Sonoma 36" Bench
(070)
1
PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
Tools Required:
End Caps
Leg Assemblies
80mm Hex Lag
Actual Size
Part Code: 316-1/4-10-80HL
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
x 2
x 2
1-3/4" Phillips Head Screw
x 4
Seat Assembly
Stretcher
4mm Allen Wrench
Actual Size
Part Code: 4MMALLEN
Actual Size
Part Code: 316-8X1-3/4PFDS
x 1
x 1
x 1
x 18
Page 1
070-Rev A
Advertisement
Table of Contents
Summary of Contents for Seaside Casual Sonoma 36
- Page 1 Actual Size Actual Size x 18 Part Code: 316-1/4-10-80HL Part Code: 316-8X1-3/4PFDS WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114 Page 1 Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com 070-Rev A...
- Page 2 ATTACH STRETCHER TO LEG ATTACH BASE TO SEAT AS- ASSEMBLIES SEMBLY Turn Seat Assembly upside down on a Attach stretcher to leg assemblies using clean, flat surface. Align base assembly (4) 80 mm Hex Lags thru counter-bored centered on the seat assembly. Secure holes in Leg Assembly into pilot holes in using (16) 1-3/4”...
