- Page 1 JAGA OXYGEN REFRESH UNITS Service manual: OXRE.015 OXRE.020 OXRU.015 OXRU.020...
-
Page 2: Table Of Contents
• any repair carried out by yourself • devices are installed in a manner that makes the devices difficult to access. Jaga reserves the right to change product specification at any time in line with our policy of continuous improvement and innovation. -
Page 3: Warnings And Safety
- do not insert body parts or objects in the air inlet or outlet - pay the utmost attention to the signs and symbols located on the appliance Connections: - non-conforming electrical and hydraulic connections releases Jaga N.V. from liability concerning damage to objects and persons Use:... -
Page 4: Spare Parts
SPARE PARTS Note: for replacement or defective parts, contact the installer and consult the general JAGA warranty terms. OXRE.015 OXRE.020 JAGA OXYGEN REFRESH UNITS OXRU.015 OXRU.020 T-air sensor 24800.00030047 T-water sensor 24800.00030053 CO2-Sensor kit 38811.160701 Control panel 24800.00030042 Motor / Fan 24590.00040005... -
Page 5: Composition
COMPOSITION OXRE Filter CO2-sensor kit Control panel T-water sensor Filter Valve* Motor / Fan * not replaceable jaga OXYGEN REFRESH UNIT service manual 97... - Page 6 OXRU CO2-sensor kit Filter Control panel T-water sensor Motor / Fan jaga 98 OXYGEN REFRESH UNIT service manual...
-
Page 7: Replacing The T-Air Sensor
1 turn so the appliance Unscrew the lid and remove it from the appliance. can be taken down from the wall. OXRE.015 / OXRU.015 OXRE.020 / OXRU.020 The t-air sensor is located in the appliance centrifuge housing. jaga OXYGEN REFRESH UNIT service manual 99... - Page 8 Unit). [T-Luchtsensor] Disconnect the t-air sensor connector from the printed circuit board. Remove the sensor by inserting the connector from the inside to the outside through the hole in the housing. [T-Luchtsensor] jaga 100 OXYGEN REFRESH UNIT service manual...
- Page 9 Check whether the sensor is in the centrifuge housing, and that it is beyond the reach of the fan. [T-Luchtsensor] Connect the new sensor to the (white) connector on the printed circuit board. jaga OXYGEN REFRESH UNIT service manual 101...
- Page 10 4 screws. ! Screw the 4 screws so the appliance is fixed. Reconnect the power supply. Mount the housing around the unit. ! CAUTION: If necessary, reconnect the coiled cable to the control panel. jaga 102 OXYGEN REFRESH UNIT service manual...
-
Page 11: Replacing The T-Water Sensor
! CAUTION: If necessary, disconnect the coiled cable from the control panel! Remove the screw above the OCU (Oxygen Con- Open the appliance OCU by sliding it up. trol Unit). Remove the sensor holder of the low H2O battery. jaga OXYGEN REFRESH UNIT service manual 103... - Page 12 [T-Watersensor] Place the new sensor through the hole at the bottom of the OCU. [T-Watersensor] [T-Watersensor] Connect the new t-water sensor to the right (red) connector on the circuit board in the OCU. jaga 104 OXYGEN REFRESH UNIT service manual...
- Page 13 Firmly push the water sensor onto the battery of the low H2O radiator. Reconnect the power supply. Mount the housing around the unit. ! CAUTION: If necessary, reconnect the coiled cable to the control panel. jaga OXYGEN REFRESH UNIT service manual 105...
-
Page 14: Replacing The Co2 Sensor Kit
Check the condition of cable. If this is still in Remove the screw above the OCU. good condition, it will not need replacing, go to step 11. If it does need to be replaced, proceed to step 6. jaga 106 OXYGEN REFRESH UNIT service manual... - Page 15 Mount the OCU. And lock the OCU with the screw. To continue: go to step 13. [Water temp sensor] Disconnect the sensor from the cable. And connect the new CO2 sensor to the cable jaga OXYGEN REFRESH UNIT service manual 107...
- Page 16 Slide the new CO2 sensor in the OCU slots provi- Reconnect the power supply. ded for this purpose. Mount the housing around the unit. ! CAUTION: If necessary, reconnect the coiled cable to the control panel. jaga 108 OXYGEN REFRESH UNIT service manual...
-
Page 17: Replacing The Control Panel
Check the condition of cable. If this is still in Remove the casing from the device. good condition, it will not need replacing, go to step 13. If it does need to be replaced, proceed to step 6. jaga OXYGEN REFRESH UNIT service manual 109... - Page 18 Open the appliance OCU by sliding it up. MODE [Bedieningspaneel] Disconnect the control panel connector and insert the new cable into the appropriate connector on the printed circuit board. Mount the OCU. And lock the OCU with the screw. jaga 110 OXYGEN REFRESH UNIT service manual...
- Page 19 Adhere the panel in the desired position, and Reconnect the power supply. apply pressure for 3 seconds. Place the grille back on the appliance. jaga OXYGEN REFRESH UNIT service manual 111...
-
Page 20: Replacing The Motor/Fan
! CAUTION: If necessary, disconnect the coiled cable from the control panel! Loosen the wall screws by 1 turn so the appliance Unscrew the lid and remove it from the appliance. can be taken down from the wall. jaga 112 OXYGEN REFRESH UNIT service manual... - Page 21 Unscrew the motor bracket (4 nuts) and remove Disconnect the motor from the brackets by loose- OUTPUT: 24V (0-10 V) the motor bracket (with motor) from the ap- ning 4 bolts. pliance. Vout Vout JDPC.006 (230V - 50Hz) [Netstekker EU] jaga OXYGEN REFRESH UNIT service manual 113...
- Page 22 Fit the new motor to the motor bracket with 4 Attach the motor bracket with motor to the ap- bolts. pliance. Pull the cables from the motor to the OCU through the provided hole. jaga 114 OXYGEN REFRESH UNIT service manual...
- Page 23 (230V - 50Hz) [Netstekker EU] Reconnect the 0-10V cables. ! CAUTION: ensure this is done in the correct order: Blue: GND / Yellow: Vout Mount the OCU. And lock the OCU with the screw. jaga OXYGEN REFRESH UNIT service manual 115...
- Page 24 4 screws. ! Screw the 4 screws so the appliance is fixed. Reconnect the power supply. Mount the housing around the unit. ! CAUTION: If necessary, reconnect the coiled cable to the control panel. jaga 116 OXYGEN REFRESH UNIT service manual...
-
Page 25: Replacing The Control Unit (Ocu)
(230V - 50 POWER 30W INPUT: 110-240VAC OUTPUT: 24V Vout AIN JDPC.006 JDPC.006 (230V - 50Hz) (230V - 50Hz) Disconnect all connectors from the printed circuit Open the appliance OCU by sliding it up. board jaga OXYGEN REFRESH UNIT service manual 117... - Page 26 Ensure the location where the control will sit is clean and free of grease. (230V - 50Hz) (0-10V) sensor POWER 30W INPUT: 110-240VAC OUTPUT: 24V Vout AIN JDPC.006 MODE (230V - 50Hz) Reconnect all cables to the new printed circuit board/OCU. jaga 118 OXYGEN REFRESH UNIT service manual...
- Page 27 jaga OXYGEN REFRESH UNIT service manual 119...
- Page 28 ! Screw the 4 screws so the appliance is fixed. Connect the coiled cable to the new control Remove the protective layer from the adhesive panel. zone on the bottom side of the new control panel. jaga 120 OXYGEN REFRESH UNIT service manual...
- Page 29 Adhere the panel in the desired position, and Reconnect the power supply. apply pressure for 3 seconds. Place the grille back on the appliance. jaga OXYGEN REFRESH UNIT service manual 121...
- Page 30 NOTA jaga 122 OXYGEN REFRESH UNIT service manual...
- Page 31 NOTA jaga OXYGEN REFRESH UNIT service manual 123...
- Page 32 Jaga N.V., Verbindingslaan z/n, B-3590 Diepenbeek Tel.: +32 (0)11 29 41 11, Fax: +32 (0)11 32 35 78, info@jaga.be, www.jaga.be 27200.23200083 - January 18, 2018 2:54 PM - Jaga N.V.
