Neogen Ideal Prima 332240 Instruction Manual

CLEANING INSTRUCTIONS

1.) LINE CLEANING: Before REMOTE
disassembling the vaccinator for DRAW-OFF
cleaning, clean the line. Partially fill a
SPIKE
sink or small container with hot, soapy
water. Hold the remote draw-off spike
underneath the water in one hand while
holding the vaccinator in the other.
Continuously squeeze the vaccinator,
pumping water through it until clean.
To rinse, repeat with clean water.
FEED LINE
D
3.) HANDLE CLEANING: Remove the feedline from the vaccinator. At this
point, the remaining handle assembly(D) should be washed or allowed to soak in
hot soapy water, then rinsed and allowed to dry. Before reinstalling the barrel
assembly, apply 1 or 2 drops of food-grade lubricant to the piston o-ring (E).
Squeeze the handle to move the piston forward, making it more accessable.
E
4.) REASSEMBLY: Reinstall the needle (A) nut onto the barrel (B) and resintall
barrel onto handle assembly-hand tighten only.
!!CAUTION!! DO NOT OVER TIGHTEN NEEDLE NUT OR BARREL! FINGER
TIGHTEN ONLY! OVERTIGHTENING CAN CAUSE BARREL BREAKAGE!
DO NOT PLACE ANY PART OF THE VACCINATOR IN A MICROWAVE OVEN
*PRIMA TECH
OR NEAR A HEAT SOURCE!
CLEANING KIT
PART# 341013.*

UNI-LOCK ASSEMBLY INSTRUCTIONS

Spike
1. Place rubber flat
2. Place spike
washer onto spike.
collar onto
bottle.
Rubber flat
washer
Spike Collar
Lock
4. Attach
spike collar
5. Insert
lock to spike
tubing
collar by
onto spike
rotating
hose barb.
clockwise.
Prima Tech instruction form #340887-A
2.) BARREL REMOVAL: Unscrew the
needle nut (A) from the barrel (B). Next,
unscrew the barrel, turning it by the
barrel flange (C) remove enitre barrel
from vaccinator. Wash the all parts in hot,
soapy water, then rinse. Use the supplied
brush to remove any remaining
contaminants from barrel.
B
C
A
Spike Collar
3. Insert
spike into
bottle.
Flexible
Tubing
6. Attach syringe to free end of
tubing. The assembly is ready
for use.
English 1-2019
Neogen Corporation
944 Nandino Bl vd • Lexington, K Y 40511
800-525-2022 • 859-254-1221
www.neogen.com
INSTRUCTION MANUAL
SHOOTER
English 1-2019
