Ultra254™ Auto UVC Disinfector
Model 950
Operating Manual
Serial #
Date
Table of Contents
Safety .................................................................................................................................................................... 2
Parts ...................................................................................................................................................................... 5
Use and Operation ................................................................................................................................................ 7
Battery and Charging ............................................................................................................................................ 9
Maintenance ......................................................................................................................................................... 9
Specifications ...................................................................................................................................................... 11
Troubleshooting .................................................................................................................................................. 12
Replacement Parts .............................................................................................................................................. 13
Warranty and Service ......................................................................................................................................... 13
Event Log ............................................................................................................................................................. 14
This document describes the product functions, use, maintenance, and service contact for model 950.
Contact CoScientific LLC at service@coscientific.com for questions that are not answered or unclear in
these instructions. Information and recommendations are not a guarantee of performance, safety,
results, or suitability to the user's application by CoScientific LLC. Not for use on medical devices. For full
terms and conditions related to this sale visit coscientific.com/terms-and-conditions. Specifications are
subject to change without notice.
P-1004-Model 950 Operating Manual_C
Advertisement
Table of Contents
Related Manuals for Scientific Ultra254 950
Summary of Contents for Scientific Ultra254 950
-
Page 1: Table Of Contents
Ultra254™ Auto UVC Disinfector Model 950 Operating Manual Serial # Date Table of Contents Safety ..................................2 Parts ..................................5 Use and Operation ..............................7 Battery and Charging ............................9 Maintenance ................................. 9 Specifications ..............................11 Troubleshooting ..............................12 Replacement Parts .............................. 13 Warranty and Service ............................ -
Page 2: Safety
Ultraviolet Radiation • Avoid exposure to the lights when they are on unless protected by a solid object or car window glass (a few types of scientific specialty glass are transparent to UVC light) • Lamps emit high power UV radiation that can cause cancer and/or severe injury to skin and eyes in less than a minute •... - Page 3 UV Overexposure Symptoms can be delayed several hours to a day and include sunburn and photokeratitis (also known as snow blindness or welder’s flash). • Skin irritation can vary in severity depending on the level of exposure, a person’s genetics, and some medications.
- Page 4 UV Radiation Warning - External Vehicle Tag (Part #1058; Description: Tag, External Safety, 4x6) • Located on both ends of the orange straps • Printed on both sides • Positioned to warn people from entering the vehicle while the UV light is on •...
-
Page 5: Parts
Parts Model 950 is a portable, battery-operated UVC light disinfecting tool that is designed for regular commercial use in unoccupied vehicles. Parts of the tool are: A. Control box – Impact resistant, carbon fiber filler polymer that supports the two lamps and their covers B. - Page 6 1. On/Off toggle switch – Turn on for immediate use, turn off the tool when not in use 2. Start button – One press starts the treatment process 3. Stop button – Illuminated red stop button will stop the process at any point and will reset the system including any error codes 4.
-
Page 7: Use And Operation
Use and Operation The Model 950 is designed for air and surface disinfection of an unoccupied vehicle with closed windows and locked doors. Inactivation of a wide variety of microorganisms is accomplished with two germicidal lamps that emit a wavelength of light at 254 nm. The treatment time required to inactivate varies by type of organism, humidity, and temperature. - Page 8 The maximum time is 24 minutes at 36⁰F. See the article Basics of UV Disinfection to Reduce the Spread of COVID-19 at coscientific.com for more information and references to scientific articles and helpful links.
-
Page 9: Battery And Charging
Battery and Charging A Milwaukee® M18™ series rechargeable battery with a capacity of 5 A-hr is provided with the tool. It should be recharged with the provided charger or another compatible charger as needed. The battery has a built-in level indicator and should be at least at 1 bar out of 4 before starting a treatment process. The tool will automatically detect an error if the battery level is too low to start a process run. - Page 10 Lamp breakage See the instructions in the safety section above Lamp replacement 1. Remove a lamp cover by removing the 4 thumbscrews and by carefully sliding the cover off the end of the lamp 2. Wear latex or nitrile gloves 3.
-
Page 11: Specifications
Specifications Power source: Milwaukee® Tool M18™ removable battery Charging: Charging cradle provided, 120 VAC Battery capacity: 6 treatments Weight: 6.4 lbs. [2.9 kg] with battery Size: 4.3” W x 8.0” H x 34” L [11 cm x 20 cm x 86 cm] Lamps: Two, 24-Watt, low-pressure Hg, ozone-free Light intensity and wavelengths: 88% at 254 nm (UVC), 12% at 360-550 nm (Visible) Treatment time: 12 minutes (time increases below 68⁰F to maintain dose) -
Page 12: Troubleshooting
Troubleshooting Error Codes – Red flashing light with a repeating pattern of blinks and a delay Number of Reason Action red blinks Lamp current out of range Check for a loose or broken lamp Drop detected Press stop to reset and start without motion after the delay Temperature out of range Low Temp –... -
Page 13: Replacement Parts
Replacement Parts Contact sales@coscientific.com for replacement parts CoScientific CoScientific Description Alt Part # Part # Manufacturer 1020 Lamp, UVC, 24W, 2G11 Base Osram Puritec HNS L 24 W 2G11 Sylvania Philips TUV PL-L 24W/4P 1CT/25 PL-L24W/TUV/2G11 1022 Battery, Milwaukee, M18, 5Ah Milwaukee M18 Redlithium XC5.0, 48-11- 1850... -
Page 14: Event Log
Event Log Date Problem or Event Notes...
