HUTTON Apex Shed Assembly Instructions

List of parts in fixings
1 x Roll of Felt (10m)
12 x 40mm Galvanised Nails
48 x 70mm Green Screws
26 x 50mm Green Screws
12 x 30mm Wire Nails
1 x Perspex Panel
100 x 15mm Felt Nails
14 x 60 mm Screws
PLEASE NOTE THERE MAY BE MORE SCREWS THAN REQUIRED
With all buildings, it is important to provide a firm level base before assembling your shed.
If a concrete base is being used we recommend this does not extend beyond the dimensions of
the shed to stop water falling from the roof and collecting on the concrete base. This can be
avoided by making the base for this shed 2400mm x 1800mm.
Church Lane, Northwood Green, Westbury-on-Severn, Gloucestershire GL14 1ND www.svw2000.co.uk/hutton
Tel: 01452 762089
Assembly Instructions
pack---
1. Place the floor section on the base you have prepared
and fix the back panel to one side panel screwing through
the vertical battens of the back panel into the battens on
the side panel using three screws. Repeat when fitting the
other side panel.
2. Fix the front panel (with door) to the two side panels as
in part 1 using screws provided. After all the panels are
fitted together, make sure it is all square and the cladding
overlaps the floor.
3. Place one roof panel on to the top of the shed. The
batten will fit into a central recess on the front and rear
panels. Repeat for the other panel. Then screw into place
using seven screws into each roof panel. Once the roof is
screwed into place, fix the panels to the floor section. Use
three screws for each side panel and two screws each for
the front and back panels.
Hutton Garden and Landscaping Products
Fax: 01452 760993
8' x 6'/6' x 4' – Apex Shed

Handy Tip for good shed maintenance

Keep the areas surrounding your shed clear of any grass or
vegetation including, pruning any trees overhead.
