Summary of Contents for TOOL WAREHOUSE WT83508
- Page 1 PROFESSIONAL HYDRAULIC GARAGE JACK-3T WT83508 Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
- Page 2 INTENDED USE This heavy-duty jack has a single hydraulic pump piston that effortlessly raises the lift arm. Pump piston dust shields and wiper seals protect the hydraulic system from contaminants. The jack features an overload valve bypass system to prevent jack damage and user injury. Compact design allows use in confined spaces. Easily fits under low vehicles.
- Page 3 SAFETY Always follow safety precautions when installing and operating this jack. Keep all decals on the unit clean and visible. Before proceeding ensure that you fully understand and comprehend the full contents of this manual. Failure to operate this equipment as directed may cause injury or death. The distributor is not responsible for any damages or injury caused by improper use or neglect.
- Page 4 ASSEMBLY DIAGRAM No. Part Description No. Part Description T83508.3 Power unit assembly GB859-M6 Spring washer M6 T83508.3.1(asm) Universal Joint Assembly GB67-M6X10 Machine screw M6X10 GB308-6 Steel ball Φ6mm Handle socket shaft T84004-7 Rubber sleeve TF1201C-29 Oil plug Spring washer M8 Return spring Machine screw M8X20mm Cotter pin Φ4x40mm...
