C O O P E R
FREESTANDING TUB FAUCET
SKU: 950732
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing �xtures. Signature
Hardware accepts no liability for any damage to the
faucet, plumbing, �oor, or for personal injury during
installation.
Observe all local plumbing and building codes.
Unpack and inspect the product for shipping damage. If
any damage is found, contact our Customer Relations
team at 1-866-855-2284.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
For Warranty information, please visit: signaturehardware.com/services/warranty
TOOLS AND MATERIALS:
Plumbers
Tape
Level
Hex Wrench
Safety Glasses
Pencil
1
Adjustable
Thread
Wrench
Sealant
Drill
Saw Blade
REVISED 12/11/2020
CODE: FH 7129-D101-BN-U
FH 7129-D101-CP-U, FH 7129-D101-ORB-U
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Signature Hardware COOPER 950732
Summary of Contents for Signature Hardware COOPER 950732
- Page 1 C O O P E R FREESTANDING TUB FAUCET SKU: 950732 TOOLS AND MATERIALS: BEFORE YOU BEGIN We recommend consulting a professional if you are unfamiliar with installing plumbing �xtures. Signature Hardware accepts no liability for any damage to the Adjustable faucet, plumbing, �oor, or for personal injury during Plumbers...
-
Page 2: Installation
C O O P E R FREESTANDING TUB FAUCET SKU: 950732 INSTALLATION 1. Set the faucet base at its desired loaction, and mark 3. Insert the provided expansion bolts through the the location of the mounting holes, as shown. Drill one bottom of the base, as shown. - Page 3 C O O P E R FREESTANDING TUB FAUCET SKU: 950732 5. Adjust M8 screws on the rough-in base to its level 7. Remove the cover and run water for pressure test. position and then tighten hex nuts. When the bubble Check all joints to make sure no leakage.
- Page 4 C O O P E R FREESTANDING TUB FAUCET SKU: 950732 9. Fill silicone sealant between the rough-in box and 11. Remove M6 x 12 screws, take out the �ange and �nished �oor. base plate, pull out the plugs. M6 x12 Screw Flange Base plate Plug...
- Page 5 C O O P E R FREESTANDING TUB FAUCET SKU: 950732 13. Take o� protective sheath from the joint, insert the 15. Connect the inlet pipe of the faucet body into the connection seat into the faucet body (the spout is outlet hole of the inner core vertically (pay attention to face down), then tighten with M5 x 6 screw to faucet the hot [red] and cold [blue] correspondence).
- Page 6 C O O P E R FREESTANDING TUB FAUCET SKU: 950732 Once installation is complete, turn the faucet on. Allow the water to �ow for approximately 60 seconds to check for any leaks. Ensure that hot and cold water are running appropriately. Divert water to the hand shower and run for another 60 seconds.
