Summary of Contents for FSN WUH4000
- Page 1 Wireless Imaging System Instructions for Use WUH4000 Model: FHD-1TX-1RX Part Numbers: FHD-1TX-2RX WUH4000 WUH4000-D WUH4060 Model: Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely. English...
-
Page 2: Table Of Contents
Table of Contents Product Description / Intended Use WUH4000 ... 3 Product Description / Intended Use WUH4060 ... 4 Symbol Defi nitions ......5 Indications for Use, Contraindications . -
Page 3: Product Description / Intended Use Wuh4000
Both components are mains powered (100 – 240 V). The WUH4000 wireless device is a non-sterile reusable device not intended for use in the sterile fi eld. Caution: Federal (U.S.A.) law restricts this device to sale by or on the order of a physician. -
Page 4: Product Description / Intended Use Wuh4060
Product Description / Intended Use WUH4060 Wireless Imaging System Carefully read all instructions prior to use. Observe all contraindications, warnings and precautions noted in these directions. Failure to do so may result in patient complications. Wireless Connection AV Source Transmitter (TX) Receiver (RX) Destination Device Description... -
Page 5: Symbol Defi Nitions
Symbol Defi nitions The following symbols appear on the product, its labeling, or the product packing. Each symbol carries a special defi nition, as defi ned below: Consult accompanying Do not disassemble Power adapter documents Non-ionizing electro- Indicates top-bottom Korea Certifi cation magnetic radiation direction DC Power control... -
Page 6: Indications For Use, Contraindications
Indications for Use The Wireless Imaging System consists of a wireless transmitter and a receiver which delivers high quality audio and video signals from sources such as endoscopy or laparoscopy camera systems, or other video sources over radio-frequency to display images during general surgical procedures. -
Page 7: Warnings, Precautions
Returned Product After troubleshooting, if problems persist, disinfect the product and return it to FSN using the original packaging. Include the accessories that came with the product in the return shipment. Please enclose a brief explanation of the malfunction. - Page 8 Precautions Always treat the product with care and keep it in a clean and dust-free environment. Do not expose the product to liquid, moisture, or humidity. Do not use your product in temperatures above 40°C when unit is operational. Do not drop or throw the product. Accessories Use only accessories specifi ed by the manufacturer, or sold with the apparatus.
-
Page 9: Wuh4000
This system complies to the above standards only when used with the supplied medical grade power supply. Wireless Imaging System Power Supply WUH4000 Adapter Technology ATM036T-P050 WUH4060 CUI INC SDM36-12-U-P5 Caution: Make sure the power cord is the correct type that is required in your area. -
Page 10: Fcc Information
Any serious incident that has occurred in relation to the device should be reported to the manu- facturer and the competent authority of the Member State in which the user and/or patient is established. Contact your local FSN Medical Technologies sales representative for information on changes and new products. - Page 11 The FSN wireless imaging system is intended to be used as a pair (transmitter and receiver) to redundantly display video where needed. The wireless device is a non-sterile, reusable device, not intended for use in the sterile fi eld. FCC Appendix Manufacturer’s declaration - electromagnetic emission...
- Page 12 This WIRELESS IMAGE system is intended for use in the electromagnetic environment specifi ed below. The customer or the user of this WIRELESS IMAGE system should assure that it is used in such an environment. Immunity test IEC 60601 Test Compliance level Electromagnetic environment-guidance level...
- Page 13 Recommended separation distances between portable and mobile RF communications equipment and the WIRELESS IMAGE system. The WIRELESS IMAGE system is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The user of the WIRELESS IMAGE system can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equip- ment (transmitters) and the WIRELESS IMAGE system as recommended below, according to the maximum output power of the communications equipment.
- Page 14 Guidance and manufacturer’s declaration - electromagnetic immunity This WIRELESS IMAGE system is intended for use in the electromagnetic environment specifi ed below. The customer or the user of this WIRELESS IMAGE system should assure that it is used in such an environment. Immunity test IEC 60601 Test level Compliance level Electromagnetic environment-guidance...
- Page 15 FCC Caution: Any changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
-
Page 16: Maintenance Of Quality Service
60GHz band and can support up to a maximum of 4 receivers within that room. As a result of these design considerations, it is not possible for one WUH4000 System to interfere with another WUH4000 System. - Page 17 The following minimum distances have been tested to demonstrate noninterference between the listed devices and the WUH4000. If the WUH4000 is thought to be causing or receiving inter- ference with the following devices, then move the devices away from each other, maintaining at...
-
Page 18: Package Contents
Package Contents Part No.: FHD-1TX-1RX (Model: WUH4000) Item Description Quantity Wireless transmitter (TX unit) Wireless receiver (RX unit) Partition Power adapter Power cord User guide Monitor VESA mount bracket HDMI 1.4 to HDMI 1.4 cable, 1.5 feet HDMI to DVI cable, 1.5 meter* Video splitter/adapter (optional, if required) Micro USB cable for power from wireless receiver to splitter/adapter, 1.5 feet... - Page 19 Package Contents Part No.: WUH4000 (Model: WUH4000) Item Description Quantity Wireless transmitter (TX unit) Wireless receiver (RX unit) Partition Power adaptor Power cord User guide Monitor VESA mount bracket HDMI 2.0 to HDMI 2.0 cable, 2 meter Mounting screw packet Verify that all components for the respective package are accounted for.
-
Page 20: Installation
Plan the Installation WUH4000 Identify the signal source for wireless transmission (example Determine the location of the WUH4000 transmitter (TX) unit (example Find a suitable power source for the transmitter. Identify the destination to receive the wireless signal (example Determine the location of the WUH4000 receiver (RX) unit (example Find a suitable power source for the receiver. - Page 21 Example of the supplied VESA mount bracket attached to the back of a display monitor. The WUH4000, RX or TX, is con- nected to the VESA mount bracket. source destination A properly operating wireless system 8/2021...
-
Page 22: Panel Interface
Link LED - Amber color. Shows the status of the wireless connection between a TX and RX unit. Power LED - Green color. Shows if the TX and RX units have power or not. SET button - Will reactivate the WUH4000 system if in sleep mode. Power input - Supplies power to the TX or RX units. -
Page 23: Directions For Use
*Video Adapter Most HD display monitors using a DVI signal can be connected directly to the WUH4000 receiver (RX) unit. However, if WUH4000 is unable to successfully transmit video from the TX to the RX, then the video adapter that is supplied with WUH4000 may be required to establish a successful connection. - Page 24 Typical Confi guration / Directions for Use Part No.: WUH4000, WUH4000-D (Model: WUH4000) Power adapter. 4K UHD source signal HDMI input to transmitter. Wireless signal connection. Power adapter. HDMI output from receiver. 4K UHD display monitor or similar destination. 8/2021...
- Page 25 Sleep Mode. If, after 2 minutes, there is no active source signal or destination recognized by a WUH4000 system, the system will go into sleep mode and the amber LED will turn off . To exit sleep mode, establish an active source signal and destination. Briefl y pressing the SET button will also exit sleep mode.
-
Page 26: General Specifi Cation
Specifi cation WUH4000 General Item Feature Description Wireless standard 60 GHz WiHD frequency Uncompressed video stream up to Stream video 4K/UHD resolution Latency Less than one frame Range 10 meter, (NLOS) Main Signal strength On-screen indicator Antenna scheme Beam steering technology... - Page 27 Specifi cation (continued) WUH4000 Item Feature Description TX: 0.57 kg (1.25 lbs.) Weight RX: 0.23 kg (0.5 lbs.) Shipping package: TBD TX: 75.8 (H) x 140 (W) x 98.25 (D) mm Physical 2.98 (H) x 5.51 (W) x 3.87 (D) inches RX: 75.8 (H) x 55 (W) x 98.25 (D) mm...
-
Page 28: Video Resolution Timing
Video Resolution Timing WUH4000 Item Feature Description 640 x 480p(VGA) 60Hz 4:4:4 8 bits 848 x 480(WVGA) 60Hz 4:4:4 8 bits 800 x 600 (SVGA)) 60Hz 4:4:4 8 bits 1024 x 768(XGA) 60Hz 4:4:4 8 bits 1280 x 1024(SXGA) 60Hz... -
Page 29: Appendix
Part No.: FHD-1TX-2RX (Model: WUH4000) A WUH4000 system has the ability to incorporate two RX units. Both RX units can show the same image coming from a TX unit. A 1-TX 2-RX system from the factory is already paired and should link using normal procedures described in this guide. - Page 30 Part No.: WUH4000-D (Model: WUH4000) A WUH4000 system has the ability to incorporate two RX units. Both RX units can show the same image coming from a TX unit. A 1-TX 2-RX system from the factory is already paired and should link using normal procedures described in this guide.
-
Page 31: Wuh4060
WUH4060 Maintenance of Quality of Service WUH4060 WUH4060 is designed to maintain an adequate Quality of Service during its use in a hospital operating room environment. Design Characteristics: Interference from other WUH4060 Devices Using a unique mating procedure implemented during manufacture, a WUH4060 transmitter is programmed to work only with authenticated WUH4060 receivers. - Page 32 Maintenance of Quality of Service WUH4060 For best results, verify the following: • The TX and RX units are between 1.525 meters (5 feet) and 10 meters (33 feet) apart from each other and without obstruction. • The TX and RX are between 1.8-3 meters (6-10 feet) above the fl oor. •...
-
Page 33: Package Contents
Package Contents WUH4060 Item Description Quantity Wireless transmitter (TX unit) Wireless receiver (RX unit) Power adapter Power cord WUH4060 VESA mount bracket HDMI 2.0 to HDMI 2.0 cable, 2 meter Mounting screw packet Verify that all components are accounted for. Inspect each component to verify that none have been tampered with in any way. -
Page 34: Installation
Plan the Installation WUH4060 Identify the signal source for wireless transmission (example Determine the location of the WUH4060 transmitter (TX) unit (example Find a suitable power source for the transmitter. Identify the destination to receive the wireless signal (example Determine the location of the WUH4060 receiver (RX) unit (example Find a suitable power source for the receiver. - Page 35 Example of the supplied VESA mount bracket attached to the back of a display monitor. The WUH4060, RX or TX, is connected to the VESA mount bracket. source destination A properly operating wireless system 8/2021...
-
Page 36: Panel Interface
Panel Interface WUH4060 Transmitter OLED display menu - Indicates the current user mode. TX: Pair, Unpair, 3D, Firmware Version. RX: Signal Quality Graph, Pair, Unpair, 1.06 3.58 Firmware Version. OLED display menu Network status LED - Off = TX or RX are not paired, or power Joystick power is off . -
Page 37: Directions For Use
Typical Confi guration / Directions for Use WUH4060 Power adapter. 4K UHD source signal input to transmitter. Wireless signal connection. Power adapter. Output from receiver to destination. HDMI or 12G SDI. 4K UHD display monitor or similar destination. 8/2021... - Page 38 Link TX and RX and Begin Wireless Transmission WUH4060 With an active signal feeding the TX, an active destination such as a display monitor connected to the RX, and power connected to both TX and RX, wireless transmission should begin. Receiver (TX) Transmitter (RX) start-up messages...
- Page 39 Advanced TX and RX pairing if required. NOTE: All WUH4060 TX and RX units sold together are programmed at the factory, and should connect automatically. For advanced unit pairing, see the steps below, or contact FSN Medical Technologies for detailed information.
-
Page 40: General Specifi Cation
Specifi cation WUH4060 General Item Feature Description Wireless standard 5 GHz frequency Streaming Uncompressed video and audio streams Latency Near zero (<1ms) Main Range 30 meters, (non line of sight) Signal strength OSD (On/Off option) Private data encryption 256-bit AES, RSA 1024 keys Input/Output signal HDMI 2.0, 12G 4Kp 23.98/24/25/29.97/30/50/59.94/60... - Page 41 Specifi cation (continued) WUH4060 Item Feature Description TX: 0.36 kg (0.79 lbs.) Weight RX: 0.43 kg (0.95 lbs.) Shipping package: 3.81 kg (8.4 lbs.) TX: 132 (H) x 91 (W) x 27 (D) mm Physical attributes 5.2 (H) x 3.58 (W) x 1.06 (D) inches RX: 112 (H) x 139 (W) x 27 (D) mm Dimension 4.41 (H) x 5.47 (W) x 1.06 (D) inches...
-
Page 42: Video Resolution Timing
Video Resolution Timing WUH4060 Resolution Color Color Sub- HDMI Type Frame Rate H x V Space Depth Sampling 4096x2160 8-bit 4:4:4 60Hz,59.94Hz,50Hz,30Hz, 29.97Hz,25Hz,24Hz,23Hz 4096x2160 8-bit 4:4:4 30Hz, 29.97Hz, 4096x2160 10-bit 4:4:4 25Hz,24Hz,23Hz 4096x2160 60Hz,59.94Hz,50Hz 8-bit 4:2:2 60Hz,59.94Hz,50Hz,30Hz, 4096x2160 10-bit 4:2:2 29.97Hz,25Hz,24Hz,23Hz 4096x2160 60Hz, 59.94Hz, 50Hz... - Page 43 8/2021...
- Page 44 Thank you for choosing our product. Service Contact the appropriate customer service listed below for product information or assistance. Warranty One year, parts and labor. EC Representative KTR Europe GmbH Mergenthalerallee 77, Eschborn 65760, Germany Tel : +49(0)6196-887170 FORESEESON GmbH Industriestrasse 38a, 63150 Heusenstamm, Germany Tel.
