Page 1 Hardware Guide V G N - A s e r i e s...
Page 2: Read This First
Sony Corporation provides no warranty with regard to this manual, the software, or other information contained herein and hereby expressly disclaims any implied warranties or merchantability or fitness for any particular purpose with regard to this manual, the software or such other information. In no event shall Sony Corporation be liable for any incidental, consequential, or special damages, whether based on tort, contract, or otherwise, arising out of or in connection with this manual, the software, or other information contained herein or the use thereof.
Page 3: Environmental Information
Corrugated cardboard is used for packaging cushions. Owner's record The serial number and model number are located on the bottom of your Sony computer. Record the numbers and refer to them if you call VAIO-Link. See also the printed Specifications document.
Page 4: Safety Information
If reporting a gas leak, do not use the modem or a telephone in the vicinity of the leak. Avoid using the modem during a severe electrical storm. To change the backup battery, please contact your nearest Sony Service Centre. Before you connect peripherals, turn off the computer and all peripherals.
Page 5 Hardware Guide Audio/video Audio and picture distortion may occur if this equipment is positioned in close proximity to any equipment emitting electromagnetic radiation. Connectivity Never install modem or telephone wiring during a severe lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. Take care when installing or modifying telephone lines.
Page 6: Regulatory Information
Hardware Guide Read this first Regulatory information Sony hereby declares that this product is in compliance with the essential requirements and other relevant provisions of European Directive 1999/5/EC (radio equipment and telecommunications terminal equipment Directive). Declaration of Conformity The European Union is targeting the free movement of goods for the internal market and to prevent technical barriers to trade. This effort has resulted in several EU Directives asking that manufacturers make their products comply with essential standards.
Page 7 Hardware Guide Read this first Your computer may have Wireless LAN functionality. If your model is equipped with Wireless LAN, please read the Regulations Guide before activating the Wireless LAN functionality. Depending on the country, usage of the Wireless LAN functionality may be restricted. For country-specific details, please refer to the Regulations Guide.
Page 8 Hardware Guide Disposing of lithium ion batteries Do not handle damaged or leaking lithium ion batteries. Dispose of promptly and properly at end-of-life. Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.
Page 9 Portability – The rechargeable battery pack provides hours of use without AC power. Sony audio and video quality – A The high-resolution LCD screen and high-quality external stereo speakers* enables you to take advantage of today’s advanced multimedia applications, games, and entertainment software.
Page 10 Hardware Guide Welcome Excellent customer support – If you are experiencing any problems with your computer, please check the VAIO-Link website for a possible solution: www.vaio-link.com Before contacting VAIO-Link, please try to solve the problem by reading this guide, your printed Guide to Troubleshooting and Recovering your VAIO System, or the manuals and help files for the peripherals or software.
Page 11: Documentation Pack
Hardware Guide Documentation pack Your documentation pack contains printed information and user guides to read on your computer. Guides are provided in PDF format, which you can easily browse through and print out. The My Info Centre portal is a perfect starting point to using your VAIO - a comprehensive collection of everything you need to get the most from your PC.
Page 12: Printed Documentation
A Guide to Troubleshooting and Recovering your VAIO System, where you will find solutions to common problems, an explanation of how to recover your computer’s system if you need to, and VAIO-Link information. Your Sony Guarantee conditions. Booklets containing the following information: Safety Regulations, Modem Regulations, Wireless LAN Regulations, Bluetooth Regulations* and Wireless Product Regulations*.
Page 13 Hardware Guide Non-printed documentation My Documentation contains the following VAIO user guides: The Hardware Guide (this guide) explains the features of your VAIO in detail, how to use these features confidently and safely, connect peripheral devices, upgrade your computer, and more. The Software Guide describes how to register your VAIO, the software features available with VAIO systems, how to change settings, how to manage drivers, and more.
Page 14 Hardware Guide Further sources Go to Start > Help and Support for VAIO support information as well as tips and tricks. Consult the Online Help files of the software you are using for detailed information on features and troubleshooting. Go to www.club-vaio.com to find online tutorials about your favourite VAIO software.
Page 15: Ergonomic Considerations
Hardware Guide Ergonomic considerations You will be using your computer as a portable device in a variety of environments. Whenever possible, you should attempt to take account of the following ergonomic considerations to both stationary and portable environments: Position of your computer – Place the computer directly in front of you (1). Keep your forearms horizontal (2), with your wrists in a neutral, comfortable position (3) while using the keyboard or touchpad.
Page 16 Hardware Guide Welcome Lighting – Choose a location where windows and lights do not create glare or reflection on the display. Use indirect lighting to avoid bright spots on the display. You can also purchase accessories for your display that help reduce glare. Proper lighting adds to your comfort and work effectiveness.
Page 17: Table Of Contents
Read on to get the most out of using your VAIO computer. Connecting a power source (page 17) Setting up your computer with Sony Notebook Setup Shutting down your computer safely Using the keyboard (page 25)
Page 18: Connecting A Power Source
Hardware Guide Connecting a power source You can use either an AC adapter or a rechargeable battery pack as a power source. Using the AC adapter To use the AC adapter, proceed as follows: Plug the cable attached to the AC adapter (1) into the DC In connector (2) on the computer or on the docking station if you are using one.
Page 19: Using The Battery Pack
A tool is installed on your machine to check if you use a genuine Sony battery designed for this model. When a different kind of battery is detected and your notebook is: 1.
Page 20: Inserting The Battery Pack
Hardware Guide Inserting the battery pack To insert the battery pack, proceed as follows: Slide the lock lever (1) on the bottom of the computer to the UNLOCK position. Slide the release lever (2) on the bottom of the computer to the RELEASE position. Remove the battery compartment cover.
Page 21: Charging The Battery Pack
Hardware Guide Charging the battery pack To charge the battery pack, proceed as follows: Connect the AC adapter to the computer or docking station. Insert the battery pack. The computer automatically charges the battery (the battery indicator light flashes in a double blink pattern as the battery charges).
Page 22: Removing The Battery Pack
Hardware Guide Removing the battery pack To remove the battery pack, proceed as follows: Turn off the computer. Slide the lock lever (1) on the bottom of the computer to the UNLOCK position. Slide the release lever (2) on the bottom of the computer to the RELEASE position. Remove the battery compartment cover.
Page 23: Setting Up Your Computer With Sony Notebook Setup
Device tab. S Buttons You can link an action that you often perform to the S1 button (button next to the power button). In Sony Notebook Setup there are some pre-defined actions: Standby, Hibernate, External Display, Launch Application. Plug and Display By default, when you connect your computer to an external display, the external display is automatically detected and Hotkey Utility automatically outputs to this display.
Page 24 For more information about each option, click Help on the Sony Notebook Setup screen to display the help file. If you open Sony Notebook Setup as a limited user, then only the About This Computer tab will be visible. Using your VAIO computer...
Page 25: Shutting Down Your Computer Safely
Hardware Guide Shutting down your computer safely It is important that you shut down your computer properly so you do not lose unsaved data. To shut down your computer, proceed as follows: Turn off any peripherals connected to your computer. Click the Start button.
Page 26: Using The Keyboard
Hardware Guide Using the keyboard Your keyboard is very similar to a standard computer keyboard, but has additional keys that perform specific notebook-related tasks. For more information on the standard keys, please go to Windows Help and Support Center > Start > Help and Support. The VAIO-Link website (www.vaio-link.com) also contains glossary information to help you use the keyboard.
Page 27 Hardware Guide Troubleshooting sound My speakers are not producing sound The built in speakers may be turned off. Press the Mute button at the front right of your computer to turn on the speakers. The speaker volume may be turned down low. Press the Volume up button to increase the volume. If your computer is powered by battery, check that the battery is inserted properly and that it is charged.
Page 28 Hardware Guide Indicators Indicator Power Battery Wireless LAN Bluetooth indicator (depending on your model) Memory Stick PRO S1 indicator Light Data is read from or written to the hard drive. Hard disk Turns on when the number keys in the numeric keypad Num Lock are active.
Page 29: Using The Touchpad
Hardware Guide Using the touchpad The keyboard features a touchpad (1), which controls the cursor on the screen. You can point to, select, drag, and scroll objects on the screen using the built-in touchpad. Action Description Point Slide one finger on the touchpad to place the pointer (2) on an item or object. Click Press the left button (3) once.
Page 30: Using The Tv Function
Stream your recorded TV contents via Ethernet (or WLAN) to connected PCs. Sony cannot guarantee the streaming of recorded content if it is beyond a certain level of high quality. For details on using VAIO Zone and the remote control, please see the dedicated guide. Otherwise read the help files within the software itself.
Page 31: Using The Mouse
Hardware Guide Using the mouse Depending on your model, your computer is delivered with a wireless optical mouse*, which has no cables to plug in and uses a light-emitting diode (LED) instead of a ball. You can use the mouse anywhere you feel comfortable within a range of approx.
Page 32 Hardware Guide Before you use the mouse Before attempting to use the wireless mouse, you must enable communication between the computer and the mouse. Two AA batteries, specific for use in the wireless mouse, are supplied with your VAIO. They are identified by a sticker "For mouse" on the packaging.
Page 33 Hardware Guide Turn the wireless mouse over, slide the power button to the ON position and press the CONNECT button. Communication between the wireless mouse and the computer is now active. Steps 3 and 4 must be carried out within 10 seconds of each other. If your wireless mouse does not operate properly, the batteries may need to be replaced.
Page 34: Using Special Buttons
By default, the light sensor detects the brightness from outside and the display brightness is adjusted accordingly. This setting only applies when the display is set to automatic brightness mode in Sony Notebook Setup. Press the brightness button to set the display to automatic brightness mode.
Page 35 Hardware Guide Using your VAIO computer S1 button You can use this shortcut button for your favourite actions. See Setting up your computer with Sony Notebook Setup (page 22).
Page 36: Using The Disc Drive
Hardware Guide Using the disc drive Your computer is equipped with a double layer DVD±RW drive, which reads data from a compatible CD or DVD and writes data to a DVD-RW, DVD+RW, DVD-R, DVD+R, CD-RW, or CD-R. To insert a disc, proceed as follows: Turn on the computer.
Page 37 Hardware Guide Reading and writing CDs and DVDs To achieve optimum performance when writing data on to disc (also called ’burning’), follow these recommendations: To make the data on a disc readable on an optical drive, you need to close the burning software when you eject it. To complete this process, follow the instructions included with your software.
Page 38: Playing Dvds
Hardware Guide Playing DVDs To achieve optimum performance when playing DVDs, you should follow these recommendations. Play DVDs using the optical drive and the WinDVD for VAIO or the VAIO Zone software. See the help file on the WinDVD for VAIO software for details.
Page 39 Hardware Guide Troubleshooting discs If you have problems with discs, check the printed Guide to Troubleshooting and Recovering your VAIO System and the VAIO- Link website (www.vaio-link.com). My disc drive tray does not open If the eject button does not work try the following: Click Start, and select My Computer.
Page 40 Hardware Guide I cannot play a DVD If a region code warning appears when you are using the DVD player, it could be that the DVD you are trying to play is incompatible with the DVD drive on your computer. The region code is listed on the packaging of the disc. Change the resolution under Control Panel - Display to a lower resolution.
Page 41 Hardware Guide I cannot play a DVD when using two screens You will not have a problem in the following situations: When you use a CRT or an LCD display on its own. When you play MPEG files which are recorded on the hard drive with Windows Media Player 9. The reading speed of CD/DVD-RWs is very slow Generally, the reading speed of a CD/DVD-RW is slower than that of a -ROM or -R.
Page 42: Using Pc Cards
Hardware Guide Using PC Cards Your computer features a PC Card slot that supports Type I or Type II PC Cards. PC Cards allow you to connect portable external devices. Inserting a PC Card You do not need to shut down your computer when inserting a PC Card. To insert a PC Card, proceed as follows: Insert the PC Card into the PC Card slot with the front label and arrow facing upwards.
Page 43: Removing A Pc Card
Hardware Guide While the card is inserted, your computer may not enter the Hibernate power management mode. It may enter Standby mode. It is recommended that you remove the card before your computer enters Hibernate mode by pressing the <Fn>+<F12> keys, and when it is set to enter Hibernate automatically while using a battery as the source of power.
Page 44 Hardware Guide Troubleshooting PC Card My PC Card is not working Make sure the PC Card is compatible with your version of Windows. Use the Sony Notebook Setup utility to disable devices you are not currently using. Using your VAIO computer...
Page 45: Using The Memory Stick
Please see your printed Specifications sheet to see which Memory Stick types are compatible with your VAIO and if there are any limitations. You can purchase Memory Sticks from the Sony Style website (www.sonystyle-europe.com), or from your local Sony dealer. Detailed information about which CLIÉ handhelds are compatible with which Memory Sticks can be found here: www.clie-link.com.
Page 46 Hardware Guide Using your VAIO computer Write-protecting a Memory Stick Some Memory Sticks are designed with an erasure prevention switch to protect valuable data from accidental erasure or overwriting. Move the tab horizontally or vertically to set or release write-protection*. When the erasure prevention switch is off, data can be saved on the Memory Stick.
Page 47: Inserting A Memory Stick
Hardware Guide Inserting a Memory Stick To insert a Memory Stick, proceed as follows: Once you have stored your data from your digital device, insert the Memory Stick with the arrow facing up and toward the Memory Stick slot. Carefully slide the Memory Stick into the slot until it clicks in place. The Memory Stick is automatically detected by your system and appears in your My Computer window as a local drive.
Page 48: Using The Modem
Hardware Guide Using your VAIO computer Using the modem Your computer is equipped with an internal modem. You need to connect to a phone line to take advantage of online services and the internet, as well as to register your computer and software online, and to contact VAIO-Link by e-mail. Use the single RJ-11 jack to connect the supplied modem cable to the phone line.
Page 49: Using The Bluetooth Functionality
Hardware Guide Using the Bluetooth functionality If your notebook is equipped with the Bluetooth functionality*, you can establish wireless communication between your notebook and other Bluetooth devices such as another notebook, a mobile phone or a modem station. You can transfer data between these devices without cables and up to 10 metres range in open space.
Page 50: Communicating With Another Bluetooth Device
Hardware Guide Communicating with another Bluetooth device You can transfer data to and from other Bluetooth devices such as another notebook, a mobile phone or a modem station without using cables. To communicate with another Bluetooth device, proceed as follows: Turn on the Wireless switch.
Page 51 Hardware Guide Choose one of the following options: If you want Windows to provide you with a password, select Choose a Passkey for me. If the documentation of the other Bluetooth device contains a password, click Use the passkey found in the documentation and enter the passkey.
Page 52: Stopping The Bluetooth Connection
Hardware Guide Communicating with another Bluetooth device using Bluetooth File Transfer Wizard You can easily transfer data, such as files or pictures, to another Bluetooth device. To transfer data from or to another Bluetooth device, proceed as follows: Choose Start > All Programs > Accessories > Communications > Bluetooth File Transfer Wizard. The Bluetooth File Transfer Wizard appears.
Page 53 Hardware Guide I cannot find the Bluetooth device with which I want to communicate If the connected device is also connected to other devices, it may not appear on the Devices tab in the in your Remote Bluetooth Device Panel dialog or you may not be able to communicate with the device. Check that the Bluetooth function of the device with which you want to communicate is on.
Page 54: Using Wireless Lan (Wlan)
(radio) connection. So there is no need anymore to pull cables or wires through walls and ceilings. The Sony WLAN supports all normal Ethernet activities, but with the added benefits of mobility and roaming. You can still access information, internet/intranet and network resources, even in the middle of a meeting, or as you move from one place to another.
Page 55 Hardware Guide Communicating without an Access Point (computer-to-computer) A computer-to-computer network is a network in which a local network is created only by the wireless devices themselves, with no other central controller or Access Point. Each device communicates directly with other devices in the network. You can set up a computer-to-computer network easily at home.
Page 56 Hardware Guide 12 Fill in exactly the same Network key again, for confirmation. 13 Select the This is a computer (ad hoc) network; wireless access points are not used check box at the bottom of the screen. 14 Click OK. Your Network name appears in the Preferred networks list.
Page 57: Communicating With An Access Point (Infrastructure)
An infrastructure network is a network that extends an existing wired local network to wireless devices by providing an Access Point, for example the Sony PCWA-A320 Access Point. The Access Point bridges the wireless and wired LAN and acts as a central controller for the Wireless LAN.
Page 58: How To Select A Wireless Lan Channel
Hardware Guide How to select a Wireless LAN channel In an 802.11b/g configuration, channels 1 to 13 can be used. (a) With an Access Point ("Infrastructure") The channel used will be the channel selected by the Access Point. For details on how to select the channel that will be used by the Access Point, please refer to the corresponding instruction manual. (b) Without Access Point ("computer-to-computer") If the Wireless connection is initiated by the VAIO computer, channel 11 will be selected.
Page 59: Troubleshooting Wireless Lan
Hardware Guide Troubleshooting Wireless LAN if you cannot use the Wireless LAN function, make sure the wireless switch is turned on before checking the following points. The Wireless LAN Access Point and my computer cannot communicate Check if the power of the Access Point is turned on. Check if the Access Point is displayed in the View Available Networks list.
Page 60 Hardware Guide I cannot access the internet Check the settings of the Access Point. See the manual of the Access Point. Check if your computer and the Access Point are communicating. If they are communicating, you see the word Connected appear behind the name of the network.
Page 61: Using Power Saving Modes
Hardware Guide Using your VAIO computer Using power saving modes When you use a battery as the source of power for your computer, you can take advantage of power management settings to conserve battery life. In addition to the normal operating mode, which allows you to turn off specific devices, your computer has two distinct power saving modes: Standby and Hibernate.
Page 62: Using Hibernate Mode
Hardware Guide If you press the power button for more than 4 seconds, the computer will switch off automatically. You will lose any unsaved data. When the computer is in Standby mode, you cannot insert a disc. The computer comes out of Standby mode quicker than out of Hibernate mode. Standby uses more power than Hibernate.
Page 63 Hardware Guide Using your VAIO computer If you press the power button for more than 4 seconds, the computer will switch off automatically. If you do not use the AC adapter for a long period of time, put your computer into Hibernate mode. This power saving mode saves you the time of shutting down in the normal way.
Page 64: Troubleshooting Power Management
Hardware Guide Troubleshooting power management The power management setting is not responding Your computer’s operating system may become unstable if a lower power state, such as Hibernate is initiated, and then changed before the computer completely enters the lower power state. To restore the computer to its normal operating stability, proceed as follows: Close all open applications.
Page 65 Hardware Guide To activate anagement, proceed as follows: Right-click the power status icon in the taskbar. Select Adjust Power Properties. The Power Options Properties screen appears. Select the VAIO Power Management tab. Activating VAIO Power Management power schemes VAIO Power Management provides several predefined power schemes. Each power scheme consists of a group of power management settings that are designed to meet specific power management goals, ranging from maximum power management to no power management.
Page 66 Hardware Guide To activate a VAIO Power Management power scheme, proceed as follows: Open Adjust Power Properties. Select the Power Schemes tab. Select a power scheme in the Power schemes drop-down list. If you now select the VAIO Power Management tab, you see that the selected power scheme appears to the right of Power Scheme.
Page 67 Hardware Guide Restoring the default settings The power scheme settings that you changed on the VAIO Power Management tab can be restored to the default settings. To restore the default settings, proceed as follows: Select the VAIO Power Management tab in the Power Options Properties window. Click Advanced.
Page 68 Hardware Guide Using your VAIO computer To change the power scheme, proceed as follows: Select the desired power scheme from the drop-down list on VAIO Power Management Viewer. To view performance with the power scheme modified with VAIO Power Management, proceed as follows: When both VAIO Power Management and VAIO Power Management Viewer are running, VAIO Power Management Viewer shows performance with the power scheme that was modified with VAIO Power Management.
Page 69: Connecting Peripheral Devices
To identify and locate the ports on your computer, please see the printed Specifications sheet. Sony computer supplies, accessories and peripherals can be purchased from your local retailer or from the Sony website: For more information about connection compatibility, go to the VAIO-Link website:...
Page 70: Connecting A Docking Station
If your model is delivered with a docking station, it features a TV tuner board. In combination with Sony's VAIO Zone software, you can watch and record television programs directly on your notebook. For more information, see Using the TV function or the VAIO Zone guide.
Page 71 Hardware Guide If your notebook does not come with a docking station, you can use the following optional docking station (VGP-PRA1): 2 USB ports (page 87) Monitor/VGA port (page 76) DVI-D connector (page 76) Optical out (page 78) The docking station can be powered only with the AC adapter supplied with your computer. Do not remove the AC adapter from the docking station or the AC outlet when using the docking station;...
Page 72 Hardware Guide Attaching your computer to a docking station To attach your computer to a docking station, proceed as follows : Disconnect all peripherals from the computer. Plug the cable attached to the AC adapter (1) into the DC In port (2) on the docking station (3). Plug the power cord (4) into the AC adapter and an AC outlet.
Page 73 Hardware Guide Slide the lock lever to UNLOCK. Align the bottom connectors of the notebook with the connectors on the docking station. Push the notebook into the docking station and then push down until it clicks into place. Connecting peripheral devices...
Page 74 When attaching your computer to the docking station, do not attempt to insert or remove the battery pack. Lifting and turning the computer with the attached docking station may cause a temporary loss of power. Use the AC adapter that comes with your notebook or the optional Sony adapter. Connecting peripheral devices...
Page 75: Disconnecting Your Computer From The Docking Station
Hardware Guide Disconnecting your computer from the docking station To disconnect your computer from the docking station, proceed as follows: Disconnect all peripherals from the computer. Slide the lock lever to UNLOCK. Lift the computer away from the docking station. Close the docking station connector cover on the bottom of your computer.
Page 76: Connecting An External Display
Hardware Guide It is extremely important to close the docking station connector cover after removing your computer from the docking station. If the cover is left open, dust may get inside and damage the computer. To disconnect your docking station completely from the mains voltage, unplug the AC adapter. Connecting an external display You can connect an external display to your computer.
Page 77: Connecting A Computer Display
Hardware Guide Connecting a computer display You can connect a computer display either directly to your computer or via a docking station. To connect a computer display, proceed as follows: If you want to connect a VGA monitor, plug the display cable (1) (not supplied) into the monitor/VGA connector (2) station.
Page 78: Connecting A Multimedia Computer Display
Hardware Guide Connecting a multimedia computer display You can connect the computer to a multimedia computer display that includes built-in speakers and a microphone. To connect a multimedia computer display, proceed as follows: Plug the display cable (1) into the monitor/VGA connector (2) Plug the speaker cable (3) into the headphone connector (4) Plug the microphone cable (5) into the microphone connector (6) Connecting peripheral devices...
Page 79: Connecting A Tv
Hardware Guide Connecting a TV You can connect a TV to the computer or to the optional docking station. To connect a TV to the computer, proceed as follows: Plug one end of the audio/video cable (1) (optional) into the TV Out connector (2) (yellow) and the other end into the TV.
Page 80 TV? You need to use an AV cable which has a minijack connector on one end and 3 RCA (also called cinch) connectors on the other end. For example, the Sony VMC-20FR which is available via direct sales and various retailers. Please note that not all TVs have RCA If your TV does not have RCA in, you need an RCA to Scart converter (provided of course that your TV has a Scart in).
Page 81: Connecting A Projector
Hardware Guide Connecting a projector You can connect a projector (such as the Sony LCD projector) directly to your computer or via a docking station. To connect a projector, proceed as follows: Plug the RGB signal cable (1) into the monitor/VGA...
Page 82: Selecting Display Modes
The Display Properties dialog box appears. Click the Settings tab. Click the Advanced button. The Sony Notebook LCD and MOBILITY RADEON Properties dialog box appears. Click the Displays tab. Select the Monitor, Panel or FPD icon. Click Apply and then OK.
Page 83: Using The Dual Display Function
Hardware Guide Using the Dual Display function The dual display function allows you to distribute portions of your desktop across separate displays. For example, if you have an external monitor attached to the monitor connector, your LCD display and the monitor can function as a single desktop. You can move the cursor from one display to the other.
Page 84 Hardware Guide Selecting the Dual Display mode To select the Dual Display mode, proceed as follows: Click the Start button on the Windows taskbar. Click Control Panel and then Appearance and Themes. Click the Display icon and then the Settings tab. Click the display marked 2 and select the Extend my Windows desktop onto this monitor check box.
Page 85 Hardware Guide Customising the virtual desktop You can customise the Dual Display mode by changing the position of the two monitors comprising the virtual desktop. To customise Dual Display mode, proceed as follows: Click the Start button on the Windows taskbar. Click Control Panel and then Appearance and Themes.
Page 86: Connecting External Speakers
Hardware Guide Connecting external speakers Using external speakers can enhance the sound quality of your computer. Depending on your model*, your notebook is delivered with a set of external speakers. If your notebook is not delivered with external speakers, you can always connect other external speakers.
Page 87: Connecting An External Microphone
Hardware Guide Connecting peripheral devices Troubleshooting sound My speakers are not producing sound If you have problems with the sound, check the printed Guide to Troubleshooting and Recovering your VAIO System and the VAIO-Link website (www.vaio-link.com). Connecting an external microphone If you need to use a sound input device, for example to chat on the internet, you need to plug in an external microphone.
Page 88: Connecting A Universal Serial Bus (Usb) Device
Hardware Guide Connecting a Universal Serial Bus (USB) device You can connect a USB device (for example, a mouse, floppy disk drive, keyboard, printer) to your computer. USB devices are hot plug and play devices. You do not need to shut down your computer prior to connecting these devices unless the manual supplied with the device states otherwise.
Page 89: Connecting A Usb Mouse
Hardware Guide Connecting a USB mouse To connect a USB mouse, proceed as follows: Choose the USB connector (1) you prefer to use. Plug the USB mouse cable (2) into the USB connector. You can use your USB mouse (3). The VAIO USB mouse software driver is preinstalled on your computer, therefore, you only need to plug the USB mouse into the USB connector and you can start working.
Page 90: Connecting A Usb Floppy Disk Drive
Hardware Guide Connecting a USB floppy disk drive As an optional extra, you can purchase a USB floppy disk drive and connect it to your computer. To connect a USB floppy disk drive, proceed as follows: Choose the USB connector you prefer to use. Plug the USB floppy disk drive cable into the USB connector.
Page 91 Hardware Guide Inserting a floppy disk To insert a floppy disk, proceed as follows: Hold the disk (1) with the label side facing up. Gently push the disk into the drive (2) until it clicks into place. Removing a floppy disk To remove a floppy disk, proceed as follows: When you have finished using the floppy disk, wait until the LED indicator (1) turns off and then press the eject button (2) to remove the disk.
Page 92: Troubleshooting Floppy Disks
Hardware Guide Troubleshooting floppy disks My USB floppy disk drive cannot write to a floppy disk If you have problems with the floppy disk drive, check the printed Guide to Troubleshooting and Recovering your VAIO System and the VAIO-Link website (www.vaio-link.com). The optional PCGA-UFD5/A (USB) floppy disk drive is not recognised as drive A To set the UFD5/A to A, proceed as follows : Turn the system power on and connect the UFD5/A.
Page 93: Connecting A Printer
Hardware Guide Connecting a printer You can connect a Windows-compatible printer to your computer to print documents. Connecting a printer using the USB connector You can connect a USB printer compatible with your version of Windows to your computer. To connect a printer using the USB connector, proceed as follows: Plug a USB printer cable (1) into one of the USB connectors (2) on your computer.
Page 94 Hardware Guide Connecting a printer using the printer connector To connect a printer using the printer connector, proceed as follows: Plug the printer cable (1) supplied with the printer into the printer connector (2) identified by the Plug the printer power cord (3) into an AC outlet. Turn off your computer and the printer, unplug the AC adapter and the power cord before connecting the printer.
Page 95: Connecting An I.link Device
Hardware Guide Connecting an i.LINK device Your computer includes an i.LINK (IEEE1394) connector, which you can use to connect to an i.LINK device such as a digital video camera recorder or to connect two VAIO notebooks in order to copy, delete or edit files. The i.LINK connector of your computer does not supply power to external devices generally powered by i.LINK connectors.
Page 96: Connecting A Digital Video Camera Recorder
Launch the DVgate Plus application. On Sony digital video cameras, connectors labelled DV Out, DV In/Out or i.LINK are i.LINK-compatible. The Sony digital video camera recorder is an example; your digital video camera recorder may need to be connected differently.
Page 97 Hardware Guide Connecting peripheral devices Troubleshooting i.LINK devices If you have problems with your i.LINK device, check the printed Guide to Troubleshooting and Recovering your VAIO System, the documentation delivered with the device, and the VAIO-Link website (www.vaio-link.com).
Page 98: Connecting To A Network (Lan)
Hardware Guide Connecting to a network (LAN) You can connect your computer to 10BASE-T/100BASE-TX and 1000BASE-T*-type networks via an Ethernet network cable. For the detailed settings and devices needed to connect to the network, consult your Network Administrator. Depending on your model. The default settings make your computer able to connect to the network.
Page 99: Upgrading Your Vaio Computer
Hardware Guide Upgrading your VAIO computer Your computer and memory modules use high precision components and electronic connectors technology. To avoid the invalidation of your guarantee by mishandling, it is recommended that: You contact your dealer to install a new memory module. You do not install it yourself, if you are not familiar with upgrading memory on a computer.
Page 100 Hardware Guide Electrostatic Discharge (ESD) can damage memory modules and other components. Install the memory Module only at an ESD workstation. If such a station is not available, do not work in a carpeted area, and do not handle materials that produce or hold static electricity (cellophane wrappers, for example).
Page 101: Removing And Installing A Memory Module
Hardware Guide Removing and installing a memory module There is one memory slot at the bottom of your notebook and one under the keyboard. To change or add a memory module, proceed as follows: Shut down your computer and disconnect all peripheral devices. Unplug the computer and remove the battery pack.
Page 102 Hardware Guide Unscrew the 2 screws next to the memory slot. Turn your computer around and lift the cover. Introduce a sharp object (such as a fine screwdriver) between the keys indicated on the picture (1) and push gently upwards. Upgrading your VAIO computer...
Page 103 Hardware Guide Lift the keyboard from the LCD display side and gently turn it over the touchpad. Be careful not to detach the cable when lifting the keyboard. 10 Touch a metal object (such as the connector panel on the back of your computer) to discharge static electricity. 11 Remove the memory module: Pull the tabs in the direction of the arrows (1).
Page 104 Hardware Guide Upgrading your VAIO computer 13 Install the memory module. Be careful not to touch the other components on the motherboard. Slide the memory module into the slot. Snap the connectors into place when the board is correctly seated.
Page 105 Hardware Guide Upgrading your VAIO computer 14 Gently replace the keyboard, then press it into your computer.
Page 106 Hardware Guide Upgrading your VAIO computer 15 Close the computer cover, then tighten the screws on the bottom of the computer. 16 Reinsert the battery and turn the computer on.
Page 107: Viewing The Amount Of Memory
To view the amount of memory, proceed as follows: Turn on the computer. Go to Sony Notebook Setup via the Start menu. The Sony Notebook Setup dialog box appears. In the About this Computer tab you can view the amount of system memory. If the additional memory does not appear, repeat the whole procedure and restart the computer.
Page 108: Getting Help
Hardware Guide Getting help This section describes how to get help and support if something goes wrong with your computer. Sony offers you many support options for your computer. Sony support options Please see the section Documentation pack your computer, as well as further sources of reference.
Page 109 Hardware Guide Getting help e-Support What is e-Support? You have searched our user guides and website (www.vaio-link.com) but have not found an answer to your question/issue? e-Support is the ideal solution for you! Our e-Support Web Portal is an interactive website on which you can submit any technical query you may have regarding your VAIO and receive answers from our dedicated support team.
Page 110 Hardware Guide Getting help Can I submit my questions at any time? Yes, you can submit your questions 24/7, but please keep in mind that our e-Support Team can only treat your queries from Monday till Friday between 8am and 6pm. Is there a cost involved for using e-Support? No, this is a complete free of charge service offered to all registered VAIO customers! How do I know when the e-Support Team has handled my query/case?
Page 111 Hardware Guide Precautions This section describes safety guidelines and precautions to help you protect your computer from potential damage. Please contact VAIO-Link if you need assistance. On handling the hard disk (page 111) On handling the LCD screen (page 111) On using the power source (page 112) On handling your computer...
Page 112: On Handling The Hard Disk
Hardware Guide On handling the hard disk The hard disk has a high storage density and reads or writes data in a short time. However, it can be easily damaged by mechanical vibration, shock or dust. Although the hard disk has the internal safety device to prevent losing data due to mechanical vibration, shock or dust, you should be careful when handling your computer.
Page 113: On Using The Power Source
Hardware Guide The LCD is manufactured using high-precision technology. You may, however, see tiny black points and/or bright points (red, blue, or green) that continuously appear on the LCD. This is a normal result of the manufacturing process and does not indicate a malfunction.
Page 114 Hardware Guide Do not place your computer in a location subject to: Heat sources, such as radiators or air ducts, Direct sunlight, Excessive dust, Moisture or rain, Mechanical vibration or shock, Strong magnets or speakers that are not magnetically shielded, Ambient temperature of more than 35ºC or less than 5ºC, High humidity.
Page 115: On Handling Floppy Disks
Hardware Guide On handling floppy disks Do not open the shutter manually or touch the surface of the floppy disk. Keep floppy disks away from magnets. Keep floppy disks away from direct sunlight and other sources of heat. Keep floppy disks away from any liquid. Do not let floppy disks get wet. When you are not using the floppy disk, always remove it from the floppy disk drive and use a storage case.
Page 116: On Using The Battery Pack
Hardware Guide Precautions If the disc is badly soiled, moisten a soft cloth with water, wring it out well, and use it to wipe the surface of the disc from the centre out. Wipe off any remaining moisture with a dry soft cloth. Never put stickers on discs.
Page 117: On Using Headphones
Hardware Guide On using headphones Road safety – Do not use headphones while driving, cycling, or operating any motorized vehicle. It may create a traffic hazard and is illegal in some areas. It can also be potentially dangerous to play loud music while walking, especially at pedestrian crossings.
Page 118 SonicStage Mastering Studio, Sony Notebook Setup, VAIO Edit Components, VAIO Launcher, VAIO Media, VAIO Power Management, VAIO Power Management Viewer, VAIO System Information, VAIO Zone, Memory Stick, the Memory Stick logo, VAIO and the VAIO logo are trademarks of Sony Corporation.
