Chapter 1 – Introduction 1.1 Welcome Thank you for choosing Waves! In order to get the most out of your new Waves plugin, please take a moment to read this user guide. To install software and manage your licenses, you need to have a free Waves account.
1.5 Components WaveShell technology enables us to split Waves processors into smaller plug-ins, which we call components. Having a choice of components for a particular processor gives you the flexibility to choose the configuration best suited to your material.
Shape tonality and dynamics using the Mid, Treble, and Compress controls. • After setting all parameters, check to make sure the Sensitivity LED indicates proper levels. If it indicates excessive levels, make the necessary adjustments. Waves Eddie Kramer Guitar Channel User Guide - 5 -...
Please note: Changing Types will reset all controls to their initial values. METER Switch toggles meter display between input and output levels. Default: Output METER displays input or output levels. Range: -24dBFS – 0dBFS Waves Eddie Kramer Guitar Channel User Guide - 7 -...
Page 8
Range: Green (good), Yellow (optimal), Red (very hot) COMPRESS controls dynamics. Range: Min (0) - Max (100), in 0.1 steps Default: 50 TREBLE 1 controls high frequencies. Range: 1 - 5 (in steps of 1) Default: 2 Waves Eddie Kramer Guitar Channel User Guide - 8 -...
Page 9
Range: Min (0) - Max (100), in 0.1 steps Default: 50 VERB MIX controls the relative level of the reverb. Range: Min (0) - Max (100), in 0.1 steps Default: 80 Waves Eddie Kramer Guitar Channel User Guide - 9 -...
Page 10
DLY controls delay characteristics. Range: 50 – 500 (in steps of 1) Default: 138 DLY MIX controls the amount of audible delay. Range: Min (0) - Max (100), in 0.1 steps Default: 80 Waves Eddie Kramer Guitar Channel User Guide - 10 -...
Page 11
COMPRESS controls dynamics. Range: Min (0) - Max (100), in 0.1 steps Default: 32.7 TREBLE 2 controls high frequency range. Range: Min (0) - Max (100), in 0.1 steps Default: 33.3 Waves Eddie Kramer Guitar Channel User Guide - 11 -...
Page 12
Range: Min (0) - Max (100), in 0.1 steps Default: 50 VERB MIX controls the amount of reverb sent to the effect. Range: Min (0) - Max (100), in 0.1 steps Default: 80 Waves Eddie Kramer Guitar Channel User Guide - 12 -...
Page 13
DLY controls delay characteristics. Range: 50-500 (in steps of 1) Default: 138 DLY MIX controls the amount of audible delay. Range: Min (0) - Max (100), in 0.1 steps Default: 80 Waves Eddie Kramer Guitar Channel User Guide - 13 -...
Page 14
COMPRESS controls dynamics. Range: Min (0) - Max (100), in 0.1 steps Default: 50 TREBLE 2 controls high frequencies. Range: Min (0) - Max (100), in 0.1 steps Default: 38.9 Waves Eddie Kramer Guitar Channel User Guide - 14 -...
Page 15
Range: Min (0) - Max (100), in 0.1 steps Default: 60.5 DEPTH controls the depth of the flange effect. Range: Min (0) - Max (100), in 0.1 steps Default: 16.2 Waves Eddie Kramer Guitar Channel User Guide - 15 -...
Page 16
DLY controls delay characteristics. Range: 50-500 (in steps of 1) Default: 138 DLY MIX controls the amount of audible delay. Range: Min (0) - Max (100), in 0.1 steps Default: 80 Waves Eddie Kramer Guitar Channel User Guide - 16 -...
Use the bar at the top of the plugin to save and load presets, compare settings, undo and redo steps, and resize the plugin. To learn more, click the icon at the upper-right corner of the window and open the WaveSystem Guide. Waves Eddie Kramer Guitar Channel User Guide - 17 -...
