Klein Tools 56064 Instructions

1.800.544.2843
ENGLISH
CONTENTS
• 56064 Headlamp
• Headlamp bracket with adjustable silicone strap
• 15" (381 mm) Micro USB Cable
• Instruction Sheet

GENERAL SPECIFICATIONS

• Dimensions: 2.25" x 3.125" x 1.375"
(57.2 mm x 79.4 mm x 34.9 mm)
• Weight (headlamp only): 2.96 oz. (84 g)
• Battery Type: Internal, Lithium polymer, 3.7V / 1800mAh
• Battery Life: 22 hours in Flood/Low mode,
12 hours in Spot/High mode
4 hours in All-On/Boost mode
• Charging Requirements: Maximum 5V DC, Minimum 0.5A
• Certifications: BC, CE, NR Can, REACH, RoHS
• Operating/Charging Temperature: 32°F to 113°F (0°C to 45°C)
• Storage Temperature: 14°F to 131°F (-10°C to 55°C)
• Drop Protection: 6 ft. (1.83 m)
• Ingress Protection (IP) Rating: IP54
Specifications subject to change.

WARNINGS

Read, understand, and follow these instructions to ensure safe
operation. Failure to observe these warnings can result in risk
of fire or electric shock.
• Keep these instructions for future reference.
• No user-serviceable parts inside. Do not open enclosure or
attempt to repair this headlamp.
• Never lubricate any part of this headlamp.
• Do not expose to direct sunlight, open flame, heat
sources, equipment that produces heat, or extremes in
environmental temperature.
• Never immerse in water or other liquids. Avoid spilling
liquids or falling foreign objects into openings on the
headlamp enclosure.
• Water-resistant cover must be properly sealed to achieve
specified water & foreign object ingress protection. Keep
seal free of dirt, oil, sand, or other material that interferes
with proper sealing. Failure to do so can result in risk of
fire or electric shock.
• Do not open water-resistant cover if wet or in a wet
environment. Dry the headlamp thoroughly and the seal
around water-resistant cover completely before opening
water-resistant cover.
• When headlamp is in use or charging, make sure there
is adequate space to allow ventilation of internally-
generated heat.
• Use safety-rated power supply or wall adapter. Never use
power supply or wall adapter that exceeds the specified
charging voltage and current.
• Route the power supply cable so that it will not to be
stepped on or pinched by other objects.

FEATURE DETAILS (FIG.A)

1 Power button 7 Spotlight/High
2 Battery level indicator 8 Floodlight/Low
9 Lever for removal from
3 Light sensor
bracket
4 Charging port cover 10 Headlamp bracket
5 USB charging port 11 Silicone strap
6 Micro-USB charging cable 12 Strap adjustment buckle

SYMBOLS ON PRODUCT (FIG.B)

Warning or Caution
Risk of Electrical Shock
Conformité Européenne. Conforms with
European Economic Area directives
WEEE – Battery disposal
Conforms with BCS regulations of
BC
California Energy Commission
Direct Current (DC)
Read Instructions
Recycle

MAINTENANCE

CLEANING: Be sure headlamp is turned off and wipe with a clean,
dry lint-free cloth. Do not use abrasive cleaners or solvents.
STORAGE: If the headlamp is to be left unused for an extended
period of time, charge to approximately 70% (red, yellow, and
one green) before storing, and recharge periodically during
storage to maintain battery's charging capacity.

DISPOSAL / RECYCLE

Do not place equipment and its accessories in the trash.
Items must be properly disposed of in accordance with
local regulations. Please see www.epa.gov or
www.erecycle.org for additional information.
OPERATING INSTRUCTIONS
PLEASE SEE REVERSE SIDE.
www.calcert.com
15
10 20
5 25
0 30
Rechargeable Headlamp - Instructions
FRONT / FRENTE / AVANT
FIG. A
9
1
3
5
.
4
8
6
12
10
11
BACK / ESPALDA / RETOUR
FIG. B
9
56064
7
2 2
.
