Step.1
步驟.一
Step.2
步驟.二
Step.3
步驟.三
Step.4
步驟.四
TREY 25W
(Track Spotlight軌道射燈)
INSTALLATION INSTRUCTION 安裝說明
Follow the track installation manual to
install the track.
預先在適當的位置跟從軌道的安裝說明書，
安裝軌道。
Choose the phase (1, 2 or 3) before
fastening into the track or afterwards.
安裝固定於軌道之前先選擇線路(1, 2 或 3)
或者在安裝後選擇。
Fastening into the track.
將軌道頭固定上軌道。
Installation is finished.
安裝完成。
Step.5
步驟.五
Rotate the joint to adjust the angle.
旋轉關節以調整照射角度。
Advertisement
Table of Contents
Summary of Contents for TCi TEJAS TREY 25W
- Page 1 TREY 25W (Track Spotlight軌道射燈) INSTALLATION INSTRUCTION 安裝說明 Powered by Step.1 Step.5 步驟.一 步驟.五 Follow the track installation manual to Rotate the joint to adjust the angle. install the track. 旋轉關節以調整照射角度。 預先在適當的位置跟從軌道的安裝說明書， 安裝軌道。 Step.2 步驟.二 Choose the phase (1, 2 or 3) before fastening into the track or afterwards.
- Page 2 Luminaires not suitable for covering with thermally insulating material. 任何情況下,燈具都不能被隔熱襯墊或 類似的材料覆蓋。 WARNING: The luminaire shall be installed by a qualified electrician and wired in accordance with the lastest IEE electrical regulations or the national rrquirements. 本產品必須交由專業人士安裝，且電線必須符合最新電氣標準或國家漂準法規。 INSTALLATION INSTRUCTION Please ensure the minimum of 40mm gqp from the top. 必須確保本產品的頂部至少有40mm的間隙。...
