GEDA 01181 Instruction Manual

Transport trailer for geda 500 z / 500 z duo / 500 z/zp 300 z/zp / 300 z / geda 200 z / 300 z / 300 zg
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction manual
Transport trailer
Item No.: 01181
For GEDA 500 Z / 500 Z Duo / 500 Z/ZP 300
Z/ZP / 300 Z
Item No.: 02520
For GEDA 200 Z / 300 Z / 300 ZG
Original operating manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 01181 and is the answer not in the manual?

Questions and answers

Summary of Contents for GEDA 01181

  • Page 1 Instruction manual Transport trailer Item No.: 01181 For GEDA 500 Z / 500 Z Duo / 500 Z/ZP 300 Z/ZP / 300 Z Item No.: 02520 For GEDA 200 Z / 300 Z / 300 ZG Original operating manual...

  • Page 3: Table Of Contents

    GEDA 300 Z/ZP ....................21 RANSPORT OF GEDA 300 Z..............23 RANSPORT OF CONSTRUCTION HOIST 9.4.1 Mounting the adapter frame for GEDA 300 Z ............... 23 9.4.2 Loading the transport platform ....................24 9.4.3 Unloading the transport platform ..................27 TRAILER ITEM NO.: 02520 .......................
  • Page 4  Identification data GEDA Transport Trailer Instruction Manual 4 / 36 BL135GB Issue 01/2017...

  • Page 5: Identification Data

    Coupling ring Passenger car 01183 Coupling ring Truck Item No. Name Usable 02520 Trailer Transport of GEDA 200 Z / 300 / 300 ZG 02521 Coupling ring Passenger car 02522 Coupling ring Truck Manufacturer GEDA Dechentreiter GmbH & Co. KG...

  • Page 6: Ordering Spare Parts

    Spare parts are ordered exclusively through the manufacturer/representative. Only original GEDA spare parts may be used. Only original GEDA spare parts guarantee full function as well as safety and reliability. The use of non-approved spare parts releases GEDA from any liability for damage arising as a consequence of any such use.

  • Page 7: Tightening Torques For General Screw Connections

     GEDA Transport Trailer Technical data Tightening torques for general screw connections 2.2.1 Tightening torques for machine screw connections All details refer to screws in strength class 8.8 Tightening torque Tightening torque 25 Nm M 16 210 Nm M 10...

  • Page 8: Tests

     Tests GEDA Transport Trailer Tests The following checks have been carried out before delivery: • Internal production checks. • Opinion by TÜV SÜD to obtain EU operating license. Images The images used possibly only constitute schematic diagrams. The fundamental function and operation are not affected by this.

  • Page 9: Safety Information

    • Loading / unloading and transport of GEDA 200 Z / 300 Z 300 ZG. Trailer Item No.: 01181 • Loading / unloading and transport of GEDA 500 Z / 500 Z Duo / 500 Z/ZP / 300 Z/ZP / 300 Z.

  • Page 10: Hazardousness Of Trailers

     Safety information GEDA Transport Trailer Hazardousness of trailers The trailers have been designed and manufactured according to the state of the art and subjected to safety check and final inspection before delivery. Nevertheless, personal hazards or material damage may result if operated incorrectly, used improperly, used without due care and attention, insufficient maintenance or if components fail.

  • Page 11: Duties Of The Operating Company

     GEDA Transport Trailer Duties of the operating company Duties of the operating company Duty to provide training/qualifications The operating company clearly defines the responsibilities of the personnel. The operating company is obliged to train all persons authorised to use the trailer in the correct handling of the trailer before using it for the first time, according to the respective area of activity and responsibility and using practical exercises.

  • Page 12: Safety Notices To Be Complied With, General

     Safety notices to be complied with, general GEDA Transport Trailer Safety notices to be complied with, general • Starting or operating the trailer without having read the manual beforehand is prohibited. This manual shall be kept accessible for future use.
  • Page 13 − Load capacity is observed − The min. / max. support load is observed. − If the parking brake is pulled, the trailer (Item No.: 01181) may still roll backwards for approx. 25 cm until the max. braking force has been reached.

  • Page 14: Trailer Item No.: 01181

     Trailer Item No.: 01181 GEDA Transport Trailer Trailer Item No.: 01181 Preparing the trailer for loading / unloading 9.1.1 Pulling / releasing the parking brake Pulling the parking brake:  Hold the parking brake by the handle. The dead point can be clearly felt.

  • Page 15: Hooking Up The Contact Breaking Cable

     GEDA Transport Trailer Trailer Item No.: 01181 9.1.3 Hooking up the contact breaking cable  Make sure to follow the national regulations for fastening the contact breaking cable  Sling the contact breaking cable around the neck of the ball.

  • Page 16: Transport Of Geda 500 Z, 500 Z Duo And 500 Z/Zp

     Trailer Item No.: 01181 GEDA Transport Trailer Transport of GEDA 500 Z, 500 Z Duo and 500 Z/ZP  A mast section must be mounted on the base mast to load or unload the base unit.  Mounting a mast section onto the base mast. Refer to the machine assembly manual.
  • Page 17  GEDA Transport Trailer Trailer Item No.: 01181  Put the protection grid underneath the hoist car aside.  Unhook the springs on the protection grid underneath the hoist car (3) on the opposite side.  Pay attention when mounting the protection grid underneath the hoist car to the platform that the springs are hooked again into the fifth lattice section (counting from the frame).
  • Page 18  Trailer Item No.: 01181 GEDA Transport Trailer  Secure the trailer by tightening the parking brake and putting the wheel chocks underneath.  Press the DOWN (8) button until the platform rests on the trailer.  Close the interlocking (6) and secure the transport platform with the screw.

  • Page 19: Checks Before Driving Off

     GEDA Transport Trailer Trailer Item No.: 01181 Moving the foot section up CAUTION Damage of the trailer / foot section possible. Release the DOWN (8) button immediately when the foot section rests against the trailer.  Press the DOWN (8) button until the foot section rests against the buffers of the trailer.

  • Page 20: Unloading The Transport Platform

     Trailer Item No.: 01181 GEDA Transport Trailer 9.2.2 Unloading the transport platform  Lower the support wheel.  Pull the parking brake.  Detach the trailer from the tractor.  Release the parking brake.  Push the trailer to the set-up site.

  • Page 21: Transport Of Geda 300 Z/Zp

    Transport Trailer Trailer Item No.: 01181 Transport of GEDA 300 Z/ZP To load and transport the transport platform GEDA 300 Z/ZP with the trailer, the adapter frame (Item No.: 39418) must first be mounted and the license plate holder swivelled aside.
  • Page 22 Loading is performed as outlined in chapter 9.2.  Swivel the license plate holder (12) or the trailer back and lock it after loading.  The trailer is now ready to transport the GEDA 300 Z/ZP.  Unloading is performed as outlined in chapter 9.2.2.

  • Page 23: Transport Of Construction Hoist Geda 300 Z

    Trailer Item No.: 01181 Transport of construction hoist GEDA 300 Z To load and transport the a construction hoist GEDA 300 Z with this trailer, the adapter frame (Item No.: 01173) must first be mounted and the license plate holder swivelled aside.

  • Page 24: Loading The Transport Platform

     Trailer Item No.: 01181 GEDA Transport Trailer  Mount the platform centring piece “Left” (16) and platform centring piece “Right” (17) on the trailer. Adjust the dimension from tip to tip of the platform centring pieces to 1445 mm.
  • Page 25  GEDA Transport Trailer Trailer Item No.: 01181  Fold up eye bolts of the mast  Align the trailer with the support wheel (5) horizontally.  Swivel the license plate holder toward the outside (see chapter 9.3).  Push the trailer under the platform and align it so that the platform comes to rest exactly on both platform supports (14/15) and platform centring pieces (16/17) of the trailer after lowering it.
  • Page 26  Trailer Item No.: 01181 GEDA Transport Trailer Moving the foot section up CAUTION Damage of the trailer / foot section possible. Release the DOWN (8) button immediately when the foot section rests against the trailer. Press the DOWN (8) button until the...

  • Page 27: Unloading The Transport Platform

     GEDA Transport Trailer Trailer Item No.: 01181 9.4.3 Unloading the transport platform  Lower the support wheel (5).  Pull the parking brake.  Detach the trailer from the tractor.  Release the parking brake.  Push the trailer to the set-up site.

  • Page 28: Trailer Item No.: 02520

     Trailer Item No.: 02520 GEDA Transport Trailer Trailer Item No.: 02520 10.1 Loading a construction hoist  Place the platform on the trailer.  Turn the key switch (1) of the platform control to the operating position and remove the key.
  • Page 29  GEDA Transport Trailer Trailer Item No.: 02520 DANGER Danger to life Staying under the raised platform is prohibited.  Align the trailer with the support wheel (8) horizontally.  Open the locking device (6) of the guide (3) toward the rear.
  • Page 30  Trailer Item No.: 02520 GEDA Transport Trailer  Loosen the holding tubes (7) on the screw (7a).  Lift the holding tubes and turn them inside until they come to rest between the protective grating and the base plate of the platform.
  • Page 31  GEDA Transport Trailer Trailer Item No.: 02520 Moving the foot section up  Before moving up the foot section both spindles (9) must be turned down to prevent collision with the license plate holder or ground station switch box.

  • Page 32: Checks Before Driving Off

     Trailer Item No.: 02520 GEDA Transport Trailer 10.2 Checks before driving off • 4 mast sections each 2 metres mounted. • Mast protection shield pushed down. • Platform entries / exits closed and locked. • Base unit moved up.

  • Page 33: Fastenings For Mast Sections

     GEDA Transport Trailer Trailer Item No.: 02520 10.4 Fastenings for mast sections  When ordering a trailer Item No.: 02520 separately, the 4 fastenings for mounting the mast sections are enclosed. Mounting the fastenings  Insert the fastenings (1) in the corresponding holes of the platform.

  • Page 34: Maintenance / Inspections

    Axle (Trailers 01181 and 02520) Check axial play of the wheel hub bearing and adjust, if necessary Lighting system (Trailers 01181 and 02520) Check for functioning before each use. Tyres (Trailers 01181 and 02520) Check tyres before each use for damage, thread depth and tyre pressure.
  • Page 36 GEDA-Dechentreiter GmbH & Co. KG Mertinger Strasse 60 86663 Asbach-Bäumenheim Tel.: +49 (0)9 06 / 98 09-0 Fax: +49 (0)9 06 / 98 09-50 E-Mail: info@geda.de Web: www.geda.de BL135 GB Edition 01/2017...
