BATTERY INSTALLATION / WIRING

Information contained in this document is copyright, and shall not be reproduced in any form

whatsoever, or its contents disclosed to any third party, without the written consent of Tyco Safety

Products (The Company). Information contained in this document is believed to be accurate and

reliable, however the company reserves the right to change the content without prior notice.

QE90

GUIDE

DOCUMENT: LT0437

ISSUE 1.00; 18 April 2007

The Vigilant QE90 EWIS is a product of

Tyco Safety Products

17 Mary Muller Drive

Hillsborough

Christchurch 8022

NEW ZEALAND

Phone : (+64 3) 389-5096

Fax : (+64 3) 389-5938

NOTICE

TYCO SAFETY PRODUCTS

Table of Contents

Need help?

Do you have a question about the QE90 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tyco QE90

Page 1 Information contained in this document is copyright, and shall not be reproduced in any form whatsoever, or its contents disclosed to any third party, without the written consent of Tyco Safety Products (The Company). Information contained in this document is believed to be accurate and reliable, however the company reserves the right to change the content without prior notice.
Page 2: Table Of Contents
TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE AMENDMENT LOG AMENDMENT DESCRIPTION DATE APPROVED PROD 1.00 ORIGINAL 18/4/07 TABLE OF CONTENTS PROCEDURE.........................3 SAFETY NOTICE ......................3 OVERVIEW ........................4 BATTERIES ........................4 KITS..........................5 INTER-CABINET WIRING .....................6 TYPICAL BATTERY / WIRING ARRANGEMENTS ............7 40Ah(2 x 40Ah BATTERIES) ..................7...
Page 3: Procedure
QE90 BATTERY INSTALLATION / WIRING GUIDE PROCEDURE It is suggested that a QE90 Panel should be first tested with mains only i.e. with the batteries disconnected. This will provide greater protection in the event of a 24V wiring problem. However, do not to activate many speaker or strobe outputs at the same time, or the power supply may shutdown as its current limit could be exceeded.
Page 4: Overview
OVERVIEW The QE90 design and costing program QECOST can calculate the required battery capacity for a given QE90 system. It can also print out the suggested arrangement for the batteries given the available space in the QE90 cabinet. The diagram and instructions that follow are the recommended procedures for fitting the batteries specified by QECOST or calculated as described in the QE90 Technical Manual (LT9002).
Page 5: Kits
QE90 BATTERY INSTALLATION / WIRING GUIDE KITS The following kits are available and will be supplied with the QE90 Panel in the correct quantities for connecting the recommended battery configuration, as specified by QECOST. KT0500 KIT, IN-CABINET M6 BATTERY LINK KIT, consisting of:...
Page 6: Inter-Cabinet Wiring
TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE KT0501 KIT,INTER-CABINET M6 BATTERY LINK KIT, consisting of: KT0499 KIT,M5/M6 BATTERY TERMINAL HARDWARE KIT 1 OFF LM0379 LOOM,156AUTO,RED/BLK,0.35M,BOTH:CRIMP M6 LUG 1 OFF LM0380 LOOM,158AUTO,RED,1.2M,BOTH:CRIMP M6 LUG 1 OFF LM0381 LOOM,158AUTO,BLK,1.2M,BOTH:CRIMP M6 LUG...
Page 7: Typical Battery / Wiring Arrangements
TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE TYPICAL BATTERY / WIRING ARRANGEMENTS In the following diagrams and procedures detailing typical battery / wiring arrangements, the batteries are numbered in the order that they are to be placed in the cabinet and, for convenience, these numbers are referred to in the procedures.
Page 8 TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 2 * 40Ah Photo Version 1.00 18 April 2007 Page 8 OF 20...
Page 9: 80Ah (4 X 40Ah Batteries)
TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 7.2 80Ah (4 x 40Ah BATTERIES) Connection Procedure 1. Place B1, B2, B3, and B4 in the cabinet as shown below with the terminals facing the door, and with B2 and B4 on top of B1 and B3.
Page 10 TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 4 * 40Ah Photo Version 1.00 18 April 2007 Page 10 OF 20...
Page 11: 99Ah (6 X 33Ah Batteries)
TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 7.3 99Ah (6 x 33Ah BATTERIES) Connection Procedure The batteries are placed on their ends, with the terminals facing to the left or right as appropriate. Place the batteries in sequence, as they are wired, as follows –...
Page 12 TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 2 x LM0377 PLAN VIEW Bottom Bottom Back Row Black (+ve at top) Black Bottom Black 3 x LM0379 From Possible inter- cabinet wiring Black Bottom Front Row Black (-ve at top)
Page 13: 75Ah (2 X 75Ah Batteries)
TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 7.4 75Ah (2 x 75Ah BATTERIES) Connection Procedure The batteries are orientated on their sides with the terminals facing to the left or right as shown below. Place the batteries in sequence, as they are wired, as follows –...
Page 14 TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 2 * 75Ah Photo Version 1.00 18 April 2007 Page 14 OF 20...
Page 15: 150Ah (4 X 75Ah Batteries)
TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 7.5 150Ah (4 x 75Ah BATTERIES) Connection Procedure The batteries are placed on their sides with their terminals facing to the left or right as shown below. Place the batteries in sequence, as they are wired, as follows –...
Page 16 TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 4 * 75 Ah Layout Version 1.00 18 April 2007 Page 16 OF 20...
Page 17 TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 4 * 75Ah Photo Version 1.00 18 April 2007 Page 17 OF 20...
Page 18: 225Ah (6 X 75Ah Batteries)
TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 7.6 225Ah (6 x 75Ah BATTERIES) Notes Note for this configuration the batteries are mounted with the terminals on top. The top layer should be spaced from the bottom layer with rectangles of 18mm thick plywood or chipboard, or folded newspaper, so that the top layer clears the terminals of the bottom layer.
Page 19 TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE PLAN VIEW Top Layer Black LM0377 Red LM0377 From Black Black Possible LM0379 inter- Black cabinet LM0379 LM0379 wiring Black LM0378 Black LM0378 Black PLAN VIEW Bottom Layer 6 * 75Ah Layout Version 1.00...
Page 20 TYCO SAFETY PRODUCTS QE90 BATTERY INSTALLATION / WIRING GUIDE 6 * 75Ah Photo Version 1.00 18 April 2007 Page 20 OF 20...
