- Page 1 GB-1823 升华打印机 Inkjet printer 操 作 说 明 操 作 说 明 Operational Instruction ZS-GB1823 东莞市至上印花机械有限公司 30-1 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 2 东莞市至上印花机械有限公司 30-2 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 3 CAUTION 这类的预防信息被忽视，可能导致操作受伤或设备损坏。 Such precautions are ignored and may result in injury to operation or damage to the equipment. 东莞市至上印花机械有限公司 30-3 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 4 Do not place anything on top of this product. - Items may cause equipment malfunction CAUTION 请勿将本产品放置在倾斜或者容易振动的地方。 这样的放置区将会造成设备倾翻或损坏。 Do not place the product in an inclined or vibration-prone location. 东莞市至上印花机械有限公司 30-4 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 5 In order to ensure smooth operation, should be left in the equipment around enough time to reserve (before and after about 2M, about 3M). 电源安全/Power safety WARNING 如电源线出现损坏，请勿自行修理 这样可能会在损坏外产生漏电，从而引起火灾或短路。 东莞市至上印花机械有限公司 30-5 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 6 The ground terminal of the power supply Good ground pile to the end The grounding position of the connection is prohibited Water pipes Gas pipe Telephone lines and lightning lead wires 东莞市至上印花机械有限公司 30-6 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 7 Keep your computer system away from potential sources of electromagnetic interference. Such as a speaker or a cordless telephone base. 不要使用损坏或损磨的电源线 Do not use damaged or damaged power cords. 东莞市至上印花机械有限公司 30-7 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 8 确保电源线连接正确。 Make sure that the power cord is properly connected. 在遇到下列情况时，切断电源后请有经验的维修人员来维护： In the following cases, the power cut off after experienced maintenance personnel to maintain: 如果电源线或插头损坏 如果液体溅入打印机中 东莞市至上印花机械有限公司 30-8 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 9 When cleaning or checking the inside of the printer, make sure that metal objects, such as necklaces or bracelets, do not touch any of the internal components. This behavior may result in injury or electric shock 防范处理消耗品/ Consumables CAUTION 在打印机运作的时候，不要触摸任何金属部件及打印头。 打印故障可能发生。 东莞市至上印花机械有限公司 30-9 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 10 Check the waste ink bottle periodically to avoid spillage. Store the ink in a dark, cold place, do not store the location of exposure to high temperature or direct sunlight. This may affect its quality. 东莞市至上印花机械有限公司 30-10 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 11 数据接口 USB2.0 RIP 软件 标准 MainTop RIP , PrintDream 操作平台 Win 7, Win 8, Win 10 电源 220V , 50HZ/ 60HZ 运行环境 温度： 20℃-28℃ 湿度：40%-70% 打印机尺寸/重量 净尺寸/重量： 3070(L)mm×750mm(W)×1380mm(H)/260KG 以上产品之技术参数若有变化，恕不另行通知。 东莞市至上印花机械有限公司 30-11 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 12 RIP software MainTop RIP , PrintDream Operation system Win 7, Win 8, Win 10 Power supply 220V , 50HZ/ 60HZ Working room Tem： 20℃-28℃ Hum：40%-70% Outer size/weight 3070(L)mm× 750mm(W)× 1380mm(H)/260KG 东莞市至上印花机械有限公司 30-12 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 13 Remove the mounting bracket that is attached to the dryer assembly and remove the mounting screws (M8 x 14 hexagon socket screws) that are secured to the rack assembly. 2.2.2 Install the dryer assembly 东莞市至上印花机械有限公司 30-13 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 14 PC Power: Selects the power requirements that match the computer and monitor For this equipment: Grounding must be good. (Recommended in the machine's ground terminal on a separate then a ground wire to the earth) In order to ensure stable power supply, the best configuration on-line UPS power supply. CAUTION 请选用打印机标识的电源，以免因使用不符合要求的电源，而使机器被损坏。...
- Page 15 (R) Core (TM) i5-6300HQ CPU @ 2.30GHZ 2.30 GHZ 系统类型： (RAM):8.00GB Recommended computer hardware and software configuration: hardware Processor: lnte (R) Core (TM) i5-6300HQ CPU @ 2.30GHZ 2.30 GHZ System type: (RAM): 8.00GB 2.PrintDream 打印控制软件的安装 将打印软件压缩包解压出来并将应用程序发送至桌面快捷方式即可 东莞市至上印花机械有限公司 30-15 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 16 2. 蒙泰安装/maintop system setup 1) 将蒙泰解压至电脑硬盘 1）Unzip Maintop to the computer hard drive 东莞市至上印花机械有限公司 30-16 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 17 (recommended to install to a disk other than the C drive) 3. 安装完成后将图标移到桌面， 打开蒙泰，点击文件-打印机设定-安装蒙泰打印机 3. After installation is complete, move the icon to the desktop, open Maintop , click File - Printer Settings - Install the Maintop printer 东莞市至上印花机械有限公司 30-17 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 18 4. 选择自定义打印机， 选择蒙泰专用曲线 Select the Default printer, and select the Maintop profile 5. 设定打印机 5. Click" Properties" to set the printer 东莞市至上印花机械有限公司 30-18 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 19 6. 完成设定后点： “设为默认打印机” 6. After setting , Click" Set as default printer 第五章 参数设置/Setting 1) Press " Printdream" , The setting screen will be display: 东莞市至上印花机械有限公司 30-19 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 20 材料设置/Media setting: 1) Print setting/ click Param-Enter into Media set screen. 1) 打印设置/ 根据材料不同进行参数设置。 东莞市至上印花机械有限公司 30-20 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 21 Position: The position where the color bar prints the image (left side of the figure, right side of the figure, both sides of the figure). 6.走料 走料速度：材料进退速度（慢速，中速，快速）可选 6. Speed Feeding speed: material advance and retreat speed (slow, medium speed, fast) optional 7.均匀模式 选择均匀模式， 可以更好的改善打印过程中的偶尔出现的深浅道问题， 不选择图片打印的精度更高， 东莞市至上印花机械有限公司 30-21 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 22 8.打印完后自动走纸，打印完成任务后自动走纸 8. Automatically after printing paper, print the task automatically after the completion of paper 2）偏差校正/Maintain Press the":Maintain", Below screen will be shown, 东莞市至上印花机械有限公司 30-22 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 23 If there is any deviation, you can perform the following operations to adjust the pulse of the cleaning action. (Each time you change the number of points to remember the point application to determine the point to save) 东莞市至上印花机械有限公司 30-23 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 24 三．检查安装好的两个喷头是否与平台平行，然后进行洗墨过程，让喷头有一个良好的状态。 Check the installed two spray heads are parallel to the platform, and then wash the ink process, so that the nozzle has a good state. 东莞市至上印花机械有限公司 30-24 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 25 四 五 东莞市至上印花机械有限公司 30-25 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 26 3. According to the top and bottom of the undisputed symmetry of the most straightforward numerical changes in software parameters for addition and subtraction, until the test chart value "0" up and down the form of the most 东莞市至上印花机械有限公司 30-26 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 27 3. in the fight out of the map to find the line and the slash of the coincidence and remember the relative figures. 4. Change the corresponding logarithm on the software. 5. until the calibration curve out of the line and the slash coincide with the location of the 0 东莞市至上印花机械有限公司 30-27 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 28 To determine whether the X motor is in motion 1.检查电脑内存是否足够 动态分配内存失败 2.关闭一些不需要的软件 10010 Dynamic allocation of memory 1. Check the computer memory is sufficient failed 2. Close some unwanted software... 东莞市至上印花机械有限公司 30-28 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 29 1. X return to the origin or flash bit Printing is not ready 2. Is there any other action in progress? 创建邮槽失败 确认 RIP-receive 是否关闭 10022 Failed to create mail slot Confirm RIP-Receive shut off and on 东莞市至上印花机械有限公司 30-29 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
- Page 30 2. Check if the Y position in the lower left corner of the software is negative. If a negative number is selected, please check the position printing (Y axis positioning function may report this error) 未检测到纸张 10030 Paper is not detected 东莞市至上印花机械有限公司 30-30 Best Printing Machine Limited Website: Http://www.zsheatpress .com Email: sales@zsheatpress.com...
