STEP1
Place base on flat surface.
STEP2
Place back frame on rear,
STEP3
Insert sides
STEP 4
Insert top
STEP5
Place front frame on,
Then screw Front and back frame with m5 screws
STEP 6
Mount upright set (A) to matching holes using m6 cage nuts set.
STEP 7
Insert front door using Ipin.
Assembly Instructions
Visual Instructions Below
Advertisement
Table of Contents
Related Manuals for Interactive US2000-W2B
Summary of Contents for Interactive US2000-W2B
- Page 1 Assembly Instructions STEP1 Place base on flat surface. STEP2 Place back frame on rear, STEP3 Insert sides STEP 4 Insert top STEP5 Place front frame on, Then screw Front and back frame with m5 screws STEP 6 Mount upright set (A) to matching holes using m6 cage nuts set. STEP 7 Insert front door using Ipin.
- Page 2 3D – Assembled Internal...
- Page 3 3D – Assembled External...
- Page 4 2D – Dimensions Design illustrative purposes only, may vary based on product & design Sides...
- Page 5 *Should you find that the door pin does not fit due to the powder coating, this is perfectly normal and requires minimal corrective effort. Step 1 – Inspect pin on the door Step 2- Clean Please use a Flat nose Pliers or similar tool to remove the extra powder coating from pin, This is achieved by gripping the pin and rotating in a circular motion,...
- Page 6 The powder should come off with ease and the metal on the pin should now be visible. Well done, the door will now fit!
- Page 7 Please note the cabinets have been strictly engineered as follows US2000-W2B = 2x US2000 Pylontech Batteries (Wall Mount) US2000-2B = 2x US2000 Pylontech Batteries US2000-4B = 4x US2000 Pylontech Batteries...
