SoundGate Simple-fi VIDBMW1V4 Quick Manual

Be Sure To Ask Your Autosound Specialist About
These Other Exciting SoundGate Products...
• Competition-Grade Interfaces for adding amplifiers
• Remote audio control interfaces that let you control aftermarket receivers and CD players from your
factory rear seat, or steering-wheel-mounted audio controls.
• And many others!

Why SoundGate Dealers have the edge...

The technologies used in today's vehicles are as sophisticated as any laptop computer. At
SoundGate we believe these new technologies are full of opportunities for mobile electronic
dealers across the nation. We make it a high priority to not only research these new systems, but
to understand them and their impact on the aftermarket car audio industry. Armed with this
knowledge, we are well equipped to help you integrate new components into these systems with
our innovative, high-performance interfaces and unparalleled technical support.
Liability Disclaimer: SoundGate ® , Stillwater Designs, Inc., its subsidiaries, or Officers of the corporation
cannot be held liable for damages or injuries caused by, or resulting from the use of this instruction guide or product.
REPAIR OR REPLACEMENT IS THE EXCLUSIVE REMEDY OF THE PURCHASER. ANY IMPLIED WARRANTY ON THIS PRODUCT
INCLUDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED IN DURATION TO THE DURATION OF
THE WARRANTY(please see the enclosed Limited Warranty document for complete Warranty information). SOUNDGATE
NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION
WITH THE SALE AND USE OF THIS PRODUCT. SOUNDGATE PROHIBITS ANY RETAILER FROM EXTENDING ANY WARRANTY
OR WARRANTIES ON BEHALF OF SOUNDGATE TO ANY PERSON. SOUNDGATE IS NOT RESPONSIBLE FOR ANY INDIRECT,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
Strictly adhere to all car manufacturer warnings that pertain to the disassembly, maintenance, or servicing of the vehicle and
any of its associated parts or systems.
SoundGate cannot be held responsible for discrepancies, or inconsistencies that may occur due to vehicle
manufacturing changes.
If you feel that you cannot agree with the above limitations, please return this product to the dealer you
purchased it from, or call SoundGate Customer service at 800-256-0808 for a Return Authorization number, and return the
product to SoundGate for a credit or refund.
Page 1
VIDBMW1V4

Purpose...

The VIDBMW1V4
allows you to add
up to 2 video
signals (DVD,
VCR, rear-view
camera, game console, etc.) to the factory
navigation systems on the BMW vehicles listed
below.
Note: The VIDBMW1V4 provides video input only. To
input audio signals, you will need an additional
interface (sold separately - see below).
The SoundGate VIDBMW1V4 works in the following BMW vehicles when the vehicle is
equipped with the factory Navigation system:
1996 - 2005 3-Series including M & Z
1997 - 2003 5-Series
9/98 - 2001 7-Series (please see VIDUNIV for 7-series with "I-Drive")
2004 - 2006 X3
2000 - 2005 X5
2003 - 2006 Z4
2001 - 2003 Z8
Audio input interfaces (one part required if you need to input audio signals also):
SDSBMW - Vehicles without factory DSP, with CD changer
AUXBMWV2 - Vehicles without factory DSP, without CD changer
SDSBMWDSP - Vehicles with factory DSP, with CD changer
AUXBMWDSP - Vehicles with factory DSP, without CD changer
Copyright © 2004-2008 SoundGate ® . All Rights Reserved. SoundGate ® is a registered
trademark of Stillwater Designs, Inc. All other trademarks are the property of their
respective owners.
If you experience any problems, call SoundGate Technical Support at 800-256-0808
or e-mail us at sgtech@soundgate.com.

Features...

The VIDBMW1V4 utilizes microprocessor
control, ultra-reliable surface-mount
construction, and advanced firmware design, to
flawlessly match the video signal from the new
sources to the factory system.
The VIDBMW1V4 is also equipped with
brightness, color and contrast adjustments
to allow you to get the best quality picture
possible.
w w w w w w . . s s o o u u n n d d g g a a t t e e . . c c o o m m
Rev 20080520
