blinking, 1. You enter the correct 2.4Ghz there could be an issue with your Wi‐Fi name and password phone setting, if you are using IOS 14, please ensure local network 2.Wi‐Fi controller is in a location permission is turned on for Genio with good Wi‐Fi coverage, try move APP ...
