Operating manual
ACi 4400 HHU-511
Product type, manufacturing date (calendar week/year of construction)
and if required, conformity mark can be found on the nameplate on the
product.
Please provide us with the contents of the nameplate when making
enquiries about the product.
ebm-papst St.Georgen GmbH & Co. KG
Hermann-Papst-Straße 1
D - 78112 St.Georgen
Phone: +49 (0) 7724 / 81-0
Fax: +49 (0) 7724 / 81-1309
info2@de.ebmpapst.com
www.ebmpapst.com
As per: 27.09.2016
Version: 0 0
Article number: 9203509511
Original operating manual
INDEX
1 SAFETY REGULATIONS AND INFORMATION
2 INTENDED USE
3 TECHNICAL DATA
4 CONNECTION AND COMMISSIONING
5 FAULTS, POSSIBLE CAUSES AND REMEDIES
6 COMPLIANCE
2
4
4
5
7
7
page 1 of 8
Advertisement
Table of Contents
Related Manuals for ebm-papst ACi 4400 HHU-511
Summary of Contents for ebm-papst ACi 4400 HHU-511
- Page 1 Please provide us with the contents of the nameplate when making enquiries about the product. ebm-papst St.Georgen GmbH & Co. KG Hermann-Papst-Straße 1 D - 78112 St.Georgen Phone: +49 (0) 7724 / 81-0 Fax: +49 (0) 7724 / 81-1309 info2@de.ebmpapst.com...
-
Page 2: Safety Regulations And Information
Electrical voltage and current SAFETY REGULATIONS AND INFORMATION DANGER Read the operating manual carefully before commencing work at the Electrical voltage product. Pay attention to the following warnings to avoid risk to persons or malfunctioning. Regularly check the electrical This operating manual is an integral part of the product. equipment of the product. - Page 3 CAUTION High temperature at motor housing. Risk of burns Ø Provide adequate protection against accidental contact. Transport Only transport the product in its original packaging. Secure during transport. The vibration values, temperature and climate ranges should not be exceeded during transport. Storage Store the product in a dry and clean environment that is well protected.
-
Page 4: Intended Use
An in situ assessment must be conducted of the heating behavior (appropriate and inappropriate operation), the protection against contact, electrical shocks, impact of foreign objects or water and the usage at altitudes higher than 2000 meters. Contact ebm-papst if you have specific queries regarding the product. page 4 of 8... -
Page 5: Connection And Commissioning
DANGER CONNECTION AND COMMISSIONING Electrical voltage Connect mechanical parts Ø As additional protection we recommend the installation of a CAUTION RCD (residual current protective Risk of cutting/squashing when device), which is adequate for removing the product from the product, usage and application. packaging and during mounting. - Page 6 Voltage control Speed control via the supply voltage is not possible. Speed control via PWM of the supply voltage is not permitted. Requirements: - Before connecting the product, ensure that the supply voltage corresponds with the product voltage. - Check whether the data on the nameplate corresponds with the interface data.
-
Page 7: Faults, Possible Causes And Remedies
FAULTS, POSSIBLE CAUSES AND REMEDIES COMPLIANCE Replace your product by a new one, do not repair it. The product bears the CE mark. DANGER The CE mark is affixed to adequately sized nameplates. Electrical voltage at motor Within the meaning of the EMC Guideline 2014/30/EU this document is Ø... - Page 8 page 8 of 8...
