USER GUIDE
SCC-RTD01 Resistance
Temperature Detector
Conventions
»
The SCC-RTD01 resistance temperature detector (RTD) input module
accepts up to two RTD input signals from 2-, 3-, or 4-wire RTDs. Each
module consists of two RTD input channels, a 30 Hz Butterworth lowpass
filter for each channel and a 1 mA excitation current source. Each input
channel includes an instrumentation amplifier with differential inputs and
a fixed gain of 25.
The SCC-RTD01 filters RTD inputs and passes them through a differential
amplifier with a fixed gain of 25 resulting in a maximum input voltage of
400 mVDC. The output of the amplifier passes through a three-pole, 30 Hz
Butterworth lowpass filter. The SCC-RTD01 provides a 1 mA excitation
current source for RTDs.
The following conventions are used in this guide:
The » symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take
to avoid injury, data loss, or a system crash. When this symbol is marked
on the product, refer to the Read Me First: Safety and Radio-Frequency
Interference document, shipped with the product, for precautions to take.
When symbol is marked on a product, it denotes a warning advising you to
take precautions to avoid electrical shock.
When symbol is marked on a product, it denotes a component that may be
hot. Touching this component may result in bodily injury.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCC-RTD01 and is the answer not in the manual?

Questions and answers

Summary of Contents for National Instruments SCC-RTD01

  • Page 1 25. The SCC-RTD01 filters RTD inputs and passes them through a differential amplifier with a fixed gain of 25 resulting in a maximum input voltage of 400 mVDC. The output of the amplifier passes through a three-pole, 30 Hz Butterworth lowpass filter.
  • Page 2 SC-2345 SC-2345 refers to both the SC-2345 connector block and the SC-2345 with configurable connectors. SCC refers to any SCC Series signal conditioning module. SCC-RTD01 Resistance Temperature Detector Input Module ni.com...
  • Page 3: What You Need To Get Started

    What You Need to Get Started To set up and use the SCC-RTD01, you need the following items: ❑ SC-2345/2350 with one of the following: – SCC-PWR01 – SCC-PWR02 and the PS01 power supply – SCC-PWR03 (requires a 7 to 42 VDC power supply, not included) ❑...
  • Page 4: Device Specific Information

    You can plug the SCC-RTD01 into any AI socket on the SC-2345. The SCC-RTD01 can function as a single-stage module or as the first stage of a dual-stage signal conditioning configuration. The socket you choose determines which E Series DAQ device channels receive the SCC-RTD01 signals, as explained in the SCC Quick Start Guide.
  • Page 5: Connecting The Input Signals

    E Series DAQ device channel X+8, and pins 3 and 4 form a second differential channel routed to E Series DAQ device channel X, where X is 0 to 7 depending on the socket of the SCC-RTD01. Pins 5 and 6 carry the 1 mA constant-current excitation source.
  • Page 6 3-Wire, 1 Channel, Remote Sensing SCC-RTD01 (1 mA) – E Series AI ( X ) – Black E Series AI ( X +8) – 2-Wire, 1 Channel Figure 1. SCC-RTD01 Single-Channel Wiring Diagrams SCC-RTD01 Resistance Temperature Detector Input Module ni.com...
  • Page 7 Use 4-wire transducer connections for a more accurate measurement. Lead Note resistance in 2- and 3-wire connections can introduce measurement errors. For information about configuring the SCC-RTD01 module using NI-DAQmx, refer to the SCC Quick Start Guide. © National Instruments Corporation...
  • Page 8 Explorer (MAX), Read Voltage Data and scale it in your ADE. Converting Voltage Measurements to Temperature Measurements If you use MAX to configure the SCC-RTD01, the reading you get from the E Series DAQ device is properly scaled. Otherwise, you must scale the...
  • Page 9 Most platinum RTD curves conform to one of the following three standardized curves: • DIN 43760 standard • U.S. Industrial or American standard • International Temperature Scale (ITS)–90 (for use with wire-wound RTDs) © National Instruments Corporation SCC-RTD01 Resistance Temperature Detector Input Module...
  • Page 10: Specifications

    Offset-error temperature coefficient ..±1.6 µV/°C Nonlinearity ..........10 ppm of full scale Recommended warm-up time....5 min Amplifier Characteristics Common-mode rejection ratio....110 dB at 60 Hz Output range ...........±10 V Calculated relative to the input range of the module SCC-RTD01 Resistance Temperature Detector Input Module ni.com...
  • Page 11: Power Requirement

    Operating temperature......0 to 50 °C Storage temperature ....... –20 to 70 °C Humidity ..........5 to 90% relative humidity, noncondensing Maximum altitude ........2,000 m Pollution Degree (indoor use only) ..2 © National Instruments Corporation SCC-RTD01 Resistance Temperature Detector Input Module...
  • Page 12: Electromagnetic Compatibility

    Safety The SCC-RTD01 meets the requirements of the following standards for safety and electrical equipment for measurement, control, and laboratory use: • IEC 61010-1, EN 61010-1 • UL 3111-1, UL 6101013-1 • CAN/CSA C22.2 No. 1010.1 For UL and other safety certifications, refer to the product label or to...
  • Page 13: I/O Connector Pin Assignments

    AI (X+8). A GND is the reference for the ±15 V supplies and REF 5 V. AI GND and A GND connect to the SC-2345 at the SCC-PWR connector. GND is the reference for the +5 V supply. Table 2. SCC-RTD01 Pin Signal Connections Pin Number Signal E Series AI (X) —...
  • Page 14 — — — National Instruments™, NI™, and ni.com™ and NI-DAQ™ are trademarks of National Instruments *371072B-01* Corporation. Product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents.
