- Page 1 RIDGEWOOD 4PC PATIO DINING CHAIRS ASSEMBLY INSTRUCTION ITEM#: RMS5373 SKU# 810452008 Need help? We are here for you! 1(877)539 – 7436 Toll Free • service.cci@polywares.com • Email Address...
- Page 2 GENERAL BEST PRACTICES FOR ASSEMBLY: Read all instructions before starting Clear a at covered space to begin assembly Always best to do it with a friend Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the product Number of the hardware corresponds to its letter in the package Helpful hints provided along the way Retain these assembly instructions for future reference...
- Page 3 PARTS LIST PART PART MATERIAL CODE PART Q’TY MATERIAL CODE PART Q’TY 17C33A0712001YX RMS5373-CS11-2 BOLT M6*35 SEAT ASSEMBLY RMS5373-CS14-1 17FA05040301-YX WASHER d6.5*D13*1.0 SUPPORT FRAME RMS5373-CS12-1 17FA08060601-YX WASHER d8.5*D17*1.6 BASE ASSEMBLY RMS5373-CS19-1 17FC08030801-YX WASHER d8.5*D12*2.1 SEAT POST 17FA05100701-YX 18000744004 DECORATIVE WASHER d6.5*D30*2.0 PLASTIC COVER 17D03A040401-YX 17C33A0706001YX...
- Page 4 STEP 2 PARTS REQUIRED: 2, 4, 7, 10, 11, & 13 Tighten all bolts by using the supplied Hex key. STEP 3 PARTS REQUIRED: 3, & 5 PAGE 3 OF 4 E-320...
- Page 5 STEP 4 PARTS REQUIRED: 3, 4, 8, & 12 Note: For ease with installation, we recommend that the seat post (#4) be slightly oiled or waxed before fastening to the base assembly (#3). STEP 5 PARTS REQUIRED: 14 Caution: To ensure one’s safety during use of this swivel rocker chair, examine all of the bolts to make sure that they are securely fastened.
