Summary of Contents for AET EagleRac AE/MSC-40
- Page 1 EagleRac – Collector Installation Produced by...
- Page 2 Parts Required: M106 – EagleRac U Bracket M505 – SS Hex Bolts 1” Length AE-RM/MSC-FRM – AET/MSC Collector Rack Mount Clips M509 – 3/8”-16 SS Nut 1. Using M106, slide M505 into rail and attach to preassembled triangles as shown below. (Triangles not to exceed 6’ O.C. spacing)
- Page 3 2. Attach AE-RM/MSC-FRM to collector using the L/5 rule. (See table below for L/5 distance) DISTANCE OF CENTEROF MOUNT FROM COLLECTOR TOP AND BOTTOM OF COLLECTOR (L/5) AE/MSC-40 2’ 0” AE/MSC-32 1’ 7-1/4” AE/MSC-28 1’ 4-3/4” AE/MSC-26 1’ 3-5/8” AE/MSC-24 1’...
- Page 4 3. Slide M505 bolts in horizontal rails and attach the collectors using M509 as shown below.
- Page 5 Available EagleRac Manuals (Available upon request) • EagleRac Parts List • EagleRac Triangle Assembly • EagleRac Splice • EagleRac Collector Installation • EagleRac Metal Seam Roof Installation • EagleRac Base Mounting Options...
