Saber Compact RP100-090W-120V-BLK Manual

LET'S ROLL
1. Power button/LED
2. Battery level LEDs
3. Bluetooth button/LED
4. USB-C
5. USB 2
6. USB 1
7. DC in
8. AC outlet
1. Power button/LED – Press for 2 sec. to turn Saber on/off. (Saber
turns off automatically after 1 minute if not in use.) Power button
LED indicates Saber's states:
• White when Saber is on
• Blinks yellow at 5% battery life
• Green when the AC outlet is on
• Blinks yellow when there's a temporary error
– check the app to troubleshoot
• Red when there's a permanent error
– call customer service at 1-833-GOSABER (1-833-467-2237)
2. Battery level LEDs – Light up gradually during charging. Light up
for 5 seconds to show Saber's battery level when powered on;
quick press the power button to check Saber's battery level again,
or just use the app.
3. Bluetooth button – Press for 2 sec. to turn Bluetooth on/off.
4. USB-C – 20V, 3A - 60W/5V, 3A - 15W
Note: USB-C supports 20V, 3A - 60W/5V, 3A - 15W. If your device's
power requirements are different, plug it into Saber's AC outlet
using the device adapter.
5. USB 2 – 5V, 1A – 5W
6. USB 1 – 5V, 2.5A – 12.5W
7. DC in – 19V, 3.42A – 65W – Connect the wall charger (included)
and plug Saber in to any standard wall outlet (charger rated for
100-240V~, 1.5A, 50-60Hz).
8. Universal AC outlet – 120V, 60Hz – 90W – Double-click the
power button to turn AC outlet on/off.
ROMEO POWER TECHNOLOGY
3
100%
75%
2
50%
25%
1
5 7
4
6
8
01
