- Page 1 Add Device Setting Instruction Add/ Extend Hardware...
- Page 2 Outline Add New Device(DevicePort/ DevicePort I/O) Topology Simple Device Power and Ethernet Connection Configuration Diagram Connect new device to Gateway Gateway Interface Setting Add Serial Port Device Add DI/O Device Add AI Device ...
- Page 3 Add New Device(DevicePort/ DevicePort I/O) Topology Demonstration of adding new device to current solution Extended Devices Ethernet/EAZInet AI/AO DI/DO RS-232 Serial Port DI/O RS-422/485 EZR5001/EZR5002 DPAD02HTP EZR5231 Power(DC) DI/O AI Interface Device RS422,485 Interface Device Interface Device...
- Page 4 Simple Device Power and Ethernet Connection Configuration Diagram 2 port RJ-45 ethernet 10/100M Fast Ethernet 2 Pin Terminal Support Daisy Chain Support 12~24VDC Power Input DP/ DP I/O Configuration Demonstration Power (DC) Ethernet...
- Page 5 Connect new device(DP/ DP I/O) to Gateway If you want to connect new device to gateway, please search gateway IP in a browser and log in to EZG1200 setting page 1.Choose DevicePorts 3. Click 【Connect】 to connect new device and Gateway 2.
- Page 6 Gateway Interface Setting-Add Serial Port Device Activate the relation between device and IoT Central. Choose the corresponding serial port device and channel according to the real situation 2. Change to Interfaces page 1.Choose Interfaces...
- Page 7 In Interfaces page, pull down to find the new serial device and the corresponding channel(UART), and click 【Config】 Here we take digital meter for example. Choose DPAD02HTP, channel 1(UART), and click 【 Config 】 2. Click 【Config】 1.Choose the new device and the...
- Page 8 In the setting page, activate the relation between device and IoT Central, set the parameter, choose device model, and click apply Here we take Shihlin Electronic power meter for example to set the parameter 3. According to the device information to set the correct parameter 4.
- Page 9 Gateway Interface Setting-Add DI/O Device Activate the relation between device and IoT Central. Choose the corresponding DI/O device and channel according to the real situation 2. Change to Interfaces page 1.Choose Interfaces...
- Page 10 In Interfaces page, pull down to find the new DI device and the corresponding channel, and click 【Config】 Here we take signal light for example. Choose EZR5002 channel 1 (DI), and click 【 Config 】 1. Choose the new device and the corresponding channel(DI) 2.
- Page 11 In the setting page, activate the relation between device and IoT Central, set the parameter, choose device model, enable data update, and click apply Here we take signal light for example. DI is the button on the signal light, so choose button and enable data update 1.
- Page 12 In Interfaces page, pull down to find the new DO device and the corresponding channel, and click 【Config】 Here we take signal light for example. Choose EZR5002 channel 3 (DO), and click 【 Config 】 1. Choose the new device and the corresponding channel(DO) 2.
- Page 13 In the setting page, activate the relation between device and IoT Central, set the parameter, choose device model, and click apply Here we take signal light for example. DO is the signal lights, so choose LED *Please follow p.9~13 steps to finish other channel’s setting 1.
- Page 14 Gateway Interface Setting-Add AI Device Activate the relation between device and IoT Central. Choose the corresponding AI device and channel according to the real situation 2. Change to Interfaces page 1.Choose Interfaces...
- Page 15 In Interfaces page, pull down to find the new AI device and the corresponding channel, and click 【Config】 Here we take temperature and humidity sensor for example. Choose EZR5231 channel 1(AI), and click 【 Config 】 1. Choose the new device and the corresponding channel(AI) 2.
- Page 16 In the setting page, activate the relation between device and IoT Central, set the parameter, choose device model, and click apply Here we take temperature and humidity sensor for example. Please choose Temperature 4. Set the correct parameter according to the device specification 5.
- Page 17 Gateway Resource Setting To make IoT Central can read the data from the new device, you need to set Field Name in the Resource page 2. Change to Resource page 1.Choose Interfaces...
- Page 18 In Resources page, choose the device and corresponding channel that you want to modify its field name and click 【Config】 Here we take signal light button for example. You can find the device and corresponding channel via MAC information. Then click 【 Config 】 2.
- Page 19 In setting page, modify the Field Name content, click Apply Here we take signal light button for example. Fill in Button and click Apply 1. Modify Field Name 【Note】 You must set the same Field Name as the Telemetry column in IoT Central 2.
- Page 20 Set IoT Central Please refer the chapter Create Telemetry on Azure IoT Central in the original KIT user manual that you’ve purchased to continue your setting The following list is the default new device field name list： Central Type Interface Display Name Field Name Note...
- Page 21 Thanks...
