Summary of Contents for NATDIS CleanBox 600
- Page 1 CleanBox 600/800 Mounting and operating instructions...
-
Page 2: Table Of Contents
Index 1. Revision summary ............................3 2. Hazard markings and safety signs ........................ 3 3. Equipment information ........................... 4 3.1 Equipment purpose..........................4 3.2 Definition of UVC-disinfection ........................4 3.4 About the documentation ......................... 4 3.5 Declaration of conformity ......................... 5 4. -
Page 3: Revision Summary
1. Revision summary Revision Date Comments/ Changes 16-03-2021 Dokument oprettet Hazard markings and safety signs The following hazard markings are used on the equipment and have the following meaning:... -
Page 4: Equipment Information
3. Equipment information 3.1 Equipment purpose The UV equipment is constructed to treat all light-accessible surfaces in the selected area in a chosen timeframe and area. 3.2 Definition of UVC-disinfection: UVC unit is dimensioned to deliver a dose of (as per by agreement) J / m2 on all light-accessible surfaces after a full cycle of the time (by agreement). -
Page 5: Declaration Of Conformity
We declare hereby that the equipment, as described below, in its design and construction complies with the health and safety requirements specified in the EU Machinery Directive 2006/42 / EC. In the event of a change of the equipment, this statement will lose its validity. Producer: NATDIS ApS Brunbjerg 70 6100 Haderslev Description of the unit: UVC unit for surfaces –... -
Page 6: Equipment Overview
4. Equipment overview The UV-unit contains of: Defined on the order confirmation. 4.1 Environment for the equipment 4.1.1 Surface The installation must be placed on a flat surface without inclination and fastened according to the instructions. 4.1.2. Placement The equipment may only be used in places where the surface is level and can be securely fastened. 4.1.3 Temperature and humidity The equipment can be used in temperatures between 10-40°C and max. -
Page 7: Connecting And Using The Unit
4.2.1 Connecting and using the unit 1. Connect plug to 230V. 2. Door 1 (unclean side) can be opened by pressing the green button. 3. When door 1 closes, a cycle starts automatically, with both doors locked. 4. At the end of the cycle, door 2 can be opened (clean side) by pressing the green button. 5. -
Page 8: One-Time Injuries
5.2 About the risk using UVC: When using normal work clothes with full cover of skin and safety glasses, the risk of permanent damage from short-term exposure to UVC light is limited to the effect on the skin and the minimal risk of damage to the eyes. -
Page 9: Repeated Daily Dose Overruns
• Skin, severe redness like light to medium sunburn. In case of severe exceedance factor +10 Risk of: • Eyes, permanent damage, impaired vision Skin, Severe sunburn; 2nd degree combustion. • 5.3.2 Repeated daily dose overruns: • Eyes, permanent damage, impaired vision Skin, development of various types of skin cancer (presumed, not detected) •... - Page 10 approved recycling site, or at an approved recycling company. The system must not be disposed of with unsorted household waste. Use the local collection • points for the disposal of electrical and electronic components and ensure that all relevant regulations are observed. The system consists of the following parts and must be sorted accordingly: Iron.
-
Page 11: Service And Maintenance
6. Service and maintenance Gloves should comply with 2019-4121X. All service and maintenance must be performed without danger. System must be shut off and cooled down before service is performed. Access to bulb change or quartz glass change can be done by detaching lamps from fittings / clips. 6.1 Bulb change: 1. -
Page 12: Cleaning Of Uvc-Systems
Attention: Protect eyes and skin against UVC-light. Equipment supplied by NATDIS may only be cleaned when the system is switched off and in a safe condition. All work on UVC systems requires that the system is secured before work begins. -
Page 13: Dry Cleaning
7.3. Dry cleaning Dry cleaning includes a thorough vacuuming of the components. A vacuum cleaner equipped with a suitable filter for product and material residues must be used. Never wipe product dust off dry, and never use compressed air for dry cleaning, as product dust will not be removed via these methods;... -
Page 14: Cleaning Procedure And Inspection
7.4. Cleaning procedure and inspection The cleaning procedure must ensure efficient daily operation. 1. Clean gloves must be worn. 2. Cleaning is performed at least once a month, or according to requirements. 3. UV-equipment is cooled down and ready for cleaning. a.
