4M Octopus Robotic Claw Quick Start Manual

OCTOPUS
Content
ROBOTIC CLAW
Content A. SAFETY MESSAGES
A
1. Adult assistance and supervision are required at all times. 2. This kit is intended for children over the age of 5. 3. This kit and its
finished product contain small parts which may cause choking if misused. Keep away from children under 3 years old. 4. Do not grab
humans, animals or any objects that could break.
B. CONTENTS
A
D E
D E
Part A: Handle x 1, Part B: Shaft x 1, Part C: Grip x 1, Part D: Hub x 1, Part E: Gripper arm x 3, Part F: Trigger x 1, Part G: End cap x 1,
Part H: Collar x 1, Part I: Washer screw x 1, Part J: Screws x 4. Also required but not included in the kit: small crosshead screwdriver.
C. ASSEMBLY
1
D
1
D
3
3
F
F
1. Slide the end of the shaft (B) that has a pin on it into the hub (D), lining up the flat side on the shaft with the flat edge inside the hub.
2. Slide the end cap (G) along the shaft onto the hub. Make sure you line up the wide ridge on the end cap with the wide slot on the hub.
Secure the cap and the shaft by the washer screw (I).
3. Clip the trigger (F) onto the end of the shaft.
4. Put the handle (A) in place under the shaft.
