I n s p e c t i o n L i g h t
P a r t s L i s t
Frame Structure
B 2 - 9/16" x 3" Bolts
C 3 - Light Housing
D 8 - 5/16" x 2" Bolts, Washers and 4
Locking Nuts
E 4 - 5/16" Hand Knobs
F 4 - Wheels w/ Locking Washers and Nuts
(2 Wheels are locking wheels)
G 4 - End Caps
D
F
WARNING
The Inspection Light should be inspected regularly for damage. Do not use if any cracks in metal or
welds are present.
2 5 4 5 M i l l e n i u m D r. ~ E l g i n , I L . 6 0 1 2 4 ( 8 0 0 ) 3 8 2 - 1 2 0 0
4 0 4 8 - C h a m p
Frame Straightening Equipment Inc.
E
Read all assembly instructions completely before attempting to assemble unit.
Improper assembly could result in damage to Inspection Light or injury to user.
Auto Body Toolmart
Champ Frame Straightening Equipment, Inc.
w w w. a u t o b o d y t o o l m a r t . c o m
C
G
Made In USA
A
B
Advertisement
Related Manuals for Champ 4048
Summary of Contents for Champ 4048
- Page 1 Auto Body Toolmart Champ Frame Straightening Equipment, Inc. 2 5 4 5 M i l l e n i u m D r. ~ E l g i n , I L . 6 0 1 2 4 ( 8 0 0 ) 3 8 2 - 1 2 0 0...
- Page 2 Attach straight bar of the Frame Structure Fully tighten 3” bolt (B) to straight bar of (A) with 3” bolt (B) the Frame Structure (A). Repeat step 1 and 2 for other side of Frame Structure (A) straight bar. Slide 2” bolt (D) through hole on bracket Place protruding 2”...
- Page 3 Auto Body Toolmart Champ Frame Straightening Equipment, Inc. 2 5 4 5 M i l l e n i u m D r. ~ E l g i n , I L . 6 0 1 2 4 ( 8 0 0 ) 3 8 2 - 1 2 0 0 w w w.
