Miboxer FUT103Z Quick Start Manual

Subordinate New Brand
GU10 RGB+CCT LED Spotlight
(Zigbee 3.0)
Model No.: FUT103Z

1. Features

This item supports zigbee 3.0 standard
protocol with low consumption, strong ability
to pair with network automatically and resist
interference.
16 Millions of
colors to choose
Color temperature
2700K~6500K
Dim brightness/
saturation
Product follow Zigbee 3.0
standard protocol
Zigbee 3.0
Zigbee 3.0 remote control
Control distance 100m (open area)
Smartphone App control
(Zigbee 3.0 gateway is needed)
Support third party voice control
(Zigbee 3.0 gateway is needed)
GU10 RGB+CCT LED Spotlight
(Zigbee 3.0)
Model No.: FUT103Z
Power: 4W
Working Temp.: -10~40°C
Voltage: 100-240V~ 50/60Hz
Color Temp.: 2700K~6500K
Light Efficiency: 70LM/W
Luminous Flux: 280LM
CRI: ＞80 PF: 0.55
Lifespan: 50000h
Beam Angle: 25°
Control Distance: 100m (open area)
Size: Φ50*57mm

2. Instructions

Put the light in the suitable lighting fixture.
Attention:
For lights with a weight significantly higher than
that of the lights for which they are a replacement,
attention should be drawn to the fact that the
increased weight may reduce the mechanical
stability of certain luminaires and lampholders
and may impair contact making and light
retention.
