Codonics Virtua 83C Series Technical Brief

Codonics Virtua
Ink Replacement
Overview
This document explains how to properly replace the ink
cartridges for the Codonics Virtua
Publisher 83C Series Recorder.
NOTE: It is strongly recommended that you keep spare
ink cartridges on site to ensure that there is no system
downtime if an ink cartridge must be replaced.
Replacing the Ink Cartridge
1. Open the front Cover.
CAUTION: Do not touch a patient while accessing
Virtua's internal components that are under the front
cover.
2. Press the Ink Cartridge Load button.
NOTE: Do not open the print head latch when replacing
an ink cartridge.
3. Press the colored tab on the back of the print head
that corresponds to the used ink cartridge. The ink
cartridge pops up slightly.
Medical Disc
®
4. Remove the used ink cartridge.
5. Remove the new ink cartridge from its packaging.
6. Remove the ink protective cap from the ink cartridge.
NOTE: Install the ink cartridge immediately after
removing the protective cap to prevent the ink from
drying out.
