Summary of Contents for ICC ANT-245GHZ
- Page 1 ICCN IEEE802.11 Wi-Fi ® antenna installation guide Antennas: ANT-245GHZ ANT-OMNI-12 ANT-DISH-24...
- Page 2 This guide helps users understand and deploy ICCN antennas including ANT-245GHZ, ANT-DISH-24, This guide helps users understand and deploy ICCN antennas including ANT-245GHZ, ANT-DISH-24, and ANT-OMNI-12. It contains instructions for set-up and best use with an ICCN compatible access and ANT-OMNI-12. It contains instructions for set-up and best use with an ICCN compatible access point.
- Page 3 Contents Chapter 1 Package Contents Connecting to an Access Point Mounting Configurations and Options Chapter 2 Using the antenna RF Design options...
- Page 4 This guide supports: This guide supports: ANT-245GHZ - 2.4GHz & 5.8GHz (dual-band) 7dBi Omni directional ANT-245GHZ - 2.4GHz & 5.8GHz (dual-band) 7dBi Omni directional antenna with an N-Male connector designed for indoor or outdoor use.
-
Page 5: Package Contents
Package Contents Each antenna system is packaged with different components. Please make sure you received all components as shown below. ANT-245GHZ 1 – Duck Antenna ANT-OMNI-12 1 – Omni Antenna 2 – Pole mount arms 4 – Screw and Nut set ANT-DISH-24 1 –... - Page 6 ICCN AP connectors are all N-Type Female ANT-OMNI-12 and ANT-DISH-24 have N- ANT-245GHZ Type Female connectors. The ANT-245GHZ is a male direct connect antenna and does NOT require When using the ANT-Omni-12 and ANT- a cable to connect to any ICCN AP.
- Page 7 Connecting to an AP ANT-245GHZ Connecting this small 2.4GHz/5GHz antenna is very simple since it connects directly to the Attach the antenna by matching Attach the antenna by matching it to the N-Type female it to the N-Type female connector on the AP and turning connector on the AP and turning clockwise.
- Page 8 Connecting to an AP ANT-OMNI-12 Connecting this 3 ft Omni directional antenna requires the use of an LMR cable to connect to the access point. The ICX20UAD-EXT is the only AP to use any ANT series antenna because it The ICX20UAD-EXT is the only AP to use any ANT series antenna because it has external 5GHz connectors.
- Page 9 Connecting to an AP ANT-DISH-24 Connecting this 17 inch directional dish antenna requires the use of an LMR cable to connect to the access point. The ICX20UAD-EXT is the only AP to use any ANT series antenna because it The ICX20UAD-EXT is the only AP to use any ANT series antenna because it has external 5GHz connectors.
-
Page 10: Mounting Options
Mounting options ANT-OMNI-12 The ANT-OMNI-12 is pole mounted as shown below. ANT-OMNI-12 antenna ANT-OMNI-12 antenna Included long screw, nuts, and bracket Completed mounting Completed mounting Horizontal and Vertical N-Type Female connectors. Connect ANT- CABLE-4 to these ports. - Page 11 Mounting options ANT-DISH-24 Before mounting the ANT-DISH-24, the antenna must be assembled. See below for the quick and easy steps for assembly. The cone is placed through the front of the dish. Be very careful not to scratch the grey coating. Use the long screws to secure the cone in place. Mount the L-shaped bracket at the rear of the unit making sure to match the bracket holes to the screws.
- Page 12 Mounting options ANT-DISH-24 To connect the ANT-DISH-24 to a pole, simply add the U-bolt assembly and pole bracket. Connect the U-bolt through the pole bracket. Fit the assembly Connect the U-bolt through the pole bracket. Fit the assembly around the pole then into the L-bracket on the antenna. Use around the pole then into the L-bracket on the antenna.
- Page 13 Chapter 2 Using the antenna RF Design options Signal propagation Best Practices ANT-OMNI-12 ANT-CABLE-4 ICX20UAD-EXT-AC ICX10UAD ANT-DISH-24 ANT-245GHZ ANT-CABLE-4 ICX20UAD-EXT-AC ICX20UAD-EXT-AC ANT-245GHZ Internet Gateway Gateway...
-
Page 14: Antenna Use
Antenna use The ICCN antenna selections are very flexible to meet client environment and requirements ANT-OMNI-12 Omni directional 12dBi antenna gain ANT-245GHZ ANT-DISH-2 Omni directional 7dBi antenna gain Directional 24dBi antenna gain... - Page 15 Antenna use The ICCN antenna selections are very flexible to meet client environment and requirements ANT-OMNI-12 Omni Directional Omni directional 12dBi antenna gain Directional ANT-DISH-24 ANT-DISH-24 Directional 24dBi antenna gain Directional 24dBi antenna gain ICCN provides free design assistance. Please call 951.936.0531 or email sales@iccnetworking.com...
- Page 17 International Communications Corp. International Communications Corp. 11801 Pierce St 2nd FL 11801 Pierce St 2nd FL Riverside, CA 92505 Riverside, CA 92505 Email: sales@intcomcorp.com Email: sales@intcomcorp.com O: (951) 934-0531 O: (951) 934-0531 F: (951) 934-0535 F: (951) 934-0535 ICCN Chicago Office ICCN Chicago Office 795 Ela Rd Suite 211 795 Ela Rd Suite 211...
