- Page 1 300379Q (B1 & B2) QUEEN SIZE BED WITH SOFT PU ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE www.coastercompany.com PAGE 1 OF 5 REVISION 0 : 12/06/2012 REVISION 1 : 06/04/2013...
-
Page 2: Assembly Tips
ITEM : 300379Q(B1 & B2) ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1.Remove hardware from box and sort by size. 2.Please check to see that all hardware and parts are present prior to start of assembly. 3.Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. Warning! 1. - Page 3 ITEM : 300379Q(B1 & B2) ASSEMBLY INSTRUCTIONS 300379Q(B1) – BOX 1 300379Q(B1 & B2) – BOX 1 & BOX 2 STEP 1 STEP 2 Lay down the headboard panel on a soft surface. Place footboard panel upside down on a soft Align and fasten bed leg to the pre-marking on the surface.
- Page 4 ITEM : 300379Q(B1 & B2) ASSEMBLY INSTRUCTIONS STEP 4 4.1) Align & fasten center support to the center of headboard panel & footboard panel using long bolt. Tighten with Allen wrench. 4.2) Align & fasten center rail onto center support using short screw. Tighten with screw driver (not included) 4.3) Align &...
- Page 5 Maintenance Notice: Headrest * When the headrest is stucked while moving: 1 . Slide out half of the drawers. Open the back cover of the headboard which is secured with velcro tape . 2. Loosen nut from the bolt of headrest with wrench. 3.
