Page 1
Ｆ1Ｈ－ＲＹＷ1K
Operation Instruction Manual
Thank you for purchasing this product.
In this manual, we have shown the important notice in
order for you to use the device just and the method of
handling this system.
In additional to you read this manual well before the
utilization, understanding well, and use.
After you read, in the place where it seen with it is seen
with anytime, please to be sure to keep.
ES1417 K0
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fenwal F1H-RYW1K
Summary of Contents for Fenwal F1H-RYW1K
- Page 1 Page 1 Ｆ1Ｈ－ＲＹＷ1K Operation Instruction Manual Thank you for purchasing this product. In this manual, we have shown the important notice in order for you to use the device just and the method of handling this system. In additional to you read this manual well before the utilization, understanding well, and use.
-
Page 2: Table Of Contents
Page Table of contents 1. Safety Instructions ..........................3 2. Name and Function of each section ......................4 3. Install ..............................5 4. Specification............................8 5. Maintenance and Inspection ........................ 10 6. Disposal ............................13 7. Support .............................. 13 ES1417 730110 K0... -
Page 3: Safety Instructions
Page Safety Instructions ･This smoke detector has the ability to transfer information outputs and alarm status indicators to detect smoke. ･Before the using, read this chapter and use correctly. ･The contents which it occurs when you handle erroneously are divided in two of “warning” and “caution”. This division states clearly the size and impendence of the harm and the damage. -
Page 4: Name And Function Of Each Section
Page Name and Function of each section Mounting Base Insert Terminal 1, 2 Insert Terminal 3, 4 Detector Smoke Air flow Power Supply & Signal output connector State Indication LED ・Normal supervision：10 seconds interval ・Alarm mode：1 seconds interval ・Trouble mode：Off (not blinking) Guide of installation ES1417 730110 K0... -
Page 5: Install
・誤った位置に取り付けると火災による煙を正常に感知できず、誤動作の Case it is not possible, please pass in the metallic conduit which the power line is 原因になります。 grounded. ・誤動作を防止する為に検知器を高電圧スイッチや大電流スイッチなどの ［モーターなどの動力線電気的ノイズ源からの隔離］ ノイズ源を近づけないで下さい。 モーターなどの動力線は検知器から 20cm 以上離して敷設して下さい。20cm 以上離す事ができない場合は、動力線を D 種接地（第 3 種接地）された金属 管の中に通して下さい。 F1H-RYW1K F1H-RYW1K ES1417 730110 K0... - Page 6 Page 2.2. Method of installation （1）Names of parts mounting base is as follows. （2）Please install a Mounting Base to “install holes” with two screws M3 which is more than 15mm length. ･Incorrect loading of the equipments can cause a malfunction, failure or drop. ･Tighten the screw in the specified torque range.
- Page 7 Page （4）Please insert the connector cable into the output connector. ・The connectors are polarized. Please make suitable polar insertion. And please ！ Warning ensure that no loose insert. Loose or Force inserts failure can cause a fire. ・Please do not pull the connector strongly. It causes damage. ・Output relay is PhotoMOS relay.
-
Page 8: Specification
Page Specification ： Photoelectric Smoke Detector Name ： F1H-RYW1K- xx xx x Type ①Sensitivity ②Type of Output ③Length of cable Standard setting F1H-RYW1K-R3BB2 Sensitivity 0.3%/m, Alarm Output B, Trouble Output B, Cable length 2m. ①Sensitivity：0.3%/m～0.9%/m,1%/m,2%/m,3%/m(Value = R3～R9、01,02,03) Standard Setting is 0.3%/m.(Value=R3) ②Type of Output：Type of Alarm &... - Page 9 Page ： Connector cable included. Connector Cable of Power supply & Connector：JST SHR－06V 6pin Output Cable：Temperature rating 80℃,Voltage rating 300V,AWG#28, UL1061 Length：Depend on Type of Product. Standard is 2m.. Connection Details Pin № & Color － Power Operating Voltage Blue White －...
-
Page 10: Maintenance And Inspection
Page 4. Maintenance and Inspection 4.1. Daily Inspection № Item Object Content Method Judgment Treatment Criteria Installation Common Securely locked? Move The detector must Retighten detector to installed screws check. securely. base with proper torque. Obstacle near the Check Obstacle must not Removed. - Page 11 Page 4.2. Periodic Inspection The items that must be inspected one or two times every 6 months to 1 year are listed below. When the equipment is moved or modified, or layout of the wiring is changed, also perform this inspection.
- Page 12 Page ･Under tightening can cause a drop, malfunction. ！ Caution ･Over tightening can cause a drop, malfunction due to damage to the screw or equipments and malfunction. ･Please use the dry cloth or wring the water out tightly cloth for the cleaning. ･After Cleaning, Do not leave a foreign substance such as sawdust or wiring debris on a detector.
-
Page 13: Disposal
This product is as general industrial waste disposal. Disposal methods are specific criteria depending on each municipality. 6. Support Please inquire about this product to Fenwal Controls of Japan Co., Ltd. Tokyo headquarters. Fenwal Controls of Japan Co., Ltd. 1-5-10 Iidabashi Chiyoda Tokyo, 102-0072 Japan...
