Attention! Reliability and life of the product are provided not only by the quality of product itself,
but also by the compliance with operating modes and conditions, therefore, this document require-
ments is mandatory
ORTUS Group
PIR-R
Motion Detector
PIR-R
Operation manual
Product Compatibility Table
Compatible radio receiver
Configuration Software
Central Monitoring Station
Version en_2
Version
Lun-R
Version
Configurator 11
Version
Orlan
1
Advertisement
Table of Contents
Related Manuals for Ortus PIR-R
Summary of Contents for Ortus PIR-R
- Page 1 Attention! Reliability and life of the product are provided not only by the quality of product itself, but also by the compliance with operating modes and conditions, therefore, this document require- ments is mandatory Motion Detector PIR-R Operation manual Product Compatibility Table Version...
- Page 2 3. Technical specifications...............................3 4. How to use..................................4 4.1. Modes Indication..............................5 4.2. Binding..................................5 4.3. Wireless signal strength............................. 5 4.4. Installing................................. 6 5. Maintenance..................................6 6. Operating conditions..............................6 7. Storage....................................7 8. Transportation................................7 9. Disposal.................................... 7 PIR-R Version en_2...
- Page 3 1. Purpose The PIR-R detector (hereinafter referred to as the “detector”) is designed to detect a penetra- tion into the internal space of protected objects and transmit this events to the Lun-R receiver that is connected to the Lun control panel (more about for compatibility, see the documentation of the relevant control panel).
- Page 4 Small animals (dog weighing up to 10 kg) on the floor (more than 2m of the detector); Medium-sized animals (for example, a dog weighing up to 20 kg) on the floor (more than 2m of the detector); Longhair animals weighing up to 40 kg. PIR-R Version en_2...
- Page 5 No connection If the signal strength is poor or there is no connection, it is recommended to change the loca - tion of the detector and repeat the above process in order to form a reliable reception map. PIR-R Version en_2...
- Page 6 2. Detector shall be used at the temperature of –20°С to +55°С and relative humidity of 5% to 85%. 3. If the transportation conditions differ from the operating conditions, then the detector must be kept in the operating conditions for 2…6 hours before switching on. PIR-R Version en_2...
- Page 7 3. Transportation temperature shall be of –50°C to +50°C at the relative humidity of 5% up to 98%. 9. Disposal Detector disposal shall be carried out according to electronic household appliance disposal rules established by the legislation of the State, where the product is operated. PIR-R Version en_2...
- Page 8 Manufacturer: ORTUS Group 1 East Liberty, 6th Floor Reno, NV 89501, USA Tel.:+1 650 240 27 62 mail: info@ortus.io http://www.ortus.io PIR-R Version en_2...
