Assembly Instruction Triflex
Assembly - TRC.40 · TRC.60 · TRC.70 · TRC.100
CLICK!
1
Hold two pieces together at inner radius and move socket up against the ball´s wedged end
Separating - TRC.40
1
Bend Triflex
®
into its radius and twist apart, counter-clockwise
Separating - TRC.60 · TRC.70 · TRC.100
1
Insert screw driver into the opening of the socket from the top. Then twist apart, counter-clockwise.
Assembly instructions Version TRE and TRL
®
R - TRC
2
2
2
page 2.6/2.7
CLACK!
Triflex
®
R
2.5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for igus Triflex R - TRC
Summary of Contents for igus Triflex R - TRC
- Page 1 Triflex ® Assembly Instruction Triflex ® R - TRC Assembly - TRC.40 · TRC.60 · TRC.70 · TRC.100 CLACK! CLICK! Hold two pieces together at inner radius and move socket up against the ball´s wedged end Separating - TRC.40 Bend Triflex ®...
- Page 2 Triflex ® Assembly Instruction Triflex ® R - TRE Assembly - TRE.40 · TRE.60 · TRE.70 · TRE.100 (chain section exposed for the purpose of demonstration) CLICK! CLACK! Hold two pieces together at inner radius and move socket up against the ball´s wedged end. Push until a klicking sound indicates a secure fit of socket onto the ball.
- Page 3 Triflex ® Assembly Instruction Triflex ® R - TRL Assembly - TRL.40 · TRL.60 · TRL.70 · TRL.100 CLACK! Very easy to assemble - simply press the ball into the socket, ready! Separating - TRL.40 · TRL.60 · TRL.70 · TRL.100 Just twist the ball slightly to remove it from its socket Filling - TRL.40 ·...
