Summary of Contents for BLUE CHIP Adapt Pro Elite 9200
- Page 2 Product Symbol Description SYMBOLS DESCRIPTION POWER ON POWER OFF ATTENTION DOUBLE ISOLATION “BF” SYMBOL, INDICATE THIS PRODUCT IS ACCORDING TO THE DEGREE OF PROTECTION AGAINST ELECTRIC SHOCK FOR TYPE BF EQUIPMENT, APPLIED PART:MATTRESS CAUTION, READ THE INSTRUTION BEFORE USE AWAY FROM THE FLAME IP21 WATER AND DUST PROTECTION CLASSIFICAITON FUSE SPECIFICATION DISPOSAL OF ELECTRICAL & ELECTRONIC EQUIPMENT (WEEE): THIS PRODUCT SHOULD BE HANDED OVER TO AN APPLICABLE COLLECTION POINT FOR THE RECYCLING OF ELECTRICAL AND ELECTRONIC EQUIPMENT. UL CERTIFICATION LOGO (COMPLIACE WITH IEC60601-1) WITH RESPECT TO ELECTRICAL SHOCK, FIRE AND MECHANICAL HAZARDS ONLY IN ACCORDANCE WITH IEC60601-1. CB CERTIFICATION LOGO CE CERTIFICATION LOGO...
- Page 3 Contents INTRODUCTION ........................3 INTENDED USE ........................3 PRODUCT DESCRIPTION ......................3 PRODUCT INSTALLATION GUIDE ..................... 4 PANEL DISPLAY AND OPERATION GUIDE ................6 CLEANING ..........................11 STORAGE ..........................12 MAINTENANCE ........................13 THE DISPOSAL OF AIR MATTRESS .......... E rror! Bookmark not defined. TROUBLESHOOTING……………….…………………………………………………………………..………15 TROUBLESHOOTING……………….…………………………………………………………………..………15 10. TROUBLESHOOTING ......................14 TECHNICAL DATA… .……………….…………………………………………………………………..………16 TECHNICAL DATA… .……………….…………………………………………………………………..………16 11. TECHNICAL DATA ........................15...
- Page 5 PRODUCT INSTALLATION GUIDE 1. Unpack the box to inspect all items for any damage that may have occurred during shipping. If there is any damage, please contact your dealer immediately for assistance. 2. Place the mattress on top of the bed frame. The foot symbol on both sides of the mattress indicates location of the foot end. Air Mattress Patient Head Model No. (Inside the cover) CPR Pump Unit Hose Connector 3. Secure the mattress onto the bed frame by using the elastic straps or Elastic binding side straps. Strap Binding Side Strap 4. Ensure the CPR valve is in CLOSED CPR Position Indicator position before turning on the power. 5. Position the Pump by its spring loaded hanger brackets over footboard of the bed. The elastic hanger brackets will self-adjust onto the footboard tightly. 6. Remove the Transport Cap of the hose connector and connect the hose connector to the Pump unit. Firmly push the hose connector into position and a “clicking” sound will secure the connection.
- Page 11 the hose from the Pump to speed up the air release. the hose from the Pump to speed up the air release. the hose from the Pump to speed up the air release. the hose from the Pump to speed up the air release. from the Pump to speed up the air release. 5.2.3 Audiovisual Alarm l Power Failure – When an electrical shortage occurs or power cord is unpluged without turning off the Pump or is pressed (intentionally or unintentionally), the “Power Failure” indicator will light up along with buzzer and will last 20 minutes. NOTE: When the Pump has not been used for more than 3 months, the Pump may need 6 hours or more of operating time for the alarms to function properly. l Low Pressure –When an abnormal low pressure occurs in body section for 2.5 minutes after the pressure is below the abnormal pressure threshold, the "Low Pressure" indicator will flash and beep. Should the situation not resolved and fault conditions continue, the alarm will resume. l Service (Malfunction) –When fault conditions occur, the "Service" indicator will light up along with buzzer. Note: Refer to Table 2 for Warning Code Reference Table if error code appears on the display or refer to 10. TROUBLESHOOTING. 5.2.4 Alarm Mute l When alarms are triggered, both LED light and buzzer will turn on to warn the patient and caregiver. By pressing the button, it will temporarily mute the buzzer so the caregiver may check for possible causes. Should the situation not resolved and fault conditions continue, the alarm will resume. Refer to 10. TROUBLESHOOTING for diagnosis. l During “power failure”, pressing “alarm mute” will cease all buzzers and indicators and turn off the system. l During “low pressure alarm” if the pressure resumes back to normal then the low pressure alarm will stop. l When more than one alarm is triggered, the alarm will be performed according to priority level. Refer to Table 2 Warning Code Reference Table for priority level.
- Page 15 TROUBLESHOOTING PROBLEM SOLUTION The mattress is not able to Check if the mattress model (model no. located inside the cover by Check the ma5ress model (model no. located inside the cover Check the ma5ress model (model no. located inside the cover Check the ma5ress model (model no. located inside the cover Check the ma5ress model (model no. located inside the cover by the foot end) Make sure that connector hoses line up with by the foot end) Make sure that connector hoses line up with by the foot end) Make sure that connector hoses line up with by the foot end) Make sure that connector hoses line up with connect with the Pump the foot end) xxAAAxxx matches with the Pump model xxBBB-xxx. the pump. If not, please contact Blue Chip. the pump. If not, please contact Blue Chip. the pump. If not, please contact Blue Chip. the pump. If not, please contact Blue Chip. The AAA should be the same as BBB. If not, please contact with the agent or distributor. Check if the Transport Cap is removed and make sure the connector is not broken. The Pump is showing no Check if the plug is connected to the mains supply. Check if plug is locked into pump and plugged into power outlet Check if plug is locked into pump and plugged into power outlet Check if plug is locked into pump and plugged into power outlet Check if plug is locked into pump and plugged into power outlet indications of working Check if the power switch is switched to ON position (press Check if there is any blown fuse. Power failure alarm failed If the Pump is in operation but failed to trigger the power failure alarm during power off. Charge the Pump for 6 hours or more of operating time and if the power failure still not works then please contact the dealer or agent for further investigation. The low pressure light is Check if the CPR is at CLOSE position constantly flashing and the Check if the connection between air tubes to Pump unit is tightly alarm is sounded secured.
