OPERATOR'S
MANUAL
WALK BEHIND LAWN MOWER
MODEL
CAUTION: Before any use, read carefully the user manual which has been
purposely drawn up to provide you with all the necessary information for
proper use, in compliance with basic safety requirements.
Symbols Explanation:
KCL21SDP
KCL21SP
KCL21P
KCL21SD
KCL21S
KCL21
KCL17S
Page 1 of 14
KCL19SDP
KCL19SP
KCL19P
KCL19SD
KCL19S
KCL19
KCL17
Advertisement
Table of Contents
Summary of Contents for ManoMano KCL21SDP
- Page 1 OPERATOR’S MANUAL WALK BEHIND LAWN MOWER MODEL KCL21SDP KCL19SDP KCL21SP KCL19SP KCL21P KCL19P KCL21SD KCL19SD KCL21S KCL19S KCL21 KCL19 KCL17S KCL17 CAUTION: Before any use, read carefully the user manual which has been purposely drawn up to provide you with all the necessary information for proper use, in compliance with basic safety requirements.
- Page 2 B1: Read the manual carefully before use. B2: Keep other people well away from the working area. B3: Risk of hand and feet injuries. When repairing, please take out the spark plug wire, then repair it according to the operational manual. B4: Emission of toxic gas, do not use the mower in a closed area or not well ventilated.
- Page 3 Technical data: KCL21SDP KCL19SDP KCL21SP KCL19SP Drive type Self-propelled Drive type Self-propelled Height adjustment Central adjustment Height adjustment Central adjustment Cutting heights 30-80mm/7grades Cutting heights 30-80mm/7grades Catcher TYPE Rear Bag Collection Catcher TYPE Rear Bag Collection Catcher volume Catcher volume...
- Page 4 IMPORTANT: Read with care the security requirements included in the engine manual before the first use of the engine. Blade engagement lever Self-propelled lever Control handle Gasoline engine Side discharge cover Height adjustment assembly Grass bag Including A: Spark plug wrench Page 4 of 14...
- Page 5 IMPORTANT: Read with care the security requirements included in the engine manual before the first use of the engine. Control handle Blade engagement lever Self-propelled lever Gasoline engine Height adjustment assembly Grass bag Including A: Spark plug wrench Page 5 of 14...
- Page 6 1 - SET UP OF THE MOWER (1) Pull the handle in position and tighten plastic nuts. The mower installation is completed comfortably and easy to handle. (2) Adjust the handle to the height you want. (3) Fix the cables with the plastic collars. (4) Introduce the rope of the recoil starter handle on its support rope guide.
-
Page 7: Cutting Height Ajustments
2 - ASSEMBLY OF THE GRASS CATCHER 1. To fit: Raise the rear cover and hitch the grass bag on rear of mower. 2. To remove: grasp and lift the rear cover, remove grass bag. 3 - CUTTING HEIGHT AJUSTMENTS Apply outward pressure to disengage lever from rack, move lever forward or backward to adjust height. -
Page 8: Operation
4 - SAFETY PRECAUTIONS a) Always use the lawnmower with the grass catcher or the deflector in position. b) Stop the engine before emptying the grass catcher or before you change the cutting height. c) While the engine is running, never introduce your hands or feet under the lawnmower or under the grass ejection area. - Page 9 6 - SECURITY MEASURESURES Safety instructions 1.1 Training 1.1.1 Read the instructions carefully. Be familiar with the controls and the proper use of the equipment; 1.1.2 Never allow children or people unfamiliar with these instructions to use the lawn mower. Local regulations can restrict the age of the operator;...
- Page 10 1.3.14 Start the engine carefully according to instructions and with feet well away from the blade(s); 1.3.15 Do not tilt the lawn mower when starting the engine; 1.3.16 Do not start the engine when standing in front of the discharge chute; 1.3.17 Do not put hands or feet near or under rotating parts.
-
Page 11: Maintenance, Cleaning And Storage
7 - MAINTENANCE, CLEANING AND STORAGE 7.1 Maintenance WARNING: stop the engine and unplug the spark plug before any repairing or maintenance operations. Refer to separate engine manual for engine maintenance instructions. Stop the engine and unplug the spark plug before any repairing or maintenance operations. For four strokes engine read carefully the maintenance engine manual. -
Page 12: Stroage Instructions
7.2 CLEANING CAUTION: Do not hose engine. Water can damage engine or contaminate the fuel system. 1. Wipe deck with dry cloth. 2. Hose under deck by tilting the mower so that the spark plug is up. 3. Refer to separate engine manual for engine cleaning instructions. 7.3 STROAGE INSTRUCTIONS The following steps should be taken to prepare lawn mower for storage. -
Page 13: Troubleshooting
8 - TROUBLE SHOOTING PROBLEM PROBABLE CAUSE CORRECTIVE ACTION Engine does not Throttle chock not in the correct Move throttle chock to correct position. start. position for the prevailing conditions. Fuel tank is empty. Fill tank with fuel: refer to ENGINE OWNERS MANUAL. -
Page 14: Warranty Conditions
9- WARRANTY WARRANTY CONDITIONS: The manufacturer warrants the product 12months from the date of purchasing, from all fabrication faults. The lawnmowers that are used in a professional or locative way are warranted 3months. The warranty cannot be claimed in case of normal wear. The manufacturer will replace at his expense the spare parts, which would be classified as defective by him or an agreed station service.
